Pyxations

Pyxations is a Python library designed to analyze eye-tracking data, whether you are working with raw eye-tracking data or processed datasets. It helps researchers and developers extract useful insights from complex eye movements using Python's robust ecosystem.

📘 Documentation

Features

• Validated BIDS Conversion: Convert EyeLink, Tobii, GazePoint, and webcam/WebGazer samples, tracker events, and behavioral tables to raw BIDS while preserving the input folder verbatim under archival sourcedata/.
• EyeLink Import: Read EyeLink ASC exports directly, or accept EDF files by first converting them with SR Research's edf2asc utility. Pyxations then extracts messages, calibration reports, tracker events, and gaze samples from the resulting ASC data.
• Trial Segmentation: Segment continuous eye-tracking data into trials using flexible methods, including start/end messages, fixed durations, or explicit start/end times.
• Behavioral Input Adapters: Normalize behavioral CSV, TSV, or standard PsychoPy New trial logs into BIDS events.tsv, with source-independent column mapping and no PsychoPy runtime dependency.
• Derivative Computation: Compute derivatives directly from the normalized raw BIDS dataset; the archived source files are not required at runtime.
• Analysis and Visualization: Load derivative tables through the experiment, subject, session, and trial hierarchy and generate gaze, scanpath, calibration, and task-specific plots.
• Eye Movement Detection: Use REMoDNaV, the Engbert–Kliegl implementation, or EyeLink-reported events.
• Saccades Direction Classification: Classify saccades based on their start and end coordinates into four primary directions: right, left, up, and down.

Requirements

• Python 3.11 or newer is required.
• EyeLink EDF input requires the edf2asc program from the EyeLink Developers Kit on PATH. Existing EyeLink ASC files can be read directly.

Dependencies

The base installation contains only the shared runtime stack:

• numpy
• polars
• matplotlib

Feature-specific packages are optional:

• pyxations[remodnav] adds REMoDNaV detection.
• pyxations[multimatch] adds MultiMatch scanpath comparison.
• pyxations[video] adds OpenCV-backed gaze animation, with optional video or image backgrounds.
• pyxations[all] installs all three feature groups.

Test and documentation tools are kept in optional dependency groups.

Canonical raw and derivative data are stored as compressed BIDS TSV/JSON, and the complete tabular pipeline uses Polars in memory.

Installation

Install the base package with uv or pip:

uv pip install pyxations
# or
pip install pyxations

Install only the features you use. The example below uses REMoDNaV:

pip install "pyxations[remodnav]"

For every optional feature:

pip install "pyxations[all]"

Documentation

Full documentation and API reference are available at https://neuroliaa.github.io/pyxations

Usage

Minimal example

import pyxations as pyx

# 1) Convert raw files to BIDS
bids_path = pyx.dataset_to_bids(
    target_folder_path="path/to/output",
    files_folder_path="path/to/source-recordings",
    dataset_name="dataset_name",
    format_name="eyelink",
    task_name="visualsearch",
)

# 2) Compute derivatives using REMoDNaV
msg_keywords = ["begin", "end", "press"]
start_msgs = {"search": ["beginning_of_stimuli"]}
end_msgs = {"search": ["end_of_stimuli"]}

pyx.compute_derivatives_for_dataset(
    bids_path,
    dataset_format="eyelink",
    detection_algorithm="remodnav",
    msg_keywords=msg_keywords,
    start_msgs=start_msgs,
    end_msgs=end_msgs,
    overwrite=True,
)

This produces two sibling, validator-tested BIDS datasets: the raw dataset and dataset_name_derivatives. Canonical derivative samples and eye-movement annotations are stored as compressed BIDS TSV.GZ files with JSON sidecars. Pyxations reconstructs the same in-memory analysis tables when they are loaded.

Contributing

Contributions are welcome! Please check out the issues and submit a pull request if you'd like to help.

To develop locally

# Clone repository
git clone https://github.com/NeuroLIAA/pyxations.git
cd pyxations

# Create virtual environment and install
uv venv
uv pip install -e '.[dev]'

# To work on documentation
uv pip install -e '.[docs]'

License

This project is licensed under the MIT License.
