SharedPubSub 2.0.0

Shared memory Publisher and Subscriber library

SharedPubSub

Provides Publisher and Subscriber classes for lock-free inter-process communication using POSIX shared memory with direct access, queues and notification.

Demo

Main features

• Lock-free at runtime.
• Event driven notification ; no need to poll for data.
• Can use atomic types for main data, will automatically use the non-atomic version for queues and readings.
• Templated, meaning you can share normal data, structs, objects, etc.
• Cross-language compatible (C++,Python,Javascript(NodeJS) )
• Multiple subscribers to one publisher.
• Publisher can send data to subscriber's queue to read data in order.
• Publishers and Subscribers also have direct access to data for custom loop timing ; Subscriber can read the current value at any time.
• Publishers and Subscribers can exit and come back at any time because the data persists in shared memory.
• Compatible on 32-bit and 64-bit platforms.

Main use cases

• Sharing data from a real-time loop to other threads/processes.
• Being able to receive data without spin looping.
• Being able to read data at any time, as opposed to MQTT which is only event driven. Ideal for multiple process that don't need the data at the same time or their processing time are different.
• Receive in-order data to make sure no data changes were missed.

Requirements

• A POSIX environment (Most Linux distros)
• C++20

How to import to a project

Python

install the library pip install SharedPubSub and import it into your project.

Functions (Python)

Publisher :

Function	Description	Usecase
publish	Set current value. Push value to subscribers' queue. Notify subscribers.	Set and send value to subscribers
publishOnChange	Same as publish, but only if the new value is different from the previous value.	Set and send value to subscribers only on change
readValue	Returns a copy of the topic's value.	To read before modifying the value. Useful if the publisher quits and comes back.
setValue	Set the current topic's value.	If we don't need to notify the subscribers, like if they do direct access.
setValueAndNotifyOnChange	Set the current topic's value and notify the subscribers.	If subscribers do direct access but still wants to get notified on change.
setValueAndPush	Set the current topic's value. Push value to subcribers' queue.	To send multiple values into subscribers' queue to notify them later so they can consume all at once or let them consume at their own pace.
notifyAll	To notify all subscribers.	If we just simply want to notify.
push	Send a value to subscribers' queue.	If we want to send value without setting the topic's value.
rawValue	returns a raw pointer to the topic's value.	To have direct access to the value. If publisher and subscribers have direct access to an atomic<> type or struc/object, they can use the value safely.

Subscriber

Function	Description	Usecase
subscribe	Opens a queue in the topic.	Enables the subscriber to get notified and read values in a queue.
clearQueue	Clears the subscriber's topic queue.	To start fresh
readValue	Returns a copy of the topic's value.	To read the current topic's value without the queue.
readWait	Pops a value in the queue. If no value,waits indefinitely for notification. Pops a value in the queue.	If we want to consume the queue or wait for a value in the queue without polling or a spinloop.
readWaitMS(timeout)	Same as readWait, but with a timeout.	If we want to make sure the program doesn't get stuck waiting forever.
waitForNotify	Simply wait for notification.	If the subscriber uses direct access but still wants to get notified.
waitForNotifyMS(timeout)	Same as waitForNotify, but with a timeout.	If we want to make sure the program doesn't get stuck waiting forever.
rawValue	returns a raw pointer to the topic's value.	To have direct access to the value. If publisher and subscribers have direct access to an atomic<> type or struc/object, they can use the value safely.

How to build and run examples

Examples are compatible between languages

Python

In the python_package folder :

• apt install libpython3-dev
• pip install .
• Examples are in the examples/python folder

Pub/Sub Example

Note : This example is only one of many mechanism. Please look at the examples folder.

Python

Publisher

from SharedPubSub import *
from time import sleep

publisher = Publisher_int("PubSub")
value = 0

while(True):
    value+=1
    publisher.publish(value)
    print("PUBLISHER PY :", value, "Normal publish")
    sleep(1)

Subscriber

from SharedPubSub import *

subscriber = Subscriber_int("PubSub","PubSubSubscriberPy",True)

while(True):
    value = subscriber.readWait()
    print("SUBSCRIBER :",value if value else "No value in queue")

Classes

This library as some base classes and a custom string classes.
YOU CAN IMPLEMENT YOUR OWN by changing the source code.

Custom Classes

• FixedString2048
• ExampleClass
• ExampleClassAtomic

Publisher Classes

• Publisher_bool
• Publisher_int
• Publisher_uint
• Publisher_int8
• Publisher_uint8
• Publisher_int16
• Publisher_uint16
• Publisher_int64
• Publisher_uint64
• Publisher_float
• Publisher_double
• Publisher_FixedString2048
• Publisher_ExampleClass

Atomic Publisher Classes

• Publisher_atomic_bool
• Publisher_atomic_int
• Publisher_atomic_uint
• Publisher_atomic_int8
• Publisher_atomic_uint8
• Publisher_atomic_int16
• Publisher_atomic_uint16
• Publisher_atomic_int64
• Publisher_atomic_uint64
• Publisher_atomic_float
• Publisher_atomic_double
• Publisher_ExampleClassAtomic

Subscriber Classes

• Subscriber_bool
• Subscriber_int
• Subscriber_uint
• Subscriber_int8
• Subscriber_uint8
• Subscriber_int16
• Subscriber_uint16
• Subscriber_int64
• Subscriber_uint64
• Subscriber_float
• Subscriber_double
• Subscriber_FixedString2048
• Subscriber_ExampleClass

Atomic Subscriber Classes

• Subscriber_atomic_bool
• Subscriber_atomic_int
• Subscriber_atomic_uint
• Subscriber_atomic_int8
• Subscriber_atomic_uint8
• Subscriber_atomic_int16
• Subscriber_atomic_uint16
• Subscriber_atomic_int64
• Subscriber_atomic_uint64
• Subscriber_atomic_float
• Subscriber_atomic_double
• Subscriber_ExampleClassAtomic

How to implement a custom class

• Create your own class in c++ and add sources into the python_package/src directory
• Don't forget to support copy constructor/assignment and operators
• Go into module.cpp and add include your file at the top
• navigate to PYBIND11_MODULE(SharedPubSub, m) {, where you can see other custom types.
• Copy the ExampleClass template and change to your need. .def_readwrite are for variables, and simple .def are for functions.
• Additionally, add your class to SharedPubSub.pyi for intellisens and autocompletion capabilities.

    py::class_<ExampleClass>(m, "ExampleClass")
        .def(py::init<>())
        .def_readwrite("value1", &ExampleClass::value1)
        .def_readwrite("value2", &ExampleClass::value2)
        .def_readwrite("value3", &ExampleClass::value3)
        .def("printValues",&ExampleClass::printValues);
    DECLARE(ExampleClass,"ExampleClass")

Things to watch out for

• There is a maximum number of values in a queue (which you can change). When the queue is full, the publisher will not push to it anymore. The subscriber needs to be able to consume the values faster than they are being published.
• All the data created in shared memory (/dev/shm) WILL PERSIST. The library does not destroy or clean the data, on purpose. That way, the publisher and subscriber can exit and come back at will and the data will still be valid. You have to manually handle cleaning if you want to.

Wish list

• Make it compatible with Windows and Mac
