pgmpy 1.1.2

Python Toolkit for Causal and Probabilistic Reasoning

pgmpy provides the building blocks for causal and probabilistic reasoning using graphical models. It implements data structures for a range of causal and graphical models such as DAGs, PDAGs, MAGs, PAGs, Bayesian Networks, Dynamic Bayesian Networks, and Structural Equation Models, along with algorithms for various tasks such as causal discovery, causal identification, causal and probabilistic inference, model validation, parameter estimation, simulations, and more.

Algorithms for each task follow a unified composable API, making them modular and extensible. They are also scikit-learn compatible when possible. They can be used directly, combined in sklearn pipelines, or used to build higher-level tools on top of them.

	Documentation · Examples . Tutorials
Open Source
Tutorials
Community
CI/CD
Code
Downloads
Supported By

Key Features

Feature	Description
Causal Discovery / Structure Learning	Learn the model structure from data, with optional integration of expert knowledge.
Causal Validation	Assess how compatible the causal structure is with the data.
Parameter Learning	Estimate model parameters (e.g., conditional probability distributions) from observed data.
Probabilistic Inference	Compute posterior distributions conditioned on observed evidence.
Causal Inference	Compute interventional and counterfactual distributions using do-calculus.
Simulations	Generate synthetic data under specified evidence or interventions.
Example Datasets and Models	Collection of datasets and models from various sources.
Plotting	Flexible plotting functionality.

Resources and Links

• Example Notebooks: Examples
• Tutorial Notebooks: Tutorials
• Blog Posts: Medium
• Documentation: Website
• Bug Reports and Feature Requests: GitHub Issues
• Questions: discord · Stack Overflow

Quickstart

Installation

pgmpy is available on both PyPI and anaconda. To install from PyPI, use:

pip install pgmpy

To install from conda-forge, use:

conda install conda-forge::pgmpy

Examples

Discrete Data

from pgmpy.example_models import load_model

# Load a Discrete Bayesian Network and simulate data.
discrete_bn = load_model("bnlearn/alarm")
alarm_df = discrete_bn.simulate(n_samples=100)

# Learn a network from simulated data.
from pgmpy.estimators import PC

dag = PC(data=alarm_df).estimate(ci_test="chi_square", return_type="dag")

# Learn the parameters from the data.
from pgmpy.models import DiscreteBayesianNetwork

discrete_bn = DiscreteBayesianNetwork(dag.edges())
discrete_bn.add_nodes_from(dag.nodes())
dag_fitted = discrete_bn.fit(alarm_df)
dag_fitted.get_cpds()

# Drop a column and predict using the learned model.
evidence_df = alarm_df.drop(columns=["FIO2"], axis=1)
pred_FIO2 = dag_fitted.predict(evidence_df)

Linear Gaussian Data

from pgmpy.example_models import load_model

# Load an example Gaussian Bayesian Network and simulate data
gaussian_bn = load_model("bnlearn/ecoli70")
ecoli_df = gaussian_bn.simulate(n_samples=100)

# Learn the network from simulated data.
from pgmpy.estimators import PC

dag = PC(data=ecoli_df).estimate(ci_test="pearsonr", return_type="dag")

# Learn the parameters from the data.
from pgmpy.models import LinearGaussianBayesianNetwork

gaussian_bn = LinearGaussianBayesianNetwork(dag.edges())
dag_fitted = gaussian_bn.fit(ecoli_df)
dag_fitted.get_cpds()

# Drop a column and predict using the learned model.
evidence_df = ecoli_df.drop(columns=["ftsJ"], axis=1)
pred_ftsJ = dag_fitted.predict(evidence_df)

Mixture Data with Arbitrary Relationships

from pgmpy.global_vars import config

config.set_backend("torch")

import pyro.distributions as dist

from pgmpy.models import FunctionalBayesianNetwork
from pgmpy.factors.hybrid import FunctionalCPD

# Create a Bayesian Network with mixture of discrete and continuous variables.
func_bn = FunctionalBayesianNetwork(
    [
        ("x1", "w"),
        ("x2", "w"),
        ("x1", "y"),
        ("x2", "y"),
        ("w", "y"),
        ("y", "z"),
        ("w", "z"),
        ("y", "c"),
        ("w", "c"),
    ]
)

# Define the Functional CPDs for each node and add them to the model.
cpd_x1 = FunctionalCPD("x1", fn=lambda _: dist.Normal(0.0, 1.0))
cpd_x2 = FunctionalCPD("x2", fn=lambda _: dist.Normal(0.5, 1.2))

# Continuous mediator: w = 0.7*x1 - 0.3*x2 + ε
cpd_w = FunctionalCPD(
    "w",
    fn=lambda parents: dist.Normal(0.7 * parents["x1"] - 0.3 * parents["x2"], 0.5),
    parents=["x1", "x2"],
)

# Bernoulli target with logistic link: y ~ Bernoulli(sigmoid(-0.7 + 1.5*x1 + 0.8*x2 + 1.2*w))
cpd_y = FunctionalCPD(
    "y",
    fn=lambda parents: dist.Bernoulli(
        logits=(-0.7 + 1.5 * parents["x1"] + 0.8 * parents["x2"] + 1.2 * parents["w"])
    ),
    parents=["x1", "x2", "w"],
)

# Downstream Bernoulli influenced by y and w
cpd_z = FunctionalCPD(
    "z",
    fn=lambda parents: dist.Bernoulli(
        logits=(-1.2 + 0.8 * parents["y"] + 0.2 * parents["w"])
    ),
    parents=["y", "w"],
)

# Continuous outcome depending on y and w: c = 0.2 + 0.5*y + 0.3*w + ε
cpd_c = FunctionalCPD(
    "c",
    fn=lambda parents: dist.Normal(0.2 + 0.5 * parents["y"] + 0.3 * parents["w"], 0.7),
    parents=["y", "w"],
)

func_bn.add_cpds(cpd_x1, cpd_x2, cpd_w, cpd_y, cpd_z, cpd_c)
func_bn.check_model()

# Simulate data from the model
df_func = func_bn.simulate(n_samples=1000, seed=123)

# For learning and inference in Functional Bayesian Networks, please refer to the example notebook: https://github.com/pgmpy/pgmpy/blob/dev/examples/Functional_Bayesian_Network_Tutorial.ipynb

Contributing

We welcome all contributions --not just code-- to pgmpy. Please refer out contributing guide for more details. We also offer mentorship for new contributors and maintain a list of potential mentored projects. If you are interested in contributing to pgmpy, please join our discord server and introduce yourself. We will be happy to help you get started.
