pyGWRetrieval

A Python package for retrieving and analyzing USGS groundwater level data.

Overview

pyGWRetrieval simplifies the process of downloading daily groundwater level data from the USGS National Water Information System (NWIS). It supports various spatial inputs including:

• Zip codes with customizable buffer distances
• GeoJSON files for custom areas of interest
• Shapefiles including state boundaries or groundwater basins
• Point vectors with buffer capabilities
• Polygon features for direct spatial queries

Features

• 🌍 Flexible Spatial Inputs: Query by zip code, GeoJSON, shapefile, or specific site numbers
• � Multiple Data Sources: Retrieve from gwlevels, daily values, or instantaneous values
• 📊 Temporal Aggregation: Aggregate data to monthly, annual, growing season, or custom periods
• 📈 Visualization: Built-in plotting for time series analysis
• 💾 Multiple Export Formats: Save data as CSV or Parquet files
• 🔧 Trend Analysis: Calculate linear trends for water level changes
• ⚡ Parallel Processing: Dask-powered parallel processing for large datasets

USGS Data Sources

pyGWRetrieval supports three USGS NWIS data sources for groundwater levels:

Source	Description	Typical Use Case
gwlevels	Field groundwater-level measurements - Discrete manual measurements taken during field visits. Most accurate but infrequent.	Long-term trend analysis, calibration
dv	Daily values - Daily statistical summaries (mean, min, max) computed from continuous sensors.	Regular monitoring, daily patterns
iv	Instantaneous values - Current/historical observations at 15-60 minute intervals from continuous sensors.	High-resolution analysis, recent conditions

Selecting Data Sources

from pyGWRetrieval import GroundwaterRetrieval

# Default: gwlevels only (backward compatible)
gw = GroundwaterRetrieval(start_date='2020-01-01')
data = gw.get_data_by_zipcode('89701', buffer_miles=10)

# All available sources
gw_all = GroundwaterRetrieval(
    start_date='2020-01-01',
    data_sources='all'  # gwlevels + dv + iv
)

# Specific sources
gw_daily = GroundwaterRetrieval(
    start_date='2020-01-01',
    data_sources=['gwlevels', 'dv']  # Field measurements + daily values
)

# Single source
gw_instant = GroundwaterRetrieval(
    start_date='2020-01-01',
    data_sources='iv'  # Instantaneous values only
)

The output data includes a data_source column to identify which source each record came from.

Note on Data Aggregation: All three data types (gwlevels, dv, iv) are stored as-is after download without any aggregation or transformation. Daily values (dv) are pre-computed by USGS, and instantaneous values (iv) retain their original high-frequency resolution (typically 15-60 minute intervals). If you need to aggregate iv data to daily or other frequencies, use the TemporalAggregator class from the temporal module.

Installation

Using pip

pip install pyGWRetrieval

From source

git clone https://github.com/montimaj/pyGWRetrieval.git
cd pyGWRetrieval
pip install -e .

With optional dependencies

# For enhanced visualization
pip install pyGWRetrieval[viz]

# For distributed computing (multi-node parallelism)
pip install pyGWRetrieval[distributed]

# For development
pip install pyGWRetrieval[dev]

# For documentation
pip install pyGWRetrieval[docs]

# All optional dependencies
pip install pyGWRetrieval[all]

Project Structure

pyGWRetrieval/
├── pyGWRetrieval/           # Main package
│   ├── __init__.py          # Package initialization and exports
│   ├── retrieval.py         # Core GroundwaterRetrieval class
│   ├── spatial.py           # Spatial utilities (zip codes, geometries, buffers)
│   ├── temporal.py          # Temporal aggregation and trend analysis
│   ├── visualization.py     # Plotting and visualization tools
│   ├── parallel.py          # Dask-based parallel processing
│   ├── cli.py               # Command-line interface
│   └── utils.py             # Helper functions and utilities
├── docs/                    # Documentation (Sphinx)
│   ├── index.md             # Documentation home
│   ├── quickstart.md        # Getting started guide
│   ├── api_reference.md     # API documentation
│   └── cli.md               # CLI documentation
├── examples/                # Example scripts
│   ├── basic_usage.py       # Simple usage examples
│   ├── full_workflow_csv_zipcodes.py  # Complete workflow
│   ├── multi_source_example.py        # Multi-source retrieval
│   ├── temporal_analysis.py           # Temporal aggregation
│   └── advanced_spatial.py            # Spatial queries
├── tests/                   # Unit tests
├── pyproject.toml           # Package configuration
├── setup.py                 # Setup script
├── requirements.txt         # Dependencies
├── LICENSE                  # MIT License
└── README.md                # This file

