fastapi-cruddy-framework 1.10.1

A holistic CRUD/MVC framework for FastAPI, with endpoint policies and relationships

FastAPI - Cruddy Framework

About Cruddy Framework

Cruddy Framework now supports GraphQL! For examples, see the example server!

fastapi-cruddy-framework is a companion library to FastAPI designed to bring the development productivity of Ruby on Rails, Ember.js or Sails.js to the FastAPI ecosystem. Many of the design patterns base themselves on Sails.js "policies," Sails.js model lifecycle events, sails-ember-rest automatic CRUD routing, and Ember.js REST-Adapter feature sets. By default, data sent to and from the auto-magic CRUD routes are expected to conform to the Ember.js Rest Envelope and Linked-data relationship specification. This specification is highly readable for front-end developers, allows for an expressive over-the-wire query syntax, and embeds self-describing relationship URL links in each over-the-wire record to help data stores automatically generate requests to fetch or update related records. This library is still in an alpha/beta phase, so use at your own risk. All CRUD actions and relationship types are currently supported, though there may be unexpected bugs. Please report any bugs under "issues."

TODO: Additional documentation and tests. (General features covered by tests) Maybe more comments. Maybe more features.

See the examples folder for a quick reference of high level setup. It currently contains a fully functional fastapi server which uses fastapi-cruddy-framework and the sqlite adapter. It even shows how to override incoming post data to do things like hash a user's password during initial registration using a simple drop-in policy function.

Come for the GraphQL and websocket managers, stay for the CRUD!

(back to top)

Front-end Libraries

If you are a front-end developer, you may be interested in using the following modules to help with making a UI that may communicate with a back-end server built with fastapi-cruddy-framework.

• cruddy-types npm, Github

(back to top)

FastAPI, SQLModel, Pydantic and SQL Alchemy Compatibility:

fastapi-cruddy-framework was originally developed against FastAPI <= 0.99.1, sqlmodel <= 0.0.12, pydantic < 2.0.0, and sqlalchemy < 2.0.0. However, beginning with fastapi-cruddy-framework version 1.x.x+, all major dependencies have been shifted forward to target FastAPI 0.100.0+, sqlmodel 0.0.14+, pydantic 2.0.0+, and sqlalchemy 2.0.0+. Therefore, when using this library, please note the following library compatibility chart:

fastapi-cruddy-framework@0.x.x:

• FastAPI <= 0.99.1
• SQLModel <= 0.0.12
• pydantic < 2.0.0
• sqlalchemy < 2.0.0

fastapi-cruddy-framework@1.x.x:

• FastAPI >= 0.100.0
• SQLModel >= 0.0.14
• pydantic >= 2.0.0
• sqlalchemy >= 2.0.0

Moving between fastapi-cruddy-framework versions? See the migration guides.

(back to top)

Installation

The fastapi-cruddy-framework module can be installed using poetry...

poetry add fastapi-cruddy-framework

Or pip.

pip install fastapi-cruddy-framework

After that, you can import and use all of the classes outlined below.

(back to top)

Cruddy Exports/Imports

Cruddy-framework provides users the following classes and helper functions to scaffold out a project. (For recommended project structure, see the "examples" folder in the Github repo)

# MASTER ROUTER GENERATOR
CreateRouterFromResources
# RESOURCE AND REGISTRY
Resource
ResourceRegistry
CruddyResourceRegistry
# CONTROLLER / CONTROLLER HELPERS
Actions
CruddyController
ControllerConfigurator
# REPOSITORY
AbstractRepository
# DATABASE ADAPTERS
BaseAdapter
SqliteAdapter
MysqlAdapter
PostgresqlAdapter
# CONSTANTS
BROADCAST_EVENT
CONTROL_EVENT
ROOM_EVENT
CLIENT_EVENT
KILL_SOCKET_BY_ID
KILL_SOCKET_BY_CLIENT
KILL_ROOM_BY_ID
JOIN_SOCKET_BY_ID
JOIN_SOCKET_BY_CLIENT
LEAVE_SOCKET_BY_ID
LEAVE_SOCKET_BY_CLIENT
CLIENT_MESSAGE_EVENT
DISCONNECT_EVENT
OPENAPI_WHERE_OVERRIDE
# TYPES / MODELS / SCHEMAS
T
UUID
RelationshipConfig
CruddyGenericModel
BulkDTO,
MetaObject
PageResponse
ResponseSchema
CruddyModel
CruddyCreatedUpdatedSignature
CruddyCreatedUpdatedMixin
CruddyIntIDModel
CruddyUUIDModel
CruddyStringIDModel
SocketMessage
SocketRoomConfiguration
ExampleUpdate
ExampleCreate
ExampleView
Example
# EXCEPTIONS
# CruddyNoMatchingRowException will be thrown if a database operation that should have succeeded didn't (typically due to row-level DB policies)
CruddyNoMatchingRowException
# WEBSOCKET MODULES
PubSub
WebsocketConnectionManager
RedisAdapter
# MODULE LOADER HELPERS
getModuleDir
getDirectoryModules
# HELPERS
pluralizer
uuid7
field_checkers
field_validators
field_errors
get_pk
possible_id_types
lifecycle_types
build_tz_aware_date
parse_datetime
coerce_to_utc_datetime
parse_and_coerce_to_utc_datetime
validate_utc_datetime
json_serial
to_json_string
to_json_object
get_state
set_state
# TEST HELPERS
BrowserTestClient
TestClient
WebSocketSession
# GRAPHQL EXPORTS
GraphQLController
GraphQLRequestCache
GraphQLResolverService
create_module_resolver
graphql_where_synthesizer
generate_gql_loader_and_type
GQL_WHERE_REPLACEMENT_CHARACTER
CruddyGQLDateTime
CruddyGQLObject
CruddyGQLArray
CruddyCreatedUpdatedGQLOverrides
CruddyGQLOverrides
# Security Exports
CruddyHTTPBearer

