GraphMemory - GraphRAG Database

An embedded graph database for RAG and knowledge graph applications, powered by DuckDB. Vector similarity search, full-text search, hybrid search, merge/upsert, graph traversal, and a full GraphRAG retrieval pipeline — all in a single Python package.

Features

• Vector Search — HNSW-indexed nearest neighbors (L2, cosine, inner product)
• Full-Text Search — BM25-scored search across node properties
• Hybrid Search — Combined vector + text with configurable weights
• GraphRAG — Retrieval pipeline: hybrid search → graph expansion → context assembly → LLM Q&A
• Merge / Upsert — Deduplicate nodes by property keys and edges by (source, target, relation)
• Query Builder — Fluent, parameterized API with multi-hop traversal
• DSPy Extraction — Entity/relationship extraction from text via DSPy (optional)
• Graph Algorithms — PageRank, centrality, components via NetworkX (optional)
• Import / Export — JSON, CSV, GraphML
• Visualizer — Interactive D3.js force-directed graph in the browser
• Thread-Safe — Connection pooling, transactions, automatic retry with exponential backoff

Installation

pip install graphmemory

# Optional
pip install graphmemory[extraction]   # DSPy extraction
pip install graphmemory[algorithms]   # NetworkX algorithms

Quick Start

from graphmemory import GraphMemory, Node, Edge

graph = GraphMemory(database="graph.db", vector_length=3, distance_metric="cosine")

# Insert nodes
alice = Node(type="Person", properties={"name": "Alice", "role": "engineer"}, vector=[0.1, 0.8, 0.3])
bob = Node(type="Person", properties={"name": "Bob", "role": "manager"}, vector=[0.2, 0.7, 0.4])
graph.insert_node(alice)
graph.insert_node(bob)

# Insert edge
graph.insert_edge(Edge(source_id=alice.id, target_id=bob.id, relation="reports_to", weight=1.0))

# Vector search
nearest = graph.nearest_nodes(vector=[0.1, 0.8, 0.3], limit=5)

# Full-text search
results = graph.search_nodes("engineer", limit=10)

# Hybrid search
results = graph.hybrid_search("engineer", query_vector=[0.1, 0.8, 0.3], text_weight=0.5, vector_weight=0.5)

# Context manager
with GraphMemory(database="graph.db", vector_length=3) as graph:
    graph.insert_node(alice)

Usage

Query Builder

# Filter by type and properties
results = graph.query().match(type="Person").where(role="engineer").execute()

# Multi-hop traversal
results = graph.query().traverse(source_id=alice.id, depth=2).execute()

# Paginate and order
results = graph.query().match(type="Person").order_by("name").limit(10).offset(0).execute()

# Query edges
edges = graph.query().match(type="Person").edges().execute()

Merge / Upsert

Insert-or-update nodes matched by property keys. Edges deduplicate on (source_id, target_id, relation).

from graphmemory import MergeStrategy

# Insert if no match, update if "name" matches an existing Person node
result = graph.merge_node(alice, match_keys=["name"])
print(result.created)  # True = inserted, False = updated

# Bulk merge with strategy
results = graph.bulk_merge_nodes(nodes, match_keys=["name"], strategy=MergeStrategy.UPDATE)

# Edge merge
result = graph.merge_edge(edge)
results = graph.bulk_merge_edges(edges)

GraphRAG Retrieval

Full pipeline: hybrid search → multi-hop graph expansion → token-aware context assembly → LLM generation.

# Retrieve context
result = graph.retrieve(query="Who leads ML?", query_vector=embedding, max_hops=2, max_tokens=4000)
print(result.context_text)      # Prompt-ready string
print(result.token_estimate)    # Token count estimate

# End-to-end Q&A
answer = graph.ask(query="Who leads ML?", query_vector=embedding, llm_callable=my_llm)
print(answer["answer"])

DSPy Extraction

Requires pip install graphmemory[extraction]. Uses DSPy typed predictors to extract entities and relationships from text.

from graphmemory.extraction import extract_and_store, extract_and_merge
import dspy

dspy.configure(lm=dspy.LM("openai/gpt-4o-mini"))

text = """George Washington was the first President. Thomas Jefferson
served as Secretary of State under Washington."""

# Extract and insert (may create duplicates on repeated calls)
nodes, edges = extract_and_store(graph, text)

# Extract and merge (deduplicates against existing graph)
node_results, edge_results = extract_and_merge(graph, text, match_keys=["name"])

Graph Algorithms

Requires pip install graphmemory[algorithms]. Powered by NetworkX.

from graphmemory.algorithms import pagerank, betweenness_centrality, connected_components, to_networkx

scores = pagerank(graph)
centrality = betweenness_centrality(graph)
components = connected_components(graph)
G = to_networkx(graph)  # Export to NetworkX DiGraph

Import / Export

# Export
data = graph.export_graph(format="json")       # also: "csv", "graphml", "json_string"

# Import
graph.import_graph(data, format="json")

Visualizer

Interactive D3.js force-directed graph visualization — opens in your browser with zero dependencies.

# Open in browser
graph.visualize()

# Save to file
graph.visualize(output="my_graph.html", open_browser=False)

Features: drag nodes, zoom/pan, hover to highlight connections, click for detail panel, search bar, filter by node type.

Data Models

All IDs are auto-generated UUIDs. All models are Pydantic BaseModel instances.

API Reference

Connection

Nodes

Edges

Search

Retrieval

Traversal

Import / Export

Examples

See examples/ for complete usage:

• openai_example.py — OpenAI embeddings, similarity search, attribute queries
• lexical_graph.py — Wikipedia text with SentenceTransformer embeddings
• dspy_example_typed_pred.py — Knowledge graph extraction with DSPy

Testing

296 tests covering all functionality.

python3 -m pytest tests/tests.py -v

License

MIT License. See LICENSE.

Contributing

Contributions welcome — open an issue or submit a PR.