Quick Start

Basic Usage

from pyGWRetrieval import GroundwaterRetrieval

# Initialize with date range
gw = GroundwaterRetrieval(
    start_date='2010-01-01',
    end_date='2023-12-31'
)

# Get data by zip code with 10-mile buffer
data = gw.get_data_by_zipcode('89701', buffer_miles=10)

# Save to CSV
gw.to_csv('groundwater_data.csv')

Using Multiple Zip Codes from CSV

from pyGWRetrieval import GroundwaterRetrieval

gw = GroundwaterRetrieval()

# Read zip codes from CSV file - parallel processing is enabled by default
data = gw.get_data_by_zipcodes_csv(
    'locations.csv',
    zipcode_column='zip',  # Name of column with zip codes
    buffer_miles=10,
    parallel=True,         # Enable parallel processing (default)
    n_workers=4            # Optional: specify number of workers
)

# Results include 'source_zipcode' column to track origin
print(data['source_zipcode'].value_counts())

# Save data to separate files per zip code
saved_files = gw.save_data_per_zipcode('output_by_zipcode/', file_format='csv')
for zipcode, filepath in saved_files.items():
    print(f"Saved {zipcode} to {filepath}")

Using Shapefiles

from pyGWRetrieval import GroundwaterRetrieval

gw = GroundwaterRetrieval()

# Get data within a polygon (e.g., basin boundary)
data = gw.get_data_by_shapefile('my_basin.shp')

# For point shapefiles, specify a buffer
data = gw.get_data_by_shapefile('well_locations.shp', buffer_miles=5)

Using GeoJSON

from pyGWRetrieval import GroundwaterRetrieval

gw = GroundwaterRetrieval(start_date='2020-01-01')

# Get data within GeoJSON polygons
data = gw.get_data_by_geojson('study_area.geojson')

# Save as Parquet
gw.to_parquet('groundwater_data.parquet')

Temporal Aggregation

from pyGWRetrieval import GroundwaterRetrieval, TemporalAggregator

# Get raw data
gw = GroundwaterRetrieval()
data = gw.get_data_by_zipcode('89701', buffer_miles=20)

# Aggregate temporally
aggregator = TemporalAggregator(data)

# Monthly means
monthly = aggregator.to_monthly(agg_func='mean')

# Annual medians
annual = aggregator.to_annual(agg_func='median')

# Growing season (April-September)
growing = aggregator.to_growing_season(start_month=4, end_month=9)

# Water year
water_year = aggregator.to_annual(water_year=True)

# Custom period (e.g., summer months)
summer = aggregator.to_custom_period(months=[6, 7, 8], period_name='summer')

Visualization

from pyGWRetrieval import GroundwaterRetrieval, GroundwaterPlotter
import matplotlib.pyplot as plt

# Get data
gw = GroundwaterRetrieval()
data = gw.get_data_by_zipcode('89701', buffer_miles=15)

# Create plotter
plotter = GroundwaterPlotter(data)

# Time series for all wells
fig = plotter.plot_time_series()
plt.savefig('time_series.png')

# Single well detailed plot
fig = plotter.plot_single_well('390000119000001')
plt.savefig('single_well.png')

# Monthly boxplot
fig = plotter.plot_monthly_boxplot()
plt.savefig('monthly_boxplot.png')

# Annual summary
fig = plotter.plot_annual_summary()
plt.savefig('annual_summary.png')

Spatial Map Visualization

Create maps showing wells colored by water level with automatic zoom:

from pyGWRetrieval import GroundwaterRetrieval, plot_wells_map, create_comparison_map
import matplotlib.pyplot as plt

# Get data from multiple zip codes
gw = GroundwaterRetrieval()
data = gw.get_data_by_zipcodes_csv('locations.csv', zipcode_column='zip', buffer_miles=20)