(back to top)

CreateRouterFromResources

This instance factory creates and returns a fully-wired fastapi APIRouter which sub-routes all Resource instances created in your project. Theoretically, you can create and mount multiple routers this way, but each router needs to be provided all of the Resource instances required to fully resolve the relationships it may care about. The recommended way to structure your project is to keep all resources required for a route set contained within a single folder. This factory is then provided the relative path to a resource set folder, starting with your application's main module, and will return the fully interconnected route set while also instantiating all of your resource modules. Typically, it is a good idea to import all of your router instances in your main module, as they will need to be "connected" to your fastapi server WITHIN the startup hook. This is critical, as the resource registry (discussed below) cannot fully resolve relationships until after SQLAlchemy is aware of all models. This occurs in-between launching your main module and the startup hook.

Example:

import my_app
from fastapi_cruddy_framework import CreateRouterFromResources
from fastapi import FastAPI, APIRouter


my_router: APIRouter = CreateRouterFromResources(
    # (REQUIRED) application_module is of "ModuleType" type, and should be a pointer to your main app module
    application_module=my_app,
    # (OPTIONAL) resource_path is of "str" type, and should specify a relative path from application_module
    # to the location of your "resources" that will be auto-loaded and bundled under this router
    # tree.
    resource_path="resources",
    # (OPTIONAL) common_resource_name is of "str" type, and should describe the common export value in each
    # resource file where the router factory can find your "Resource" instances. Use this if you want to name
    # all of your resource objects something other than "resource"
    common_resource_name="resource"
)

app = FastAPI(title="My App", version="1")

@app.on_event("startup")
async def bootstrap():
  app.include_router(my_router)

# fin!

(back to top)

Resource

The Resource class is the fundamental building block of fastapi-cruddy-framework. Your resource instances define the union of your models, resource "controller" (which is a fastapi router with baked-in CRUD logic), business policies, repository abstraction layer, any resource lifecycle hook, and database adapter. Fortunately for you, the user, everything is essentially ready-to-go out of the box. Like sails-ember-rest or Ruby on Rails, you can now focus all of your development time on creating reusable policies (which contain your business logic that lies just above your CRUD endpoints), defining your models, and extending your resource controllers to add one-off actions like "login" or "change password". Lifecycle actions allow you to alter query configurations or record data before or after it is persisted to a database, or perform some other task before replying to the user. All of your resources should be loaded by the router factory (above) to ensure that relationships and routes are resolved in the correct order. Don't forget, only plug the master router into your application in the fastapi startup hook!

Resource Nuances:

• Defining your policies is done at definition time!
• Lifecycle actions occur immediately before and after any database interaction your CRUD controllers make
• Lifecycle actions passed into the Resource constructor to interact with your queries or data MUST be async functions.
• Policies are run in the exact order in which they are included in the list sent to the resource definition.
• policies_universal apply to ALL CRUD routes, and always run BEFORE action specific policy chains.
• Action specific policies run AFTER all policies_universal have resolved successfully.
• Each endpoint is protected by policies_universal + policies_<action>.
• One-to-Many and Many-to-Many sub-routes (like /users/{id}/posts) will be protected by the policy chain: user.policies_universal + user.policies_get_one + posts.policies_get_many. Security, security, security!
• Blocking user REST modification of certain relationships via the default CRUD controller is also done at definition time!
• protected_relationships, protected_create_relationships and protected_update_relationships are list[str] types with each string indicating a one-to-many, many-to-one, or many-to-many relationship that should not be allowed to create or update via the default CRUD actions. (protected_relationships alone blocks BOTH)
• You should define your application-wide adapter elsewhere and pass it into the resource instance.
• Resources cannot span different databases.

Available Policy Chain Definitions:

• policies_universal
• policies_create
• policies_update
• policies_delete
• policies_get_one
• policies_get_many

Available ASYNC Repository Level Lifecycle Hooks:

• lifecycle_before_create
• lifecycle_after_create
• lifecycle_before_update
• lifecycle_after_update
• lifecycle_before_delete
• lifecycle_after_delete
• lifecycle_before_get_one
• lifecycle_after_get_one
• lifecycle_before_get_all
• lifecycle_after_get_all
• lifecycle_before_set_relations
• lifecycle_after_set_relations

Available ASYNC Controller Level Lifecycle Hooks:

• lifecycle_before_controller_create
• lifecycle_after_controller_create
• lifecycle_before_controller_update
• lifecycle_after_controller_update
• lifecycle_before_controller_delete
• lifecycle_after_controller_delete
• lifecycle_before_controller_get_one
• lifecycle_after_controller_get_one
• lifecycle_before_controller_get_all
• lifecycle_after_controller_get_all

Available Relationship Blocks:

• protected_relationships
• protected_create_relationships
• protected_update_relationships

Updating Relationships:

• You can update relationships via either CREATE or UPDATE actions against each base resource!

As you will discover, your resource's create and update models will automatically gain "shadow" properties where one-to-many and many-to-many relationships exist. These properties expect a client to send a list of IDs that specify the foreign records that relate to the target record. So - if a user is a member of many groups, and a group can have many users, you could update the users in a group by sending a property "users": [1,2,3,4,5] within the group payload object you send to the POST /groups or PATCH /groups routes/actions. It will all be clear when you look at the SWAGGER docs generated for your API.

