zugbruecke 0.0.2

Calling routines in Windows DLLs from Python scripts running under Linux, MacOS or BSD

Synopsis

zugbruecke is an EXPERIMENTAL Python module (currently in development status 3/alpha). It allows to call routines in Windows DLLs from Python code running on Unices / Unix-like systems such as Linux, MacOS or BSD. zugbruecke is designed as a drop-in replacement for Python’s standard library’s ctypes module. zugbruecke is built on top of Wine. A stand-alone Windows Python interpreter launched in the background is used to execute the called DLL routines. Communication between the Unix-side and the Windows/Wine-side is based on Python’s build-in multiprocessing connection capability. zugbruecke has (limited) support for pointers and struct types. zugbruecke comes with extensive logging features allowing to debug problems associated with both itself and with Wine. zugbruecke is written using Python 3 syntax and primarily targets the CPython implementation of Python.

About Wine (from winehq.org): Wine (originally an acronym for “Wine Is Not an Emulator”) is a compatibility layer capable of running Windows applications on several POSIX-compliant operating systems, such as Linux, MacOS and BSD. Instead of simulating internal Windows logic like a virtual machine or emulator, Wine translates Windows API calls into POSIX calls on-the-fly, eliminating the performance and memory penalties of other methods and allowing you to cleanly integrate Windows applications into your desktop.

This project is NEITHER associated NOR affiliated in any way or form with the Wine project.

Prerequisites

for usage	CPython 3.x (tested with 3.{4,5,6}) - no additional Python packages required Wine 2.x (tested with 2.{5,6,10,12} regular & staging) - expected to be in the user’s PATH
for tests	pytest mingw cross-compiler - for building DLLs against which examples and tests can be run
for documentation	Sphinx

Installation

master / release	pip install zugbruecke
development branch	pip install git+https://github.com/pleiszenburg/zugbruecke.git@develop

Examples

Start an interactive Python session under Unix and try the following:

from zugbruecke import cdll, c_double
dll_pow = cdll.msvcrt.pow
dll_pow.argtypes = (c_double, c_double)
dll_pow.restype = c_double
print('You should expect "1024.0" to show up here: "%.1f".' % dll_pow(2.0, 10.0))

You have just witnessed msvcrt.dll in action on Unix. Interested in more? Check the examples in zugbruecke’s documentation or read ctypes’ documentation.

A lot of code, which was written with cdll, windll or oledll in mind and which runs under Windows, should run just fine with zugbruecke on Unix (assuming it does not use Windows features not supported by Wine).

Speed

zugbruecke performs reasonably well given its complexity with less than 0.2 µs overhead per call in average on modern hardware. Check the latest benchmarks for more details.

Security

zugbruecke is notoriously insecure. Never, ever, run it with root / super users privileges! Do not use it where security matters! For details, check the section on security in the documentation.

Need help?

Feel free to post questions in the GitHub issue tracker of this project. Make sure to label them as question.

Bugs & issues

• Report bugs in zugbruecke here: GitHub issue tracker

• Report bugs in ctypes here: Python tracker

• Report bug in Wine here: WineHQ Bug Tracking System

Make sure you have read the chapter on bugs in zugbruecke’s documentation.

Miscellaneous

• Full project documentation

  • at Read the Docs

  • at zugbruecke repository

• License (LGPL v2.1)

• Contributing (Contributions are highly welcomed!)

• FAQ

• Authors

• Missing features (for full ctypes compatibility)

• Long-term ideas

• Upstream issues (relevant bugs in dependencies)

For production environments

DO NOT run this code (as-is) in production environments unless you feel that you really know what you are doing or unless you are absolutely desperate! Being experimental in nature and of alpha quality, it is prone to fail in a number of unpredictable ways, some of which might not be obvious or might not even show any (intermediately) recognizable symptoms at all! You might end up with plain wrong, nonsensical results without noticing it!
