gwGenealogy 0.1.0

Binary black hole population phenomenology: remnants, recoil kicks, retention, and hierarchical mergers

gwGenealogy

A Python toolkit for binary black-hole (BBH) phenomenology: sampling BBH populations, computing remnant properties, modeling hierarchical mergers with simple back-of-the-envelope calculations in dense stellar clusters, and analyzing remnant retention across astrophysical environments. For more detailed studies of hierarchical mergers in clusters, we recommend using rapster or other dedicated packages.

This package is a culmination of my works into understanding hierarchical mergers with my amazing collaborators Digvijay Wadekar and Konstantinos Kritos.

Comments/suggestions/criticisms are always welcome!

Package structure

gwGenealogy/
├── utils/      — Distribution samplers, coordinate transforms, conversions, statistics
├── binaries/   — BBH population sampling (masses, spins, redshifts, GWTC models), BBHRemnant
├── stellar/    — Stellar evolution (Fryer12, SEVN), Kroupa IMF, natal kicks
├── hosts/      — Plummer clusters, star cluster sampling, escape velocities, environment retention
├── core/       — Hierarchical mergers, BH seed growth, IMBH formation probability, retention grids

Installation

git clone https://github.com/tousifislam/gwGenealogy.git
cd gwGenealogy
pip install -e .

Dependencies

• numpy, scipy, matplotlib, h5py
• gwModels >= 0.1.6 — remnant mass, spin, and kick models (required; 0.1.6 adds the batched flow.sample/log_prob the kick code relies on)
• surfinBH — NR surrogate remnant models (optional)

Quick start

Sample a BBH population and compute remnants

import numpy as np
from gwGenealogy.binaries import BBHs, BBHRemnant, sample_masses, sample_spins

m1, m2 = sample_masses(5000, m_min=5, m_max=50, m1_distribution='powerlaw', alpha=-2.35, seed=42)
chi1, chi2 = sample_spins(5000, chi_max=1.0, spin_magnitude='beta', spin_angles='isotropic', seed=43)

# sample_spins returns Cartesian spin vectors; BBHs takes magnitudes + angles
bbh = BBHs(m1=m1, m2=m2,
           a1=np.linalg.norm(chi1, axis=1), a2=np.linalg.norm(chi2, axis=1),
           theta1=np.arccos(chi1[:, 2] / np.linalg.norm(chi1, axis=1)),
           theta2=np.arccos(chi2[:, 2] / np.linalg.norm(chi2, axis=1)),
           phi1=np.arctan2(chi1[:, 1], chi1[:, 0]) % (2 * np.pi),
           phi2=np.arctan2(chi2[:, 1], chi2[:, 0]) % (2 * np.pi))
rem = BBHRemnant(bbh=bbh, precessing=True)
# rem.Mf, rem.af, rem.vkick

Hierarchical mergers across generations

from gwGenealogy.core import HierarchicalMergersInClusterPopulation

sim = HierarchicalMergersInClusterPopulation(n_samples=50000, chi_max=0.2, m_min=3, m_max=60,
                                              kick_model='gwmodel', seed=42)
data = sim.simulate(verbose=True)
fig, axes = sim.plot_generations(data)

BH seed growth and IMBH formation

from gwGenealogy.core import MonteCarloBHSeedGrowth

mc = MonteCarloBHSeedGrowth(v_esc=300, Z=0.005, chi_max=0.2, m_seed=10.0,
                             m_targets=[250], kick_model='gwmodel', seed=42)
result = mc.simulate(n_experiments=10000, verbose=True)

Retention probability grids

from gwGenealogy.core import BBHRetentionProbabilityOverChiq
import numpy as np

grid = BBHRetentionProbabilityOverChiq(
    q_values=np.linspace(1, 10, 50),
    chi_max_values=np.linspace(0.01, 1, 50),
    v_esc_values=[50, 100, 200, 500],
    kick_models=['hlz', 'gwmodel'], seed=42)
grid.compute(verbose=True)
fig, axes = grid.plot_heatmap_all_vesc()

