FixedEffectModel 0.0.5

Solutions to linear model with high dimensional fixed effects.

FixedEffectModel: A Python Package for Linear Model with High Dimensional Fixed Effects.

FixedEffectModel is a Python Package designed and built by Kuaishou DA ecology group. It is used to estimate the class of linear models which handles panel data. Panel data refers to the type of data when time series and cross-sectional data are combined.

Main Features

• Linear model
• Linear model with high dimensional fixed effects
• Difference-in-difference model with parallel checking plot
• Instrumental variable model
• Robust/white standard error
• Multi-way cluster standard error
• Instrumental variable model tests, including weak iv test (cragg-dolnald statistics+stock and yogo critical values), over-identification test (sargan/Basmann test), endogeneity test (durbin test)

For instrumental variable model, we now only provide two stage least square estimator and produce second stage regression result. In our next release we will include GMM method and robust standard error based on GMM.

Installation

Install this package directly from PyPI

$ pip install FixedEffectModel

Getting started

This very simple case-study is designed to get you up-and-running quickly with fixedeffectmodel. We will show the steps needed.

Loading modules and functions

After installing statsmodels and its dependencies, we load a few modules and functions:

import numpy as np
import pandas as pd


from fixedeffect.iv import iv2sls, ivgmm, ivtest
from fixedeffect.fe import fixedeffect, did, getfe
from fixedeffect.utils.panel_dgp import gen_data

gen_data is the function we use to simulate data.

Data

We use a simulated dataset with 100 cross-sectional units and 10 time units.

N = 100
T = 10
beta = [-3,1,2,3,4]
ate = 1
exp_date = 5
df = gen_data(N, T, beta, ate, exp_date)

Ihe the above simulated dataset, "beta" are true coefficients, "ate" is the true treatment effect, "exp_date" is the start date of experiment.

Model fit and summary

Instrumental variables estimation

We include two function: "iv2sls" and "iv2gmm" for instrumental variable regression.

iv2sls

This function return two-stage least square estimation results. Define y as the dependent variable, x_1 as exogenous variable, x_2 as endogenous variable, x_3 and x_4 are instrumental variables. id and time are cross sectional id and time id. An IV two-way fixed effect model estimated by two-stage least square is achieved by using:

formula = 'y ~ x_1|id+time|0|(x_2~x_3+x_4)'
model_iv2sls = iv2sls(data_df = df,
                      formula = formula)
result = model_iv2sls.fit()
result.summary()

or

exog_x = ['x_1']
endog_x = ['x_2']
iv = ['x_3','x_4']
y = ['y']

model_iv2sls = iv2sls(data_df = df,
                      dependent = y,
                      exog_x = exog_x,
                      endog_x = endog_x,
                      category = ['id','time'],
                      iv = iv)

result = model_iv2sls.fit()
result.summary()

The two grammars above yield identical results. We provide specification test for iv models:

ivtest(result1)

Three tests are included: weak iv test (Cragg-Dolnald statistics + Stock and Yogo critical values), over-identification test (Sargan/Basmann test), and endogeneity test (Durbin test).

ivgmm

This function returns one-step gmm estimation result. With same variables definition, estimation is achieved by:

formula = 'y ~ x_1|id+time|0|(x_2~x_3+x_4)'

model_ivgmm = ivgmm(data_df = df,
                    formula = formula)
result = model_ivgmm.fit()
result.summary()

or

exog_x = ['x_1']
endog_x = ['x_2']
iv = ['x_3','x_4']
y = ['y']

model_ivgmm = ivgmm(data_df = df,
                      dependent = y,
                      exog_x = exog_x,
                      endog_x = endog_x,
                      category = ['id','time'],
                      iv = iv)

result = model_ivgmm.fit()
result.summary()

Fixed Effect Model

This function returns fixed effect model estimation result. Define y as the dependent variable, x_1 as independent variable, id and time are cross sectional ID and time ID. Following code yield estimation of a two-way fixed effect model with two-way cluster standard error:

formula = 'y ~ x_1|id+time|id+time|0'

model_fe = fixedeffect(data_df = df,
                       formula = formula,
                       no_print=True)
result = model_fe.fit()
result.summary()

or

exog_x = ['x_1']
y = ['y']
category = ['id','time']
cluster = ['id','time']


model_fe = fixedeffect(data_df = df,
                      dependent = y,
                      exog_x = exog_x,
                      category = category,
                      cluster = cluster)

result = model_fe.fit()
result.summary()

Difference in Difference

DID is simply a specific type of fixed effect model. We provide a function of DID to help simplify the estimation process. The regular DID estimation is achieved using following command:

formula = 'y ~ 0|0|0|0'

model_did = did(data_df = df,
                formula = formula,
                treatment = ['treatment'],
                csid = ['id'],
                tsid = ['time'],
                exp_date = 2)
result = model_did.fit()
result.summary()