Repository Lifecycle hooks

The following lifecycle hook methods, which can be defined in user-space code, receive the following information from fastapi-cruddy-framework:

lifecycle_before_create - Record without an ID. Values altered on this record in the lifecycle hook will be persisted to the DB.

lifecycle_after_create - Record with an ID, as returned from the database.

lifecycle_before_update - A key-values dictionary to be applied to the database, and the primary key id of the record which will be updated. Values altered in the dictionary will be applied to the DB update.

lifecycle_after_update - Record with an ID, as returned from the database

lifecycle_before_delete - Record with an ID, as returned from the database.

lifecycle_after_delete - Record with an ID, as returned from the database. This record no longer exists in the database.

lifecycle_before_get_one - A primary key value that will be used to fetch the record from the database, and a secondary where filter if one was used.

lifecycle_after_get_one - Record with an ID, as returned from the database.

lifecycle_before_get_all - Recieves a query configuration object. Any user-space modifications to this object will impact the query made by fastapi-cruddy-framework. This method is also invoked when a foreign Resource queries a relationship that affects the Resource where you plug in this hook.

lifecycle_after_get_all - Receives a BulkDTO object, containing the database objects retrieved by a get_all query, as well as the query metadata. This method is also invoked when a foreign Resource queries a relationship that affects the Resource where you plug in this hook.

lifecycle_before_set_relations - Receives a relationship configuration object which containts information about the record id affected, the relationship being altered, and the new list of relations for this relationship type.

{
    "id": id, # The database id whos relationship are about to be altered (of your defined PK type)
    "relation": relation, # The relationship that is about to change (string)
    "relations": relations # An array of foreign ids, or record dictionaries that will now define this relationship (Framework will attempt to discard old relations)
}

lifecycle_after_set_relations - Receives a completed mapping of the affected relational change, which can be used to echo changes to other databases or services.

{
    "model": model, # The CruddyModel affected by this relationship change
    "relation_conf": relation_conf, # The configuration object from lifecycle_before_set_relations
    "relation_type": MANYTOMANY, # An SQL Alchemy relationship-type identifier (MANYTOMANY or ONETOMANY)
    "related_table": foreign_table, # The table that ultimately represents the far-side of this relationship (not the join table!)
    "related_field": field_name, # The field on the related_table that represents the far side of the relationship
    "updated_db_count": result # The number of records now in the database associated with this relationship. If the number is different than the length of relation_conf.relations, you probably have a non-nullable field on the far-side of this relationship.
}

Controller Lifecycle hooks

The following lifecycle hook methods, which can be defined in user-space code, receive the following information from fastapi-cruddy-framework:

lifecycle_before_controller_create - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_after_controller_create - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_before_controller_update - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_after_controller_update - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_before_controller_delete - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_after_controller_delete - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_before_controller_get_one - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_after_controller_get_one - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_before_controller_get_all - request (a FastAPI Request), context (A mutable action context dictionary)

lifecycle_after_controller_get_all - request (a FastAPI Request), context (A mutable action context dictionary)

Resource Definition Options (And Defaults!):

