PkTree A Python package for incorporating prior domain knowledge into tree-based models

PkTree is a Python package that enables the integration of prior knowledge into Decision Trees (DT) and Random Forests (RF). By prioritizing relevant features, this package enhances interpretability and aligns predictive models with prior insights.

The enhancements in PkTree build upon the scikit-learn library.

---

Features

1. Prior-Informed Decision Trees

We introduce two key modifications to the traditional Decision Tree algorithm to prioritize relevant features during tree construction:

• Feature Sampling: Weighted feature sampling during training. A hyperparameter k controls the influence of prior knowledge score w_prior on sampling.
• Impurity Improvement: Adjusting impurity calculations based on prior knowledge scores. An additional hyperparameter v controls the strength of the prior knowledge score's (w_prior) impact.

The modified models include a parameter pk_configuration, which can take the following values:

• 'no_gis': Standard tree without knowledge.
• 'on_feature_sampling': Applies prior knowledge-informed feature sampling.
• 'on_impurity_improvement': Incorporates prior knowledge scores in impurity computations.
• 'all': Combines both feature sampling and impurity improvement.

2. Prior-Informed Random Forest

The modificationsabove can be seamlessly extended to the Random Forest model, which functions as an ensemble of Decision Trees. We also introduces an additional modification for Random Forests which leverages the Out-of-Bag (OOB) samples. This modification is activated with parameters oob_score=True and on_oob=True.

Out-of-Bag (OOB) Weights

This approach leverages Out-of-Bag predictions for weighting individual estimators in the Random Forest ensemble:

• For each tree, calculate:
  • f_score: Accuracy on OOB samples.
  • s_prior: Average prior-knowledge relevance of selected features.
• Compute weights for each tree based on these scores and normalize them.
• A hyperparameter r increases the weight differences across trees, enhancing the influence of prior-knowledge scores.

Weighted Voting

During prediction Tree predictions are weighted based on their normalized scores and aggregated.

Prior-knowledge Score

The prior knowledge score w_prior is assumed to be in the range [0,1], where higher values indicate greater relevance based on the prior knowledge considered. If the w_priorscore does not fall within this range, it is first normalized. Then, the score is transformed using a predefined function (pk_function) to obtain a reversed interpretation, where higher values indicate lower relevance. Check here for the different implemented forms of the pk_function.

---

Getting Started

Installation

Install the package via pip:

pip install pktree

Example Usage

Here’s how to use PkTree packageto build and train prior-knowledge informed Decision Tree or Random Forest models:

Toy Dataset

Build a toy dataset and generate prior knowledge score w_prior.

import numpy as np
import pandas as pd
from sklearn.datasets import make_classification, make_regression

# Generate w_prior
def assign_feature_scores(n_features = 50):
    scores = np.round(np.random.uniform(0.01, 0.99, size=n_features), 5)
    return scores

# Generate toy dataset
def generate_dataset(task_type, n_samples = 100, n_features = 50, noise_level = 0.1):

    if task_type == 'classification':
        X, y = make_classification(
            n_samples=n_samples,
            n_features=n_features,
            n_informative=int(n_features * 0.7),
            n_redundant=int(n_features * 0.2),
            n_classes=2,
            random_state=42
        )

        X += np.random.normal(0, noise_level, X.shape)

    elif task_type == 'regression':
        X, y = make_regression(
            n_samples=n_samples,
            n_features=n_features,
            noise=noise_level,
            random_state=42
        )
    return X, y


w_prior = assign_feature_scores()
X_classification, y_classification = generate_dataset('classification')
X_regression, y_regression = generate_dataset('regression')


Decision Trees

Build a Decision Tree classifier:

from pktree import tree

X_train, X_test, y_train, y_test = train_test_split(X_classification, y_classfication, test_size=0.2, random_state=42)

model = tree.DecisionTreeClassifier(random_state=42, pk_configuration='all', w_prior=w_prior, k=2, v=0.5, pk_function='reciprocal')

model.fit(X_train, y_train)
predictions = model.predict(X_test)

Build a Decision Tree regressor:

X_train, X_test, y_train, y_test = train_test_split(X_regression, y_regression, test_size=0.2, random_state=42)

model = tree.DecisionTreeRegressor(random_state=42, pk_configuration='on_impurity_improvement', w_prior=w_prior, k=2, v=0.5,pk_function='reciprocal')

model.fit(X_train, y_train)
predictions = model.predict(X_test)

Random Forest

Build a Random Forest classifier:

from pktree import ensemble


X_train, X_test, y_train, y_test = train_test_split(X_classification, y_classfication, test_size=0.2, random_state=42)

forest = ensemble.RandomForestClassifier(random_state=42, pk_configuration='on_feature_sampling', oob_score=True, on_oob=True, w_prior=w_prior, r=3)

forest.fit(X_train, y_train)
predictions = forest.predict(X_test)

Build a Random Forest Regressor:

#
X_train, X_test, y_train, y_test = train_test_split(X_regression, y_regression, test_size=0.2, random_state=42)

forest = ensemble.RandomForestRegressor(random_state=42, pk_configuration='on_impurity_improvement', w_prior=w_prior)

forest.fit(X_train, y_train)
predictions = forest.predict(X_test)

---

Compatibility

• Built on top of scikit-learn.
• Compatible with both classification and regression tasks.

---

License

This package is open-source and distributed under the MIT License.