"exp_date" is the first date that the experiment begins, "treatment" is the column name of the treatment variable. This command estimate the equation below:

We also provide DID with individual effect:

formula = 'y ~ 0|0|0|0'

model_did = did(data_df = df,
                formula = formula,
                treatment = ['treatment'],
                group_effect='individual',
                csid = ['id'],
                tsid = ['time'],
                exp_date = 2)
result = model_did.fit()
result.summary()

This command above estimate the equation below:

Main Functions

Currently there are five main function you can call:

Function name	Description	Usage
fixedeffect	define class for fixed effect estimation	fixedeffect (data_df = None, dependent = None, exog_x = None, category = None, cluster = None, formula = None, robust = False, noint = False, c_method = 'cgm', psdef = True)
iv2sls	define class for 2sls estimation	iv2sls (data_df = None, dependent = None, exog_x = None, endog_x = None, iv = None, category = None, cluster = None, formula = None, robust = False, noint = False)
ivgmm	define class for gmm estimation	ivgmm (data_df = None, dependent = None, exog_x = None, endog_x = None, iv = None, category = None, cluster = None, formula = None, robust = False, noint = False)
did	define class for did estimation	did (data_df = None, dependent = None, exog_x = None, treatment = None, csid = None, tsid = None, exp_date = None, group_effect = 'treatment', cluster = None, formula = None, robust = False, noint = False, c_method = 'cgm', psdef = True)
model.fit	fit pre-defined models	result = model.fit()
result.summary	result.object	result.summary()
fit_multi_model	fit multiple models	models = [model,model_did,model_iv2sls], fit_multi_model (models)
getfe	get fixed effects	getfe(result)
ivtest	get iv post estimation tests results	ivtest (result)

fixedeffect

Provide results for a fixed effect model:

model = fixedeffect (data_df = None, dependent = None, exog_x = None, category = None, cluster = None, formula = None, robust = False, noint = False, c_method = 'cgm', psdef = True)

Input parameters	Type	Description
data_df	pandas dataframe	Dataframe with relevant data.
dependent	list	List object of dependent variables
exog_x	list	List object of independent variables
category	list, default []	List object of category variables, i.e, fixed effect
cluster	list, default []	List object of cluster variables, i.e, the cluster level of your standard error
formula	string, default None	Formula used to parse grammar.
robust	bool, default False	Whether or not to calculate df-adjusted white standard error (HC1)
noint	bool, default True	Whether or not generate intercept
c_method	str, default 'cgm'	Method to calculate multi-cluster standard error. Possible choices are 'cgm' and 'cgm2'.
psdef	bool, default True	if True, replace negative eigenvalue of variance matrix with 0 (only in multi-way clusters variance)

Return an object of results:

Attribute	Type
params	Estimated coefficients
df	Degree of freedom.
bse	standard error
variance_matrix	coefficients' variance-covariance matrix

iv2sls/ivgmm

model = iv2sls (data_df = None, dependent = None, exog_x = None, endog_x = None, iv = None, category = None, cluster = None, formula = None, robust = False, noint = False)

model = ivgmm (data_df = None, dependent = None, exog_x = None, endog_x = None, iv = None, category = None, cluster = None, formula = None, robust = False, noint = False)

Input parameters	Type	Description
data_df	pandas dataframe	Dataframe with relevant data.
dependent	list	List object of dependent variables
exog_x	list	List object of exogenous variables
endof_x	list	List object of endogenous variables
iv	list	List object of instrumental variables
category	list, default []	List object of category variables, i.e, fixed effect
formula	string, default None	Formula used to parse grammar.
robust	bool, default False	Whether or not to calculate df-adjusted white standard error (HC1)
noint	bool, default True	Whether or not generate intercept

Return the same object of results as fixedeffect does.

We also provide two-step GMM estimator if you set thet option "gmm2=True". Define a matrix

• "ivgmm", the one-step GMM estimator generate with variance-covariance matrices equal

  • Unadjusted. Define , the variance-covariance matrix is
  • Heteroskedasticity robust. Define and , the variance-covariance matrix is
  • Cluster. Deine , the variance-covariance matrix is

• "ivgmm" with "gmm2=True", the two-step GMM estimator generate

  • Unadjusted.
  • Heteroskedasticity robust. Define and as the diagonal matrix generated using the residual from the two-step GMM. , the variance-covariance matrix is
  • Cluster. Define


  , the variance-covariance matrix is .