id_type: Type[int] | Type[UUID] = int,
# You SHOULD pass in 'adapter'
adapter: BaseAdapter | SqliteAdapter | MysqlAdapter | PostgresqlAdapter | None = None,
# The following adapter specific options will probably get removed. You don't need to pass them in.
# They exist solely in the event you are defining disparate resources and want the resources to
# automatically build their own adapters. This is probably not a great idea.
adapter_type: Literal["mysql", "postgresql"] = "postgresql",
db_mode: Literal["memory", "file"] = "memory",
db_path: str | None = None,
connection_uri="",
pool_size=4,
max_overflow=64,
# link_prefix will be applied at the beginning of each relationship link on each record.
# This can help with things like sub-domains, or CORS with your API, and will allow you
# to point your relationships endpoints at a complete URL. You could pass in something like
# https://api.mydomain.com, which would make a relationship link look like
# https://api.mydomain.com/resource/{id}/relationship
link_prefix="",
# Path specifies where this resource resides within the API. This is generated for you by
# default. Only change if you know what you are doing. Ember.js would expect a resource path
# to be the pluralized name of its base model. So a 'user' resource should be accessible at
# '/users', and all of its sub-routes and actions are nested under that route.
path: str = None,
# The "tags" list corresponds with the fastapi "tags" list. You can alter this if needed.
# It is defined for you initially as the singular name of your resource model. User -> 'user'
tags: list[str] = None,
# The next four options are mandatory. 'create_model' specifies the inner schema that is
# allowed to be sent to the create endpoint by a user. It will be auto-wrapped in a REST
# envelope schema. 'update_model ' specifies the inner schema that is allowed to be sent
# to the update endpoint by a user. It too will be auto-wrappted in a REST envelope schema.
# 'resource_model' is your base model, which includes all possible fields of your model and
# has table=True specified. 'response_schema' defines the fields of your model to return
# to the client during all CRUD transactions. 'response_schema' will be wrapped in REST
# envelope in both single and many responses. Only 'resource_model' should have a table!!
# All of your models should descend from CruddyModel, which is a simple SQLModel class.
resource_create_model: CruddyModel = ExampleCreate,
resource_update_model: CruddyModel = ExampleUpdate,
resource_model: CruddyModel = Example,
response_schema: CruddyModel = ExampleView,
# 'response_meta_schema' allows you to remap the "meta" values returned to the client for
# any paginated routes. You shouldn't NEED to change this, but you can if you want.
response_meta_schema: CruddyGenericModel = MetaObject,
# 'protected_relationships' will ban-hammer relationship fields specified from gaining
# an auto-magic create or update property. This will prevent users from creating or updating
# these relationships via the default CRUD actions. You will need to build other business logic
# to manage creating or changing protected relationships elsewhere in your application.
# Protected relationships will still be viewable at their designated GET routes.
# 'protected_create_relationships' and 'protected_update_relationships' only prevent embedded
# relational changes at the CREATE and UPDATE routes, respectively.
protected_relationships: list[str] = [],
protected_create_relationships: list[str] = [],
protected_update_relationships: list[str] = [],
# 'artificial_relationship_paths' will add an arbitrary list of sub-paths to each CRUD object's
# relationship "links" attribute. For example, adding "artificial_relationship_paths": ["fake"]
# would cause each object's "links" attribute to contain a key-value pair of:
# "fake": "<link_prefix>/<model>/{id}/fake"
# within its links object. This can be used to create arbitrarily complicated controller GET
# actions (that can handle nested or complex relationships) and then have those actions
# successfully mapped into the RestAdapter compliant links specification for each object instance.
artificial_relationship_paths: list[str] = [],
# The following options allow you to pass in your Sails.js-like policy chains, which will
# run before all of your endpoints (in the case of universal), or in front of only specific
# endpoints that match the action specified. These policies can be used for nearly any purpose,
# from triggering other APIs and services, protecting endpoints to ensure only the correct
# users can alter data, or to intercept and even modify data before it gets to a default CRUD
# action! (Like hashing a user's password based on the plain-text password they send to register)
policies_universal: Sequence[Callable] = [],
policies_create: Sequence[Callable] = [],
policies_update: Sequence[Callable] = [],
policies_delete: Sequence[Callable] = [],
policies_get_one: Sequence[Callable] = [],
policies_get_many: Sequence[Callable] = [],
# The disable_<endpoint> options allow app developers to simply abort automatic generation of select
# CRUD endpoints on the resource's controller. For instance, to make a write-once collection a
# developercould set disable_update to True, which would cause the resource to abort building a route
# for PATCH resource/{id}. Be aware of the overall impact of endpoints you totally disable!
disable_create: bool = False,
disable_update: bool = False,
disable_delete: bool = False,
disable_get_one: bool = False,
disable_get_many: bool = False,
# The disable_relationship_getters list allow app developers to instruct the framework to NOT hoist
# an automatic GET route for a list of specific named relationships. Note, that any relationship name
# you disable will also cause the corresponding "link" entry that would point out that relationship
# to be removed from Swagger documentation, as well as from any returned link objects in real-world
# response payloads. This would effectively make a relationship invisble in GET routing.
disable_relationship_getters: list[str] = [],
# The disable_nested_objects flag prevents users from sending dictionaries inside of relationship arrays
# which the server will automatically unpack by default into an attempted create or update of the related
# resource. Any nested objects sent will still flow through the entire policy chain of the target resource!
# Any dictionary send with a primary key field will be handled as if it is an update. To create a new
# object via an embedded relationship, send the nested object without a primary key set!
disable_nested_objects: bool = False,
# Default limit will only set a limit on incoming queries if the user DOES NOT specify one. You should
# implement POLICIES to enforce a MAX limit, as you will ultimately have to re-use any max limit
# policies in your own custom controller functions for consistency. Max limit policies can be implemented
# by overriding any limit query parameter sent by the user with a maximum number if the user value is
# above whatever the max limit should be.
default_limit: int = 10,
# 'controller_extension' is the mount point for user-defined actions to-be-added to this resource's
# controller/router. Pass in your class definition and it will be instantiated at the appropriate
# time! See "CruddyController" example below!
controller_extension: CruddyController = None,
# 'custom_sql_identity_function' is an insertion point where you can pass in a lambda function or
# other SYNCHRONOUS callable that will return some sqlalchemy query segment that determines the identity
# of the resource in question. This is used for any CRUD actions that need to determine the identity
# of a single record. Your lambda function / callable will be passed the {id} param from the controller.
# You can use this to enable things like composite keys, and use {id} to capture <part a>.<part b>.
custom_sql_identity_function: Callable[..., Any] | None = None,
# 'custom_link_identity' is similar to custom_sql_identity_function, but is used specifically for building
# the {id} segment of a 'link' value in the response JSON. The custom_link_identity function you pass in
# will receive a record's value dictionary, which you can use to build a custom link {id} segment if needed.
# You can use this to enable things like composite keys, and format {id} as <record value a>.<record value b>.
custom_link_identity: Callable[..., str] | None = None,
# 'use_model_defaults' will wrap any record values sent to the `create` action with ANY added defaults from
# the base `model` for a resource. Setting this value to `false` would only propagate values contained in the
# actual POST body to the database level. If you use this feature, by setting this flag to `false`, you MUST
# have all required values generate their own defaults INSIDE the database.
use_model_defaults: bool = True,
# The following REPOSITORY lifecycle hooks can each recieve an async function which will be invoked
# before or after the target lifecycle event. Generally, whatever values are passed to the lifecycle
# hook are alterable WITHIN the hook so that userspace code can alter the behavior of the lifecycle
# based on app level concerns. This allows apps to do things like: hash a user password, force certain
# relationships to always exist, force "many" queries to obey sensible limits, commit log entries,
# send messages to queues for processing based on CRUD events, or generally handle unforseen
# circumstances.
lifecycle_before_create: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_create: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_update: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_update: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_delete: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_delete: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_get_one: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_get_one: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_get_all: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_get_all: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_set_relations: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_set_relations: Callable[..., Coroutine[Any, Any, Any]] | None = None,
# The following CONTROLLER lifecycle hooks can each recieve an async function which will be invoked
# before or after the target lifecycle event. Generally, whatever values are passed to the lifecycle
# hook are alterable WITHIN the hook so that userspace code can alter the behavior of the lifecycle
# based on app level concerns. CONTROLLER lifecycles hooks will also receive the REQUEST context,
# allowing the hook to take actions that consider the user and their priveleges, while still
# interleaving that logic within the cruddy action.
lifecycle_before_controller_create: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_controller_create: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_controller_update: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_controller_update: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_controller_delete: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_controller_delete: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_controller_get_one: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_controller_get_one: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_before_controller_get_all: Callable[..., Coroutine[Any, Any, Any]] | None = None,
lifecycle_after_controller_get_all: Callable[..., Coroutine[Any, Any, Any]] | None = None,

