VOLATOUCH

Ultra-Low Latency Mobile Air Control & Wireless Trackpad for PC over Wi-Fi

⚡ Quick Start • ✨ Features • 📱 Gestures • 🏗️ Architecture • 🛡️ Security • ⚙️ Settings • 🇹🇷 Türkçe Rehber

⚡ Quick Start (PyPI)

Install and launch Volatouch with a single command from your terminal:

# 1. Install Volatouch via pip
pip install volatouch

# 2. Launch the server
volatouch

Once started, the console displays your local server address (e.g., http://192.168.1.5:8000).
Open this URL in Safari or Chrome on your phone (connected to the same Wi-Fi) — no mobile app installation required!

✨ Key Features

• 🚀 Ultra-Low Latency Binary Video Streaming:

  • Screen capture powered by mss delivering hardware-level 60 FPS.
  • Direct 4-channel BGRA JPEG compression via OpenCV (cv2.imencode), skipping CPU color-space conversions.
  • Raw binary ArrayBuffer transmission over WebSockets with 8-byte high-precision double timestamp headers for sub-millisecond round-trip profiling.
  • Zero-delay, single-slot subscriber queues (asyncio.Queue(maxsize=1)) prevent buffer bloat and queue lag.

• 🎯 Dual Input Modes (Direct Target & Relative Trackpad):

  • Direct Mode: Tap anywhere on your phone's screen to navigate the cursor directly to that coordinate on your desktop display.
  • Relative Trackpad Mode: Precision multi-touch trackpad navigation with acceleration and configurable sensitivity.

• 🏝️ Draggable Floating Action Island:

  • L-Click / R-Click: Dedicated, ergonomic primary action buttons.
  • Hold / Drag Lock: One-tap persistent mouse hold with tactile haptic feedback for window movement and drag-and-drop.
  • Scroll Up / Down: Instant micro-step vertical scrolling without needing two-finger gestures.
  • Collapsible Mini-Pill: Compact mode keeps 100% of your screen visible when not interacting.
  • Auto Boundary Clamping: Widgets automatically re-align to stay safely within the viewport across orientation changes and fullscreen toggles.

• ⌨️ Comprehensive Built-In Virtual Keyboard:

  • Full QWERTY layout with smart dynamic Caps / Shift character switching.
  • Sticky Modifier Keys: Ctrl, Shift, Alt, and Win (Super) lock on tap (highlighted in indigo) for seamless desktop combos (e.g., Ctrl + C).
  • Dedicated F1–F12 function row, navigation keys (Esc, Tab, Home, End, Arrows), and Voice / Text input drawer.

• 📱 Landscape Edge-to-Edge Fill Mode:

  • Switch between Fit (Aspect Ratio) and Fill (Full Screen Stretch) modes to eliminate black side bars on widescreen mobile displays.

• 🌐 Bilingual UI (English & Türkçe):

  • Instant toggle between English and Turkish directly from Settings, remembered via localStorage.

📱 Gesture & Touch Cheatsheet

🏗️ Architecture

flowchart TD
    subgraph Host ["Desktop Host (Windows)"]
        MSS["mss (Screen Capture 60 FPS)"] --> BGRA["Direct BGRA Frame (No cvtColor)"]
        BGRA --> CV2["cv2.imencode (JPEG Compression)"]
        CV2 --> TIME["Timestamp Header (8-Byte Double)"]
        TIME --> ASYNC["Zero-Copy Queue (asyncio.Queue)"]
        ASYNC --> WS_STREAM["/ws/stream (Binary WebSocket)"]

        WS_INPUT["/ws/input (JSON WebSocket)"] --> CTRL["InputController (pynput)"]
        CTRL --> OS_INPUT["Windows OS Hardware Emulation"]
    end

    subgraph Client ["Mobile Client (Browser / PWA)"]
        WS_STREAM --> BITMAP["createImageBitmap (Worker-like GPU decode)"]
        BITMAP --> RAF["requestAnimationFrame() -> HTML5 Canvas"]