# Create a spatial map with auto-zoom
# - Local extent (<20 mi): detailed zoom
# - Regional extent (<100 mi): wider view
# - State extent (<500 mi): state-level view
# - National extent (>1500 mi): continental view
fig = plot_wells_map(
    data,
    agg_func='mean',  # Show mean water level per well
    title='Groundwater Wells (ft below surface)',
    cmap='RdYlBu_r',  # Red=deep water, Blue=shallow
    add_basemap=True,  # Add OpenStreetMap-style basemap
    group_by_column='source_zipcode'  # Label by zip code
)
plt.savefig('wells_map.png', dpi=300)

# Create a 4-panel comparison map (mean, min, max, record count)
fig = create_comparison_map(data, figsize=(18, 12))
plt.savefig('comparison_map.png', dpi=300)

Parallel Processing

pyGWRetrieval uses Dask for parallel processing of large datasets:

from pyGWRetrieval import GroundwaterRetrieval, check_dask_available, get_parallel_config

# Check if parallel processing is available
print(f"Dask available: {check_dask_available()}")
print(f"Config: {get_parallel_config()}")

# Parallel processing is enabled by default for multi-zipcode queries
gw = GroundwaterRetrieval(start_date='1970-01-01')
data = gw.get_data_by_zipcodes_csv(
    'locations.csv',
    zipcode_column='zip',
    parallel=True,           # Default
    n_workers=4,             # Number of parallel workers
    scheduler='threads'      # 'threads', 'processes', or 'synchronous'
)

# For distributed computing across multiple machines
from pyGWRetrieval import get_dask_client

client = get_dask_client(n_workers=8)  # Creates local cluster
# Dashboard available at client.dashboard_link

Command Line Interface (CLI)

pyGWRetrieval provides a full-featured CLI for all operations.

Installation

After installing the package, the pygwretrieval command is available:

pygwretrieval --help

Retrieve Data

# By zip code with buffer (default: gwlevels only)
pygwretrieval retrieve --zipcode 89701 --buffer 10 --output data.csv

# Retrieve from all USGS data sources (gwlevels, dv, iv)
pygwretrieval retrieve --zipcode 89701 --buffer 10 --data-sources all --output data.csv

# Retrieve from specific sources
pygwretrieval retrieve --zipcode 89701 --data-sources gwlevels dv --output data.csv

# From CSV file with multiple zip codes (parallel processing)
pygwretrieval retrieve --csv locations.csv --zipcode-column zip --parallel --output data.csv

# Multi-source retrieval from CSV
pygwretrieval retrieve --csv locations.csv --zipcode-column zip --data-sources all --parallel --output data.csv

# Save separate files per zip code
pygwretrieval retrieve --csv locations.csv --zipcode-column zip --save-per-zipcode --per-zipcode-dir output/

# From shapefile
pygwretrieval retrieve --shapefile basin.shp --buffer 5 --output basin_data.csv

# From GeoJSON
pygwretrieval retrieve --geojson study_area.geojson --output area_data.csv

# By state
pygwretrieval retrieve --state NV --output nevada_data.csv

# Specific sites
pygwretrieval retrieve --sites 390000119000001 390000119000002 --output sites_data.csv

# With date range
pygwretrieval retrieve --zipcode 89701 --start-date 2010-01-01 --end-date 2023-12-31 --output data.csv

# Save well locations as GeoJSON
pygwretrieval retrieve --zipcode 89701 --buffer 15 --output data.csv --wells-output wells.geojson

Aggregate Data

# Monthly aggregation
pygwretrieval aggregate --input data.csv --period monthly --output monthly.csv

# Annual aggregation
pygwretrieval aggregate --input data.csv --period annual --agg-func mean --output annual.csv

# Water year aggregation
pygwretrieval aggregate --input data.csv --period water-year --output water_year.csv

# Growing season (April-September)
pygwretrieval aggregate --input data.csv --period growing-season --start-month 4 --end-month 9 --output growing.csv

# Custom period with median
pygwretrieval aggregate --input data.csv --period custom --start-month 6 --end-month 8 --agg-func median --output summer.csv