Below is an example for creating a user resource. The best way to organize your app would be to place the definition for your user resource in a folder like my_app/resources/user.py, where the name of your application is my_app. As you saw earlier in the description for CreateRouterFromResources you would then load this user resource file by simply specifying application_module=my_app and resource_path="resources". Your fastapi-cruddy-framework project would then auto-magically load your resource file(s), create dynamic routes to create, read, update, and delete this resource, and further create sub-routes within this resource to browse, query and update all of the relationships for your resource.

Example:

from fastapi_cruddy_framework import Resource, UUID
from my_app.adapters import sqlite
from my_app.models.user import (
    User,
    UserCreate,
    UserUpdate,
    UserView,
)
from my_app.schemas.response import MetaObject
from my_app.policies.verify_session import verify_session
from my_app.policies.hash_user_password import (
    hash_user_password,
)


resource = Resource(
    id_type=UUID,
    adapter=sqlite,
    resource_update_model=UserUpdate,
    resource_create_model=UserCreate,
    resource_model=User,
    response_schema=UserView,
    response_meta_schema=MetaObject,
    protected_relationships=["posts"],
    policies_universal=[verify_session],
    policies_create=[hash_user_password]
)

# fin!

Easy, right?

(back to top)

ResourceRegistry

The ResourceRegistry class should be invisible to the average user. There are no input parameters when creating a registry, and by default Cruddy defines its own library-internal registry. The registry exists to perform the following functions:

• Maintain a map of all resources available to fastapi-cruddy-framework
• Trigger resolve for all resources after SQL Alchemy finishes computing the relationship properties on each SQLModel.
• Plugin to the Resource class, so that each Resource you define can automatically call ResourceRegistry.register() when you define it. This is all "under the hood".

(back to top)

CruddyResourceRegistry

The CruddyResourceRegistry is a framework-created instance of the ResourceRegistry class, exposed as an export so that application builders can acquire framework component instance references dynamically. It manages all of the resources and other subordinate components the active Cruddy framework is aware of. This framework internal registry instance is extremely helpful for looking up resource, controller, and model classes and instances without causing a litany of circular import issues in app code. Due to the asynchronous nature of how cruddy framework must initialize, application developers should use the CruddyResourceRegistry to "lookup" objects in any app code that needs to use a fully functional framework instance. What's a good example of where this is useful? Acquiring a resource's repository instance from within a policy so you can run database checks before a CRUD action occurs. There are many other applicable scenarios. See example, below.

# This is an example policy file that could live in your project at policies/load_user_into_session.py
from fastapi import Request
from fastapi_cruddy_framework import AbstractRepository, CruddyResourceRegistry, BulkDTO

async def load_user_into_session(request: Request):
    some_value = "that identifies a user"
    user_repository: AbstractRepository = CruddyResourceRegistry.get_repository_by_name(model_name="User")
    repo_dto: BulkDTO = await user_repository.get_all(limit=1, where={"some_field": some_value})
    if len(repo_dto.data) == 0:
        raise Exception("User not found!")
    request.session.update({"user": repo_dto.data.pop()})

The available registry lookup function signatures are:

• get_model_by_name(model_name: str) -> CruddyModel
• get_relationships_by_name(model_name: str) -> dict
• get_resource_by_name(model_name: str) -> Resource
• get_repository_by_name(model_name: str) -> AbstractRepository
• get_controller_by_name(model_name: str) -> APIRouter
• get_controller_extension_by_name(model_name: str) -> CruddyController

Make sure that the model_name string you pass to the registry EXACTLY mirrors the class name for your base table CruddyModel. So for a model with a class of User you would pass in model_name="User". Pay attention to the capitalization!

(back to top)

Actions

The Actions class contains all the business logic for the base CRUD actions that are wired into a controller's route tree based on the framework options used. Each resource / controller will generate its own unique CRUD actions instance, and make this object available to user-space CruddyController instance, which are described in more detail below. Actions that are deferred from routing automatically (using option flags such as disable_create) are still generated for reach resource's actions map, which makes those functions available in the CruddyController setup function.

Available actions:

async def create(request: Request, data: create_model)

async def update(request: Request, id: id_type = Path(..., alias="id"), *, data: update_model)

async def delete(
    request: Request, id: id_type = Path(..., alias="id")
)

async def get_by_id(
    request: Request,
    id: id_type = Path(..., alias="id"),
    where: Json = Query(None, alias="where"),
)

async def get_all(
    request: Request,
    page: int = 1,
    limit: int = 10,
    columns: list[str] = Query(None, alias="columns"),
    sort: list[str] = Query(None, alias="sort"),
    where: Json = Query(None, alias="where"),
)

You can re-use CRUD actions in your controllers as follows:

from pydantic.types import Json
from fastapi_cruddy_framework import CruddyController
from fastapi import Query, Path, HTTPException, status
from fastapi_cruddy_framework import CruddyController, dependency_list
from examples.fastapi_cruddy_sqlite.policies.verify_session import verify_session


class UserController(CruddyController):
    def setup(self):
        # You can extend controller actions here!
        # You can also access:
        # self.actions
        # self.resource
        # self.repository
        # self.adapter
        # self.controller
        id_type = self.resource._id_type
        many_schema = self.resource.schemas["many"]