        TOUCH["Multi-Touch Engine (Direct & Relative)"] --> WS_INPUT
        KB["Virtual Keyboard & Sticky Modifiers"] --> WS_INPUT
        ACTIONS["Floating Island (Click, Hold, Scroll)"] --> WS_INPUT
    end

🛡️ Security & Sandbox

Volatouch implements defense-in-depth security to protect your workstation on shared Wi-Fi networks:

1. Subnet Verification (RFC-1918): Only clients within the identical /24 private local subnet as the host machine can access endpoints or initiate WebSocket handshakes. External and non-local requests receive an immediate 403 Forbidden.
2. Strict Origin & CSP Isolation: Rejects unauthorized origin headers; enforces modern Content-Security-Policy, X-Frame-Options: DENY, and strict frame-ancestors restrictions.
3. Whitelisted Hardware Commands: Only explicit, sanitized commands (mouse_move, mouse_click, key_tap, etc.) are processed. Arbitrary shell commands are impossible.
4. Failsafe Key Release: Whenever a WebSocket connection drops, all pressed keys and mouse buttons are instantly released via input_ctrl.release_all() to prevent stuck keys on your PC.
5. Private Console Telemetry: No third-party tracking, no external web calls, and silenced debug logs. The host console only shows an active connection counter.

⚙️ Settings & Diagnostics

Tap the floating gear icon to access:

• JPEG Quality Slider (15% – 95%): Dynamically tune bandwidth usage vs. visual clarity in real time.
• Resolution Scale Slider (30% – 100%): Downscale resolution for ultra-high FPS over congested Wi-Fi channels.
• Cursor Speed & Acceleration: Fine-tune trackpad velocity and exponential sensitivity curves.
• Real-time Latency & FPS Badge: Monitor live stream frame rates and hardware round-trip ping in milliseconds.
• Language Selector: Seamlessly switch between English and Türkçe.

💻 Running From Source

If you prefer building and developing Volatouch locally:

Prerequisites

• Python 3.8+ (Recommended: Python 3.10+)
• Node.js 18+ (for building the frontend)

Setup

# 1. Clone repository
git clone https://github.com/ugurturkerkebeci/volatouch.git
cd volatouch

# 2. Install Python dependencies
pip install -r backend/requirements.txt

# 3. Build React frontend
cd frontend
npm install
npm run build
cd ..

# 4. Run application
python run.py

🇹🇷 Türkçe Rehber

Volatouch, aynı yerel Wi-Fi ağına bağlı bilgisayarınızı mobil cihazınızın web tarayıcısı üzerinden sıfıra yakın gecikmeyle (ultra-low latency) yönetmenizi sağlayan yüksek performanslı bir uzaktan kontrol ve hava trackpad sistemidir.

Hızlı Kurulum (PyPI):

pip install volatouch
volatouch

Konsolda yazan adresi (örn. http://192.168.1.5:8000) telefonunuzun tarayıcısında açmanız yeterlidir.

Başlıca Özellikler:

• Sıfır Gecikme: mss ve OpenCV tabanlı binary JPEG akışı, doğrudan GPU'da çizilen HTML5 Canvas ile tear veya kare düşmesi yaşatmaz.
• Doğrudan ve Bağıl Mod: İster ekrana dokunup imleci doğrudan oraya yönlendirin (Direct), ister dizüstü bilgisayar trackpad'i gibi kullanın (Relative).
• Yüzen Fonksiyon Adası: Sol tık, sağ tık, dosya sürüklemek için sol tık kilidi (HOLD), ve hassas kaydırma (UP/DOWN) butonları.
• Dahili Türkçe/İngilizce QWERTY Klavye: Ctrl, Alt, Shift gibi niteleyici tuşları basılı tutma desteği, F1–F12 tuşları ve ses/metin aktarım çekmecesi.
• Yerel Ağ Güvenliği: Yalnızca aynı yerel Wi-Fi alt ağındaki (subnet) cihazların bağlanmasına izin verir.

📄 License

Distributed under the MIT License. See LICENSE for full details.

Crafted with ❤️ by Uğur Türker Kebeci