Calculate Statistics and Trends

# Both statistics and trends
pygwretrieval stats --input data.csv --output analysis

# Statistics only
pygwretrieval stats --input data.csv --output stats --type statistics

# Trends with parallel processing
pygwretrieval stats --input data.csv --output trends --type trends --parallel

Create Visualizations

# Time series plot
pygwretrieval plot --input data.csv --type timeseries --output timeseries.png

# Single well detailed plot with trend
pygwretrieval plot --input data.csv --type single-well --wells 390000119000001 --show-trend --output well.png

# Monthly boxplot
pygwretrieval plot --input data.csv --type boxplot --output boxplot.png

# Annual summary
pygwretrieval plot --input data.csv --type annual --output annual.png

# Custom figure size and DPI
pygwretrieval plot --input data.csv --type timeseries --figsize 14 10 --dpi 300 --output plot.png

Create Spatial Maps

# Basic map with basemap
pygwretrieval map --input data.csv --output wells_map.png --basemap

# Map with custom colormap and grouping
pygwretrieval map --input data.csv --output map.png --basemap --cmap viridis --group-by source_zipcode

# Different basemap provider
pygwretrieval map --input data.csv --output map.png --basemap --basemap-source Esri.WorldImagery

# Comparison map (4 panels: mean, count, min, max)
pygwretrieval map --input data.csv --output comparison.png --comparison --basemap

Get Data Information

# Basic info
pygwretrieval info --input data.csv

# Detailed statistics
pygwretrieval info --input data.csv --detailed

Global Options

# Verbose output
pygwretrieval -v retrieve --zipcode 89701 --output data.csv

# Quiet mode (errors only)
pygwretrieval -q retrieve --zipcode 89701 --output data.csv

# Version
pygwretrieval --version

API Reference

Core Classes

GroundwaterRetrieval

Main class for data retrieval from USGS NWIS.

GroundwaterRetrieval(start_date='1900-01-01', end_date=None, data_sources='gwlevels')

Parameters:

• start_date (str): Start date in 'YYYY-MM-DD' format (default: '1900-01-01')
• end_date (str): End date (default: today)
• data_sources (str | List): Data sources to retrieve:
  • 'gwlevels' (default): Field measurements
  • 'dv': Daily values
  • 'iv': Instantaneous values
  • 'all': All sources
  • ['gwlevels', 'dv']: List of specific sources

Methods:

• get_data_by_zipcode(zipcode, buffer_miles, country) - Query by zip code
• get_data_by_zipcodes_csv(filepath, zipcode_column, buffer_miles) - Query multiple zip codes from CSV
• get_data_by_geojson(filepath, buffer_miles, layer) - Query using GeoJSON
• get_data_by_shapefile(filepath, buffer_miles) - Query using shapefile
• get_data_by_state(state_code) - Query entire state
• get_data_by_sites(site_numbers) - Query specific sites
• to_csv(filepath) - Export to CSV
• to_parquet(filepath) - Export to Parquet
• save_data_per_zipcode(output_dir, file_format, prefix) - Save data per zip code

TemporalAggregator

Class for temporal aggregation of groundwater data.

TemporalAggregator(data, date_column='lev_dt', value_column='lev_va', site_column='site_no')

Methods:

• to_monthly(agg_func, include_count) - Monthly aggregation
• to_annual(agg_func, water_year) - Annual aggregation
• to_growing_season(start_month, end_month, region) - Growing season aggregation
• to_custom_period(months, period_name) - Custom period aggregation
• to_weekly(agg_func) - Weekly aggregation
• resample(freq, agg_func) - Pandas resample
• calculate_statistics(groupby) - Comprehensive statistics
• get_trends(period) - Linear trend analysis

GroundwaterPlotter

Class for visualization of groundwater data.

