JAX Solar: Top of atmosphere incident solar radiation, in JAX

Authors: Peter Norgaard and Stephan Hoyer

JAX Solar is a JAX implementation of top of atmosphere incident solar radiation (TISR), for use in weather and climate models. It was originally written for NeuralGCM.

This code uses simple formulas inspired by pysolar, but unlike pysolar it does not include atmospheric scattering effects. Of particular note, the constants used to compute solar irradiance are different.

Typical usage

import jax_solar
import jax_datetime as jdt

# near sunset in San Francisco
time = jdt.to_datetime('2024-12-28T00:30')
lat = 37.7749
lon = -122.4194
relative_flux = jax_solar.normalized_radiation_flux(time, lon, lat)
print(relative_flux)  # 0.07284241

How accurate is it?

JAX Solar is accurate to within about 0.5% of TISR values in ERA5:

import xarray
import jax_solar
import jax_datetime as jdt

time = '20231230T22'

ds = xarray.open_zarr(
    'gs://gcp-public-data-arco-era5/ar/full_37-1h-0p25deg-chunk-1.zarr-v3',
    chunks=None,
    storage_options=dict(token='anon'),
)
tisr_era5 = ds.toa_incident_solar_radiation.sel(time=time).compute()

# TISR in ERA5 is integrated over the previous hour, whereas JAX Solar
# provides instantaneous values.
lats, lons = xarray.broadcast(tisr_era5.latitude, tisr_era5.longitude)
dt = 5*60  # in seconds
times = jdt.to_datetime(time) - jnp.arange(0, 60*60//dt + 1) * jdt.Timedelta(seconds=dt)
flux = jnp.trapezoid(
    jax.vmap(lambda t: jax_solar.radiation_flux(t, lons.data, lats.data))(times),
    axis=0,
    dx=dt,
)
tisr_jax_solar = tisr_era5.copy(data=flux)

# first plot: reference TISR from ERA5
tisr_era5.plot(size=3, aspect=2)

# second plot: relative error
relative_error = (tisr_jax_solar - tisr_era5) / tisr_era5.max()
relative_error.rename('Relative error').plot(size=3, aspect=2)

If 0.5% accuracy is not good enough for you, you could consider using the solar radiation code from GraphCast, which nearly exactly matches ERA5.
