InterOptimus 0.1.0

High throughput simulation for crystalline interfaces

InterOptimus

Crystal interface search and optimization with MLIP acceleration, optional VASP, and Jobflow / jobflow-remote execution.

This distribution focuses on the JSON-driven IOMaker pipeline (submit → lattice match → MLIP → optional DFT → reports and fetch tooling).

Highlights

• Lattice matching, termination screening, single / double interface builds
• MLIP global minimization; optional VASP (cluster workers)
• One-shot config: interoptimus-simple -c your.yaml or run_simple_iomaker(...)
• Outputs include io_flow.json, io_report.txt, pairs_summary.txt, opt_results.pkl (use iomaker_fetch_results / remote_submit helpers after server submit)

Installation

From PyPI (after publish):

# Core only (lattice match, jobflow, interface pipeline). MLIP calculators need the extra:
pip install "InterOptimus[mlip]"         # torch + orb-models + sevenn + deepmd-kit

# Common combinations:
pip install "InterOptimus[mlip,web,yaml]"   # MLIP backends + browser UI + YAML configs
pip install InterOptimus                    # minimal deps; add [mlip] before running MLIP steps

From a git checkout:

pip install -e .

See GETTING_STARTED for first-time server setup (MongoDB, jobflow-remote, POTCAR, MLIP checkpoints). Links use HEAD so they stay valid on the PyPI project description and on GitHub.

Quick start (recommended)

# 1) Copy and edit paths / cluster / workers
cp InterOptimus/agents/simple_iomaker.example.json my_run.json
vim my_run.json

# 2) On the login node, after JOBFLOW / JFREMOTE / conda are configured:
interoptimus-simple -c my_run.json

Python API:

from pathlib import Path
import json
from InterOptimus.agents.simple_iomaker import (
    run_simple_iomaker,
    iomaker_status,
    iomaker_fetch_results,
)

with open("my_run.json") as f:
    result = run_simple_iomaker(json.load(f))

print(iomaker_status(result))
# When finished:
# iomaker_fetch_results(result, copy_images_to=Path("./out"))

Lower-level builder (already-normalized settings dict):

from InterOptimus.agents.iomaker_job import (
    LocalBuildConfig,
    execute_iomaker_from_settings,
    normalize_iomaker_settings_from_full_dict,
)

Full parameter reference: simple_iomaker_parameters.

Optional: browser GUI (local runs)

pip install -e '.[web]'
interoptimus-web

The web UI drives the same run_simple_iomaker pipeline as the CLI; session directories default to ~/.interoptimus/web_sessions/ (override with INTEROPTIMUS_DESKTOP_SESSIONS or INTEROPTIMUS_WEB_SESSIONS). Optional relaxation telemetry uses INTEROPTIMUS_VIZ_LOG + INTEROPTIMUS_VIZ_ENABLE (see InterOptimus.viz_runtime).

Requirements

• Python ≥ 3.10
• Core stack: pymatgen, interfacemaster, atomate2, jobflow, jobflow-remote, qtoolkit, … (see setup.py)
• MLIP stack (optional): install InterOptimus[mlip] for torch, orb-models, sevenn, and deepmd-kit, or install those packages into your environment manually. MatRIS is not on PyPI; install from the upstream project if you use calc=matris.

Layout

InterOptimus/
├── itworker.py       # InterfaceWorker (physics + optimization)
├── matching.py       # Lattice matching & screening
├── jobflow.py        # IOMaker + Jobflow makers
├── mlip.py           # MLIP calculators + checkpoint resolution
├── agents/
│   ├── simple_iomaker.py   # CLI + run_simple_iomaker / status / fetch / rerun helpers
│   ├── iomaker_job.py      # BuildConfig + execute_iomaker_from_settings
│   ├── remote_submit.py    # submit_io_flow_locally, progress, fetch
│   └── server_env.py       # interoptimus-env
├── web_app/                # FastAPI UI + job_worker (interoptimus-web)
├── session_workflow.py     # web session driver (form → run_simple_iomaker)
├── result_bundle.py        # curated result/ artifact folder
└── docs/

License

MIT — see LICENSE.