GroundwaterPlotter(data, date_column='lev_dt', value_column='lev_va', site_column='site_no')

Methods:

• plot_time_series(wells, figsize, title) - Time series plots
• plot_single_well(site_no, show_trend, show_stats) - Detailed single well plot
• plot_comparison(wells, normalize) - Multi-well comparison
• plot_monthly_boxplot(wells) - Monthly distribution
• plot_annual_summary(wells, agg_func) - Annual statistics
• plot_heatmap(well, cmap) - Year-month heatmap
• plot_spatial_distribution(wells_gdf) - Spatial map

Utility Functions

from pyGWRetrieval import (
    save_to_csv,
    save_to_parquet,
    validate_date_range,
    setup_logging,
)

# Configure logging
setup_logging(level=logging.DEBUG, log_file='pyGWRetrieval.log')

Data Sources

This package retrieves data from the USGS National Water Information System (NWIS) using the dataretrieval-python library.

Available Data Sources

Source	API Function	Description	Use Case
gwlevels	get_gwlevels()	Field measurements - Discrete manual readings during field visits	Long-term trends, calibration
dv	get_dv()	Daily values - Daily statistical summaries from continuous sensors	Regular monitoring
iv	get_iv()	Instantaneous values - High-frequency (15-60 min) sensor data	Real-time analysis

USGS Parameter Codes

The following parameter codes are used for groundwater levels:

• 72019: Depth to water level, feet below land surface
• 72020: Elevation above NGVD 1929, feet
• 62610: Groundwater level above NGVD 1929, feet
• 62611: Groundwater level above NAVD 1988, feet

Site Type: GW (Groundwater)

Data Columns and Units

The package retrieves groundwater level data with the following columns:

Column	Description	Units
site_no	USGS site identification number	-
lev_dt	Date of water level measurement	Date (YYYY-MM-DD)
lev_tm	Time of measurement	Time (HH:MM)
lev_va	Water level value	Feet below land surface
lev_acy_cd	Water level accuracy code	-
lev_src_cd	Source of water level data	-
lev_meth_cd	Method of measurement code	-
lev_status_cd	Status of the site at time of measurement	-
station_nm	Station name (merged from site info)	-
dec_lat_va	Decimal latitude	Degrees
dec_long_va	Decimal longitude	Degrees
source_zipcode	Source zip code (for CSV queries)	-

USGS Parameter Codes

Code	Description	Units
72019	Depth to water level below land surface	Feet
72020	Elevation above NGVD 1929	Feet
62610	Groundwater level above NGVD 1929	Feet
62611	Groundwater level above NAVD 1988	Feet

Note: The primary measurement lev_va represents depth to water in feet below land surface. Lower values indicate a shallower water table, while higher values indicate deeper groundwater.

Requirements

• Python ≥ 3.8
• dataretrieval ≥ 1.0.0
• pandas ≥ 1.3.0
• geopandas ≥ 0.10.0
• shapely ≥ 1.8.0
• pyproj ≥ 3.0.0
• pgeocode ≥ 0.3.0
• matplotlib ≥ 3.4.0
• numpy ≥ 1.20.0

Optional Dependencies

• seaborn (enhanced visualizations)
• contextily (basemaps for spatial plots)
• pyarrow (Parquet support)
• scipy (trend analysis)

Storage Requirements

Storage requirements vary based on the number of zip codes, buffer distance, and data sources queried. Below are example estimates based on the full_workflow_csv_zipcodes.py example (99 zip codes, 25-mile buffer, gwlevels source, ~8M records):

Component	Size	Description
Combined Parquet	~80 MB	All retrieved groundwater data
Per-zipcode data	~130 MB	Individual parquet files per zip code
Wells GeoJSON	~25 MB	Well locations with metadata
Aggregated CSVs	~27 MB	Monthly and annual aggregations
Visualization plots	~15 MB	15 PNG figures at 300 DPI
Analysis CSVs	~2 MB	Trends, statistics, projections
Total	~275 MB	Complete workflow output

Scaling estimates:

• ~3 MB per 1,000 wells retrieved
• ~10 KB per groundwater measurement record (Parquet format)
• Plot sizes: ~0.5-1.5 MB each at 300 DPI

Tip: Use Parquet format (default) for efficient storage. Parquet files are ~60% smaller than equivalent CSV files and load significantly faster.