        # You can tap into the controller's CRUD actions map in the following ways:
        # 1. Override the action key
        old_delete = self.actions.delete

        async def new_delete(id: id_type = Path(..., alias="id"), confirm: str = "N"):
            if confirm == "Y":
                return await old_delete(id=id)
            else:
                raise HTTPException(
                    status_code=status.HTTP_400_BAD_REQUEST,
                    detail="You must confirm you want to delete this record by setting the 'confirm' parameter to 'Y'",
                )

        self.actions.delete = new_delete

        # 2. Provide a new route to an existing function (notice, no @ symbol!)
        self.controller.get(
            "/all",
            description="Another way to get many users",
            response_model=many_schema,
            response_model_exclude_none=True,
            dependencies=dependency_list(verify_session),
        )(self.actions.get_all)

        # 3. Re-use within your own function
        @self.controller.get(
            "/everything",
            description="Yet another way to get many users",
            response_model=many_schema,
            response_model_exclude_none=True,
            dependencies=dependency_list(verify_session),
        )
        async def get_all_again(
            page: int = 1,
            limit: int = 10,
            columns: list[str] = Query(None, alias="columns"),
            sort: list[str] = Query(None, alias="sort"),
            where: Json = Query(None, alias="where"),
        ):
            return await self.actions.get_all(
                page=page, limit=limit, columns=columns, sort=sort, where=where
            )

(back to top)

CruddyController

The CruddyController is a base class with a single method setup that applications can leverage to "extend" the default CRUD route controllers as needed. This class is needed to control application flow during the resolution boot cycle, and to allow you to share methods between resources like a mixin. Controllers should generally be placed within a project folder named "controllers". Controller classes can be imported in your resource file, and passed to the resource at definition time. Don't worry, the Resource class will create a controller instance for you!

Example my_app/controllers/User.py:

from fastapi import Depends
from fastapi_cruddy_framework import CruddyController, CruddyGenericModel
from my_app.policies.verify_session import verify_session

class HelloSchema(CruddyGenericModel):
    hello: str = "world"

class UserController(CruddyController):
    def setup(self):
        # You can extend controller actions here!
        # You can also access:
        # self.actions
        # self.resource
        # self.repository
        # self.adapter
        # self.controller
        @self.controller.get(
            "/hello", response_model=HelloSchema, dependencies=[Depends(verify_session)]
        )
        async def hello():
            return HelloSchema(hello="world")

Example Continued my_app/resources/User.py:

from fastapi_cruddy_framework import Resource, UUID
from my_app.adapters import sqlite
from my_app.models.user import (
    User,
    UserCreate,
    UserUpdate,
    UserView,
)
from my_app.schemas.response import MetaObject
from my_app.controllers.user import UserController
from my_app.policies.verify_session import verify_session
from my_app.policies.hash_user_password import (
    hash_user_password,
)


resource = Resource(
    adapter=sqlite,
    response_schema=UserView,
    response_meta_schema=MetaObject,
    resource_update_model=UserUpdate,
    resource_create_model=UserCreate,
    resource_model=User,
    protected_relationships=["posts"],
    id_type=UUID,
    policies_universal=[verify_session],
    policies_create=[hash_user_password],
    controller_extension=UserController
)

Notice that you don't need to instantiate your controller!

CruddyController extension classes passed to the Resource definition will be setup() BEFORE the auto-generated CRUD routes but AFTER SQL Alchemy has resolved model relationships. This ensures that your user-defined routes receive priority for incoming HTTP requests. If extension classes were not loaded first, then the CRUD handlers would almost always intercept the incoming request first.

(back to top)

ControllerConfigurator

The ControllerConfigurator is a configuration function invoked by the Resource class after SQL Alchemy has resolved all model relationships. You shouldn't need to interact with this function, but if you're a super advanced user, or wunderkind, maybe you will find a reason to need this. In essence, this function builds out all of the basic CRUD logic for a resource, after the resource has constructed a repository and generated the shadow schemas for your models. This is where your CRUD routes and sub-routes are auto-magically configured.

The controller/router configured by each of your Resource objects will allow the base resource or its relationships to be queried from the client via an arbitrarily complex where object (JSON encoded query parameter).

Invalid attributes or ops are just dropped. (May change in the future)

Improvements that will be made in the near future:

1. Conditional table joins for relationships to...
2. Make resources searchable with joined relationships via dot notation in the where object!
3. Maybe throw an error if a bad search field is sent? (Will help UI devs)

Clients can build an arbitrarily deep query with a JSON dictionary, sent via a query parameter in a JSON object that generally contains all possible filter operators along with "and," "or," and "not" conditions.

Field level and boolean operators begin with a * character. This will nearly always translate down to the sqlalchemy level, where it is up to the model class to determine what operations are possible on each model attribute. The top level query of a where object is an implicit AND. To do an OR, the base key of the search must be *or, as in the below examples:

/resource?where={"*or":{"first_name":"bilbo","last_name":"baggins"}}

/resource/{id}/relationship?where={"*or":{"first_name":{"*contains":"bilbo"},"last_name":"baggins"}}

/resource?where={"*or":{"first_name":{"*endswith":"bilbo"},"last_name":"baggins","*and":{"email":{"*contains":"@"},"first_name":{"*contains":"helga"}}}}

/resource?where={"*or":{"first_name":{"*endswith":"bilbo"},"last_name":"baggins","*and":[{"email":{"*contains":"@"}},{"email":{"*contains":"helga"}}]}}

The following query would be an implicit *and:

/resource?where=[{"first_name":{"*endswith":"bilbo"}},{"last_name":"baggins"}]

As would the following query:

/resource/{id}/relationship?where={"first_name":{"*endswith":"bilbo"},"last_name":"baggins"}

"Dot" notation is currently supported for JSON or JSON-like columns. The following queries showcase this:

/resource?where={"user.config.favoriteColor":{"*eq":"black"}}

/resource?where={"favorites.":{"*contained_by":{"tags":["foo","bar","baz]}}}

/resource?where={"favorites.tags":{"*contains":["foo"]}}

(back to top)

AbstractRepository

The AbstractRepository is a helpful way to interact with the data layer of your models. It contains all of the underlying functions that the Resource and Controller objects use to query, create, update, and delete your database information. Each Resource you define will automatically create an AbstractRepository instance that manages it. This can be accessed in your application at your_resource_instance.repository. The methods available to you via this repository instance are:

# User functions accessible from any resource's 'AbstractRepository'
async def create(data: CruddyModel, request: Request = None)

async def get_by_id(id: UUID | int | str, request: Request = None)

async def update(id: UUID | int | str, data: CruddyModel, request: Request = None)

async def delete(id: UUID | int | str, request: Request = None)

async def get_all(page: int = 1, limit: int = 10, columns: list[str] = None, sort: list[str] = None, where: Json = None, request: Request = None)

async def get_all_relations(id: UUID | int | str = ..., relation: str = ..., relation_model: CruddyModel = ..., relation_view: CruddyModel = ..., page: int = 1, limit: int = 10, columns: list[str] = None, sort: list[str] = None, where: Json = None, request: Request = None)

async def set_many_many_relations(id: UUID | int | str, relation: str = ..., relations: list[UUID | int | str] = ..., request: Request = None)

async def set_one_many_relations(id: UUID | int | str, relation: str = ..., relations: list[UUID | int | str] = ..., request: Request = None)

Generally, these functions do about what you would expect them to do. More documentation will be added to describe their function soon. Please read nuances below, however, as it applies to how x-to-Many relationships are managed via the automatic CRUD routes.

Important AbstractRepository Nuances

• set_many_many_relations and set_one_many_relations both destroy and then re-create the x-to-Many relationships they target. If a user with the id of 1 was a member of groups 1, 2, and 3, then calling await user_repository.set_many_many_relations(1, 'groups', [4,5,6]) would result in user 1 being a member of only groups 4,5, and 6 after execution. Client applications should be aware of this functionality, and always send ALL relationships that should still exist during any relational updates.

(back to top)

Validators / Checkers

fastapi-cruddy-framework includes validators and checkers useful to enrich your model definitions by exporting field_checkers, field_validators, and field_errors objects. These objects are all simple re-exports of the core validators, checkers and errors from validator-collection. For additional documentation on what is available, see that project's README.

(back to top)

WebsocketConnectionManager

fastapi-cruddy-framework includes a relatively full-featured WebsocketConnectionManager that offers many of the same features as other great websocket libraries, such as socket.io. The easiest way to see the full capabilities of the websocket manager is to look at the example server used to test this library! For instance, here and here you can see how to instantiate a WebsocketConnectionManager. You can then bind an instance of a WebsocketConnectionManager to your ApplicationRoute, as seen here, using the async context manager's .connect() function to initiate a bidirectional websocket context that supports broadcasts, rooms, direct socket-to-socket messages, kill commands, a custom socket identity hook (to identify or kill many sockets owned by the same user), and a horizontally scaling control plane where you can even plugin your own custom commands! Note that you need to .startup() and .dispose() of a WebsocketConnectionManager in your application's lifespan hook, as seen here.

The WebsocketConnectionManager will receive more thorough documentation in the future when it becomes more stable, but it is fully tested in it's current state and is very reliable!

Note that currently the WebsocketConnectionManager requires redis to function. In the future, other broker types may be added as well! The pub/sub aspect is delegated to a separate class under the hood.

(back to top)

BrowserTestClient

The BrowserTestClient is a useful helper class to enable test suites to "boot" a Cruddy based app, and then use different virtual "browsers" to execute API tests against the app at the same time, against the same app instance. For usage examples, see tests/conftest.py and tests/crud/*.py. BrowserTestClient is designed to use the async ASGI server runner TestClient, which is re-exported from async-asgi-testclient. Assuming your app has some level of authentication present you could setup your own conftest.py to look like:

from logging import getLogger
from asyncio import get_event_loop_policy, sleep
from pytest import fixture, mark
from fastapi import FastAPI
from fastapi_cruddy_framework import TestClient, BrowserTestClient

logger = getLogger(__name__)

FAKE_AUTH_TOKEN = "somefaketokenvalue"
FAKE_AUTH_QP = f"?auth_token={FAKE_AUTH_TOKEN}"
FAKE_AUTH_HEADERS = {"Authorization": f"Bearer {FAKE_AUTH_TOKEN}"}


@fixture(scope="session", autouse=True)
def event_loop():
    loop = get_event_loop_policy().new_event_loop()
    yield loop
    loop.close()


@fixture(scope="session", autouse=True)
async def app():
    # Don't move this import!
    from your_app.main import app

    yield app


@fixture(scope="session", autouse=True)
async def client(app: FastAPI):
    # By using "with" the FastAPI app launch hook is run, connecting the application router
    async with TestClient(app, use_cookies=False) as client:
        while (await client.get("/health")).json() != True:
            await sleep(0.5)
        yield client


@fixture(scope="session", autouse=True)
async def unauthenticated_client(client: TestClient):
    blank_client = BrowserTestClient(client=client, cookies=None, headers=None)
    yield blank_client


