ffmpeg-bitrate-stats 1.3.3

Calculate bitrate statistics using FFmpeg

FFmpeg Bitrate Stats

Simple script for calculating bitrate statistics using FFmpeg.

Author: Werner Robitza [e-mail]

Note: Previous versions installed a ffmpeg_bitrate_stats executable. To harmonize it with other tools, now the executable is called ffmpeg-bitrate-stats. Please ensure you remove the old executable (e.g. run which ffmpeg_bitrate_stats and remove the file).

Contents:

• Requirements
• Installation
• Usage
• Output
• Plotting
• API
• Contributors
• License

---

Requirements

• Python 3.9 or higher
• FFmpeg:
  • download a static build from their website
  • put the ffprobe executable in your $PATH

Installation

Simply run it via uv:

uvx ffmpeg-bitrate-stats

Or install via pipx. Or with pip:

pip3 install --user ffmpeg_bitrate_stats

Usage

The script outputs a bunch of bitrate statistics, including aggregations for pre-defined windows. These windows can either be time-based or GOP-based (for video streams). When choosing a time-based window, you can specify the size of the chunks in seconds.

Output is to STDOUT so you can redirect that to a file or another script.

See ffmpeg-bitrate-stats -h:

usage: __main__.py [-h] [-n] [-v] [-q] [-s {video,audio}] [-a {time,gop}]
                   [-c CHUNK_SIZE] [-rs READ_START] [-rd READ_DURATION]
                   [-of {json,csv}] [-p] [-pw PLOT_WIDTH] [-ph PLOT_HEIGHT]
                   [--ffprobe-path FFPROBE_PATH]
                   input

ffmpeg_bitrate_stats v1.1.4

positional arguments:
  input                 input file

options:
  -h, --help            show this help message and exit
  -n, --dry-run         Do not run command, just show what would be done
                        (default: False)
  -v, --verbose         Show verbose output (default: False)
  -q, --quiet           Do not show progress bar (default: False)
  -s, --stream-type {video,audio}
                        Stream type to analyze (default: video)
  -a, --aggregation {time,gop}
                        Window for aggregating statistics, either time-based
                        (per-second) or per GOP (default: time)
  -c, --chunk-size CHUNK_SIZE
                        Custom aggregation window size in seconds (default:
                        1.0)
  -rs, --read-start READ_START
                        Time to wait before sampling video (in HH:MM:SS.msec
                        or seconds) (default: None)
  -rd, --read-duration READ_DURATION
                        Duration for sampling stream (in HH:MM:SS.msec or
                        seconds). Note that seeking is not accurate, see
                        ffprobe documentation on '-read_intervals'. (default:
                        None)
  -of, --output-format {json,csv}
                        output in which format (default: json)
  -p, --plot            Plot the bitrate over time (to STDERR) (default:
                        False)
  -pw, --plot-width PLOT_WIDTH
                        Plot width in characters (auto-detected to fit the
                        terminal if not set) (default: None)
  -ph, --plot-height PLOT_HEIGHT
                        Plot height in characters (auto-detected to fit the
                        terminal if not set) (default: None)
  --ffprobe-path FFPROBE_PATH
                        Path to ffprobe executable (default: ffprobe)

By default, a progress bar is shown during analysis. Use -q/--quiet to disable it, or -v/--verbose to show debug output instead.

Output

The output can be JSON, which includes individual fields for each chunk, or CSV, which repeats each line for each chunk. The CSV adheres to the “tidy” data concept, so it's a little redundant.

Rates are given in kilobit per second, using SI prefixes (i.e., kilo = 1000).

Explanation of the fields:

• input_file: Path to the input file
• stream_type: Type of stream used (video, audio)
• avg_fps: Average FPS (number of frames divided by duration)
• num_frames: Number of frames
• avg_bitrate: Average bitrate
• avg_bitrate_over_chunks: Average bitrate calculated over the chunks
• max_bitrate: Maximum bitrate calculated over the chunks
• min_bitrate: Minimum bitrate calculated over the chunks
• max_bitrate_factor: Relation between peak and average
• bitrate_per_chunk: Individual bitrates for each chunk
• aggregation: Type of aggregation used
• chunk_size: Size of the chunk (when aggregation is "time")
• duration: Total duration of the stream. It is the sum of all frame durations, where each frame's duration is either based on duration_time field in ffmpeg, or the difference between the current and previous frame's PTS.

JSON example:

ffmpeg-bitrate-stats -a time -c 30 -of json BigBuckBunny.mp4

This returns:

{
    "input_file": "BigBuckBunny.mp4",
    "stream_type": "video",
    "avg_fps": 60.002,
    "num_frames": 38072,
    "avg_bitrate": 8002.859,
    "avg_bitrate_over_chunks": 7849.263,
    "max_bitrate": 14565.117,
    "min_bitrate": 3876.533,
    "max_bitrate_factor": 1.82,
    "bitrate_per_chunk": [
        8960.89,
        8036.678,
        6099.959,
        4247.879,
        7276.979,
        5738.383,
        7740.339,
        7881.705,
        7572.594,
        8387.719,
        9634.343,
        9939.488,
        9365.104,
        5061.071,
        14565.117,
        9725.483,
        4573.873,
        7765.041,
        9796.135,
        12524.024,
        3876.533,
        3914.455
    ],
    "aggregation": "time",
    "chunk_size": 30.0,
    "duration": 634.517
}

CSV example:

➜  ffmpeg-bitrate-stats -a time -c 30 -of csv BigBuckBunny.mp4
input_file,chunk_index,stream_type,avg_fps,num_frames,avg_bitrate,avg_bitrate_over_chunks,max_bitrate,min_bitrate,max_bitrate_factor,bitrate_per_chunk,aggregation,chunk_size,duration
BigBuckBunny.mp4,0,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,8960.89,time,30.0,634.517
BigBuckBunny.mp4,1,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,8036.678,time,30.0,634.517
BigBuckBunny.mp4,2,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,6099.959,time,30.0,634.517
BigBuckBunny.mp4,3,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,4247.879,time,30.0,634.517
BigBuckBunny.mp4,4,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,7276.979,time,30.0,634.517
BigBuckBunny.mp4,5,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,5738.383,time,30.0,634.517
BigBuckBunny.mp4,6,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,7740.339,time,30.0,634.517
BigBuckBunny.mp4,7,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,7881.705,time,30.0,634.517
BigBuckBunny.mp4,8,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,7572.594,time,30.0,634.517
BigBuckBunny.mp4,9,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,8387.719,time,30.0,634.517
BigBuckBunny.mp4,10,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,9634.343,time,30.0,634.517
BigBuckBunny.mp4,11,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,9939.488,time,30.0,634.517
BigBuckBunny.mp4,12,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,9365.104,time,30.0,634.517
BigBuckBunny.mp4,13,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,5061.071,time,30.0,634.517
BigBuckBunny.mp4,14,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,14565.117,time,30.0,634.517
BigBuckBunny.mp4,15,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,9725.483,time,30.0,634.517
BigBuckBunny.mp4,16,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,4573.873,time,30.0,634.517
BigBuckBunny.mp4,17,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,7765.041,time,30.0,634.517
BigBuckBunny.mp4,18,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,9796.135,time,30.0,634.517
BigBuckBunny.mp4,19,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,12524.024,time,30.0,634.517
BigBuckBunny.mp4,20,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,3876.533,time,30.0,634.517
BigBuckBunny.mp4,21,video,60.002,38072,8002.859,7849.263,14565.117,3876.533,1.82,3914.455,time,30.0,634.517

Plotting

To enable plots, pass the -p or --plot flag. This will plot the bitrate over time to STDERR. You can redirect this to a file, or pipe it to another program. Or you can disable STDOUT output with >/dev/null to only see the plot:

ffmpeg-bitrate-stats -a time -c 30 -p BigBuckBunny.mp4 >/dev/null

This might output a plot like this:

  7474.000 |
  6975.733 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⡎⡆⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀
  6477.467 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⢰⠁⢱⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀
  5979.200 | ⡇⠀⠀⠀⠀⡀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⡎⠀⠈⡆⠀⡀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⢀⡄⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀
  5480.933 | ⡧⡀⠀⠀⢰⢱⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⢰⠁⠀⠀⠱⠊⠱⡀⠀⠀⠀⠀⢀⠤⡀⠀⠀⠀⠀⠀⠀⢀⡄⠀⠀⢠⠊⠈⡆⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀
  4982.667 | ⡇⠈⢆⠀⡜⠀⢣⠀⠀⠀⠀⠀⠀⡠⠒⠙⡄⠀⠀⡀⠀⠀⢀⡀⠀⢠⢢⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⡎⠀⠀⠀⠀⠀⠀⢣⠀⢀⣀⠤⠊⠀⠈⠑⠢⢄⠀⠀⢠⠊⠘⡄⡰⠁⠀⠀⠈⢢⠀⠀⠀⣀⠤⠤⡀⠀⠀⠀⠀
  4484.400 | ⡇⠀⠈⢶⠁⠀⠈⠦⣀⠀⠀⠀⡔⠁⠀⠀⠱⡀⢰⠙⡄⢀⠎⠈⠒⠁⠀⠱⡀⠀⠀⠀⢠⠓⡄⢀⠤⡀⢰⠁⠀⠀⠀⠀⠀⠀⠀⠋⠁⠀⠀⠀⠀⠀⠀⠀⠀⠉⠉⠁⠀⠀⠘⠁⠀⠀⠀⠀⠀⠑⠒⠊⠀⠀⠀⠈⠢⠤⡄⠀
  3986.133 | ⡇⠀⠀⠀⠀⠀⠀⠀⠈⢢⠀⡸⠀⠀⠀⠀⠀⢣⠃⠀⠘⠎⠀⠀⠀⠀⠀⠀⠈⢆⡀⠀⡎⠀⠈⠁⠀⠱⡎⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⢱⠀
  3487.867 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠈⢢⠃⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠈⠚⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠘⡄
  2989.600 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⡇
  2491.333 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⢸
  1993.067 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠈
  1494.800 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀
   996.533 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀
   498.267 | ⡇⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀
     0.000 | ⣇⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀⣀
-----------|-|---------|---------|---------|---------|---------|---------|---------|---------|-> (Time (s))
           | 0.000     5.760     11.520    17.280    23.040    28.800    34.560    40.320    46.080

API

The program exposes an API that you can use yourself:

from ffmpeg_bitrate_stats import BitrateStats

ffbs = BitrateStats("path/to/ref")
ffbs.calculate_statistics()
ffbs.print_statistics()

For more usage please read the docs.

Contributors

GabrielChanzy 💻

License

ffmpeg_bitrate_stats, Copyright (c) 2019-2023 Werner Robitza

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