Examples

The examples/ directory contains several example scripts:

• basic_usage.py - Basic data retrieval and visualization
• temporal_analysis.py - Temporal aggregation and trend analysis
• advanced_spatial.py - Advanced spatial queries
• full_workflow_csv_zipcodes.py - Complete end-to-end workflow

Full Workflow Example

The full_workflow_csv_zipcodes.py demonstrates a complete pipeline:

from pyGWRetrieval import GroundwaterRetrieval, TemporalAggregator, GroundwaterPlotter

# 1. Read zip codes from CSV and download data from ALL USGS sources
gw = GroundwaterRetrieval(
    start_date='1970-01-01',
    data_sources='all'  # gwlevels + dv + iv
)
data = gw.get_data_by_zipcodes_csv(
    'locations.csv',
    zipcode_column='ZipCode',
    buffer_miles=100
)

# Data includes 'data_source' column identifying record origin
print(data.groupby('data_source').size())

# 2. Save combined and per-zipcode data
gw.to_csv('all_data.csv')
saved = gw.save_data_per_zipcode('output/', file_format='csv')

# 3. Temporal aggregation
aggregator = TemporalAggregator(data)
monthly = aggregator.to_monthly()
annual = aggregator.to_annual()

# 4. Visualization
plotter = GroundwaterPlotter(data)
fig = plotter.plot_time_series()

This workflow:

• Processes multiple zip codes from a CSV file
• Downloads historical groundwater data (1970-present)
• Saves data both combined and per zip code
• Performs monthly and annual aggregations
• Creates time series, boxplot, and comparison visualizations

Case Study: Regional Groundwater Analysis of 9 U.S. Metropolitan Areas

The full_workflow_csv_zipcodes.py example demonstrates a comprehensive regional groundwater analysis across nine major U.S. Metropolitan Statistical Areas (MSAs): New York, Miami, Washington DC, Houston, Boston, Philadelphia, San Francisco, Chicago, and Dallas.

Study Overview

Metric	Value
Total Records	7,995,927
Monitoring Wells	33,018
Temporal Coverage	1970-2025 (55 years)
Metropolitan Areas	9
Zip Codes Analyzed	99
Visualizations Generated	15 figures

Key Findings

• Dallas shows remarkable groundwater recovery (+10.6 ft/year rising trend)
• Washington DC is the only region with significant declining trend (+1.1 ft/year deepening)
• Miami demonstrates the most stable groundwater conditions (lowest variability)
• 5 of 9 regions show statistically significant long-term trends (p < 0.05)

Generated Analyses

The workflow produces 15 publication-ready visualizations:

1. Regional Trends - Trend analysis by MSA
2. Data Quality - Coverage and density metrics
3. Distributions - Water level statistical distributions
4. Temporal Patterns - Decadal and seasonal patterns
5. Monthly/Annual Boxplots - Seasonal and inter-annual variability
6. Correlation & Clustering - Inter-regional relationships
7. Extreme Events - Drought and anomaly analysis
8. Rate of Change - Trend acceleration analysis
9. Geographic Patterns - Coastal vs. inland comparisons
10. Change Point Detection - Regime shift identification
11. Sustainability Index - Risk assessment (0-100 scale)
12. Future Projections - 5, 10, 20-year water level forecasts
13. Comprehensive Statistics - Publication-ready summary tables

Output Files

• Data: Parquet files (~275 MB total), GeoJSON well locations
• Analysis: CSV files with trends, projections, sustainability metrics
• Report: Auto-generated markdown report (ANALYSIS_REPORT.md)
• Visualizations: 15 PNG figures at 300 DPI

See examples/output/ANALYSIS_REPORT.md for the complete analysis report.

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

1. Fork the repository
2. Create your feature branch (git checkout -b feature/AmazingFeature)
3. Commit your changes (git commit -m 'Add some AmazingFeature')
4. Push to the branch (git push origin feature/AmazingFeature)
5. Open a Pull Request

License

This project is licensed under the MIT License - see the LICENSE file for details.

Citation

If you use this package in your research, please cite:

@software{pyGWRetrieval,
  author = {Sayantan Majumdar},
  title = {pyGWRetrieval: Scalable Retrieval and Analysis of USGS Groundwater Level Data},
  year = {2026},
  url = {https://github.com/montimaj/pyGWRetrieval}
}

Acknowledgments

• USGS for providing groundwater data through NWIS
• dataretrieval-python for the NWIS API interface