DID

model = did (data_df = None, dependent = None, exog_x = None, treatment = None, csid = None, tsid = None, exp_date = None, group_effect = 'treatment', cluster = None, formula = None, robust = False, noint = False, c_method = 'cgm', psdef = True)

Input parameters	Type	Description
data_df	pandas dataframe	Dataframe with relevant data.
dependent	list	List object of dependent variables
exog_x	list	List object of independent variables
treatment	list	List object of treatment variables
csid	list	List object of cross sectional id variables
tsid	list	List object of time variables
exp_date	string	Experiment start date
group_effect	string, default 'treatment'	Either equals 'treatment' or 'individual'
cluster	list, default []	List object of cluster variables, i.e, the cluster level of your standard error
formula	string, default None	Formula used to parse grammar.
robust	bool, default False	Whether or not to calculate df-adjusted white standard error (HC1)
noint	bool, default True	Whether or not generate intercept
c_method	str, default 'cgm'	Method to calculate multi-cluster standard error. Possible choices are 'cgm' and 'cgm2'.
psdef	bool, default True	if True, replace negative eigenvalue of variance matrix with 0 (only in multi-way clusters variance)

Return the same object of results as fixedeffect does.

fit_multi_model

This function is used to get multi results of multi models on one dataframe. During analyzing data with large data size and complicated, we usually have several model assumptions. By using this function, we can easily get the results comparison of the different models.

Input parameters	Type	Description
data_df	pandas dataframe	Dataframe with relevant data
models	list, default []	List of models
table_header	str, default None	Title of summary table

Return a summary table of results of the different models.

getfe

This function is used to get fixed effect.

Input parameters	Type	Description
result	object	output object of fixedeffect function
epsilon	double, default 1e-8	tolerance for projection
normalize	bool, default False	Whether or not to normalize fixed effects.
category_input	list, default []	List of category variables to calculate fixed effect.

Return a summary table of estimates of fixed effects and its standard errors.

ivtest

This function is used to obtain iv test result.

Input parameters	Type	Description
result	object	output object of ivgmm/iv2sls function

Return a test result table of iv tests.

Example

# need to install from kuaishou product base
import numpy as np
import pandas as pd
from fixedeffect.iv import iv2sls, ivgmm,ivtest
from fixedeffect.fe import fixedeffect, did,getfe
from fixedeffect.utils.panel_dgp import gen_data
from fixedeffect.iv import ivtest

N = 100
T = 10
beta = [-3,1,2,3,4]
ate = 1
exp_date = 5

#generate sample data
df = gen_data(N, T, beta, ate, exp_date)

#------------------------------#
#define instrumental variable model
# iv2sls
formula = 'y ~ x_1|id+time|0|(x_2~x_3+x_4)'
model_iv2sls = iv2sls(data_df = df,
                      formula = formula)
result = model_iv2sls.fit()
result.summary()

# ivgmm
formula = 'y ~ x_1|id|0|(x_2~x_3+x_4)'

model_ivgmm = ivgmm(data_df = df,
                    formula = formula)
result = model_ivgmm.fit()
result.summary()

# obtain iv test results
ivtest(result)

#------------------------------#

#define fixed effect model
exog_x = ['x_1']
y = ['y']
category = ['id','time']
cluster = ['id','time']


model_fe = fixedeffect(data_df = df,
                      dependent = y,
                      exog_x = exog_x,
                      category = category,
                      cluster = cluster)

result = model_fe.fit()
result.summary()

#obtain fixed effect
getfe(result)

#------------------------------#
#define DID model
formula = 'y ~ 0|0|0|0'

model_did = did(data_df = df,
                formula = formula,
                treatment = ['treatment'],
                csid = ['id'],
                tsid = ['time'],
                exp_date=2)
result = model_did.fit()
result.summary()

Requirements

• Python 3.6+
• Pandas and its dependencies (Numpy, etc.)
• Scipy and its dependencies
• statsmodels and its dependencies
• networkx

Citation

If you use FixedEffectModel in your research, please cite us as follows:

Kuaishou DA Ecology. FixedEffectModel: A Python Package for Linear Model with High Dimensional Fixed Effects.https://github.com/ksecology/FixedEffectModel,2020.Version 0.x

BibTex:

@misc{FixedEffectModel,
  author={Kuaishou DA Ecology},
  title={{FixedEffectModel: {A Python Package for Linear Model with High Dimensional Fixed Effects}},
  howpublished={https://github.com/ksecology/FixedEffectModel},
  note={Version 0.x},
  year={2020}
}

Feedback

This package welcomes feedback. If you have any additional questions or comments, please contact [e-mail].

Reference

[1] Simen Gaure(2019). lfe: Linear Group Fixed Effects. R package. version:v2.8-5.1 URL:https://www.rdocumentation.org/packages/lfe/versions/2.8-5.1

[2] A Colin Cameron and Douglas L Miller. A practitioner’s guide to cluster-robust inference. Journal of human resources, 50(2):317–372, 2015.

[3] Simen Gaure. Ols with multiple high dimensional category variables. Computational Statistics & Data Analysis, 66:8–18, 2013.

[4] Douglas L Miller, A Colin Cameron, and Jonah Gelbach. Robust inference with multi-way clustering. Technical report, Working Paper, 2009.

[5] Jeffrey M Wooldridge. Econometric analysis of cross section and panel data. MIT press, 2010.