@fixture(scope="session", autouse=True)
async def authenticated_client(client: TestClient):
    sessioned_client = BrowserTestClient(
        client=client, cookies=None, headers=FAKE_AUTH_HEADERS
    )
    await sessioned_client.get(f"/users/authorization{FAKE_AUTH_QP}")
    yield sessioned_client


@fixture(scope="function")
async def authenticated_websocket(authenticated_client: BrowserTestClient):
    async with authenticated_client.websocket_connect("/ws") as websocket:
        # For example: data = await websocket.receive_json()
        # Or await websocket.send_json(data)
        # If your server sends any kind of "welcome" messages, make
        # sure you purge them here BEFORE yielding the socket back
        # to whatever function needs to run tests
        yield websocket

(back to top)

Where Queries

Additional documentation will be added soon on complete functionality supported via the CRUD endpoint / AbstractRepository where parameter.

NEW QUERY FEATURES

Column casting!

To cast a column to a different type during a query, send a where payload like one of the examples below.

A tsvector cast:

where = {"column_name:tsvector:english": {"*websearch_to_tsquery": "foo or bar -baz"}}

The query stage's casting key name for tsvector should match the format <column_name>:tsvector:<vector language>.

tsvector is the most complicated form of casting, as it requires the cast type (tsvector) as well as the tsvector language (english, or another langauge) in the key definition.

tsvector then supports the following query operators at the next level: *websearch_to_tsquery and *match, both of which mirror the sqlalchemy docs regarding functionality.

To add a tsvector field to your cruddy data model, complete with proper indexing for performance, add the following to your table model class:

# models/example.py
from typing import Any
from sqlmodel import Field, cast, func, Text
from sqlalchemy import Column, Index, literal_column
from sqlalchemy.dialects.postgresql import JSONB, UUID as psqlUUID
from fastapi_cruddy_framework import  CruddyModel, CruddyCreatedUpdatedMixin, UUID, uuid7


class ExampleUpdate(CruddyModel):
    data: Any = Field(
        schema_extra={
            "json_schema_extra": {
                "example": {
                    "some": {
                        "key": "value"
                    }
                }
            }
        }
    )


class ExampleCreate(ExampleUpdate):
    pass


class Example(CruddyCreatedUpdatedMixin(), ExampleCreate, table=True):  # type: ignore
    id: UUID =  Field(
        sa_column=Column(
            psqlUUID(as_uuid=True),
            primary_key=True,
            index=True,
            nullable=False,
            default=uuid7,
        )
    )
    data: Any = Field(
        default=None,
        sa_column=Column(JSONB, nullable=True, default=None),
    )
    __table_args__ = (
        Index("ix_Example_data_gin", "data", postgresql_using="gin"),
        Index('ix_Example_data_tsvector', func.to_tsvector(literal_column("'english'"), cast(data.sa_column, Text)), postgresql_using="gin"),
    )

A Text (or any other) cast:

where = {"a_json_column_name:Text": {"*icontains": "some substring"}}

The query stage's casting key name should match the format <column_name>:<cast type>.

Generally cast types are straightforward and expect a query operator and input type that can be mapped to the column's casted type. Supported column cast types are:

array
tsvector
BigInteger
Boolean
Date
DateTime
Double
Enum
Float
Integer
Interval
LargeBinary
MatchType
Numeric
SmallInteger
String
Text
Time
Unicode
UnicodeText
Uuid
ARRAY
BIGINT
BINARY
BLOB
BOOLEAN
CHAR
CLOB
DATE
DATETIME
DECIMAL
DOUBLE
DOUBLE_PRECISION
FLOAT
INT
INTEGER
JSON
NCHAR
NUMERIC
NVARCHAR
REAL
SMALLINT
TEXT
TIME
TIMESTAMP
UUID
VARBINARY
VARCHAR

Value casting!

Datetime value with timezone:

where = {"datetime_column": {"*gt": {"*datetime": "2024-02-14T19:17:40.860657Z"}}}

Datetime value without timezone:

where = {"datetime_column": {"*gt": {"*datetime_naive": "2024-02-14T19:17:40.860657Z"}}}

(back to top)

GraphQL

Cruddy now supports GraphQL Read Operations! The GraphQL class APIs are considered unstable at the moment, but the GraphQL feature set is still secure, so it is safe to add it on top of your APIs!

For examples on how to integrate GraphQL functionality with your cruddy-based app, inspect the example server.

Additional documentation will be added once the GraphQL API stabilizes! The cruddy exports that are directly needed to enable GraphQL are:

GraphQLController
GraphQLRequestCache
GraphQLResolverService
create_module_resolver
graphql_where_synthesizer
generate_gql_loader_and_type
GQL_WHERE_REPLACEMENT_CHARACTER
CruddyGQLDateTime
CruddyGQLObject
CruddyGQLArray
CruddyCreatedUpdatedGQLOverrides
CruddyGQLOverrides

(back to top)

Contributing

To work on this repository, you need to take the following steps first:

• Use python 3.10+ for your local python environment. (library relies on alternative union syntax)
• Install pre-commit globally by using the command pip install pre-commit (This will be used to manage pre-commit git hooks)
• Clone this project git clone https://github.com/mdconaway/fastapi-cruddy-framework.git or git clone [e-mail]:mdconaway/fastapi-cruddy-framework.git
• cd into this project directory.
• Run make install to install all dependencies and setup git pre-commit hooks!
• Use make run-example-sqlite to hoist an example server while operating on the framework.
• Use make test to confirm functionality and ensure there are no regressions after modification.
• Submit pull requests for new feature additions.

(back to top)

License

Distributed under the MIT License. See LICENSE for more information.

(back to top)