GWTC population sampling

The GWTC population files are large (hundreds of MB) and are not bundled with the package; fetch them once from Google Drive (requires pip install gdown):

from gwGenealogy.binaries import download_gwtc_data, sample_gwtc_population, available_catalogs

download_gwtc_data()              # one-time: into ~/.gwGenealogy/data (or $GWGENEALOGY_DATA)

available_catalogs()
pop = sample_gwtc_population(50000, catalog='gwtc5', source='posterior', seed=42)
# pop['mass_1'], pop['a1'], pop['chi_eff'], pop['redshift'], ...

Environment retention

from gwGenealogy.hosts import compute_multi_environment_retention, ENVIRONMENTS

ret = compute_multi_environment_retention(v_kick_array)
# ret['GC'], ret['NSC'], ret['EG'], ret['DG'], ret['MW'], ret['M31']

Tutorials

#	Notebook	Description
01	Distributions	Core distribution samplers and JSD
02	Stellar evolution	Kroupa IMF, Fryer12/SEVN remnants, natal kicks
03	BBH nonprecessing	BBHs + BBHRemnant with nonprecessing models
04	BBH precessing	BBHs + BBHRemnant with precessing and surrogate models
05	GWTC populations	GWTC-3/4/5 population sampling, posterior vs prior
06	Retention probability	1G+1G retention heatmaps across kick models
07	Host environments	Plummer clusters, escape velocities, environment retention
08	Hierarchical mergers	Multi-generation mergers, pairing models, evolving v_esc
09	Seed growth	BH seed growth chains, v_esc sweeps, evolving v_esc
10	Displacement & return times	Apocentre displacement, dynamical friction return times, GC vs NSC
11	Single-cluster mergers	Hierarchical mergers in one cluster: mass/Z/pairing sweeps, evolving v_esc
12	Runaway SMBH progenitor	Inferring the progenitor of recoiling SMBH RBH-1 from its kick (flow log_prob inversion)

Citations

If you use this package, please cite the relevant papers:

@article{Islam:2025drw,
    author = "Islam, Tousif and Wadekar, Digvijay",
    title = "{Accurate models for recoil velocity distribution in black hole
              mergers with comparable to extreme mass-ratios and their
              astrophysical implications}",
    eprint = "2511.11536",
    archivePrefix = "arXiv",
    primaryClass = "gr-qc",
    doi = "10.1103/4jvv-qg4h",
    journal = "Phys. Rev. D",
    volume = "113",
    number = "10",
    pages = "104017",
    year = "2026"
}

@article{Islam:2026yxx,
    author = "Islam, Tousif and Wadekar, Digvijay and Kritos, Konstantinos",
    title = "{Kick matters: The impact of a new recoil model on the retention
              of hierarchical black-hole remnants in globular clusters}",
    eprint = "2603.10170",
    archivePrefix = "arXiv",
    primaryClass = "astro-ph.HE",
    month = "3",
    year = "2026"
}

@article{Islam:2026iyn,
    author = "Islam, Tousif",
    title = "{Inference of recoil kicks from binary black hole mergers up to
              GWTC--4 and their astrophysical implications}",
    eprint = "2604.04546",
    archivePrefix = "arXiv",
    primaryClass = "astro-ph.HE",
    month = "4",
    year = "2026"
}

@article{Islam:2026sjl,
    author = "Islam, Tousif and Venumadhav, Tejaswi and Wadekar, Digvijay",
    title = "{Progenitor of the recoiling super-massive black hole RBH-1
              identified using HST/JWST imaging}",
    eprint = "2601.18986",
    archivePrefix = "arXiv",
    primaryClass = "astro-ph.HE",
    month = "1",
    year = "2026"
}

Contact

For questions or issues, please reach out to [e-mail].

License

MIT
