AppTap 0.3.0

Application-Scoped Traffic Acquisition Pipeline — capture only one application's network traffic, scoped by its Linux UID.

Application-Scoped Traffic Acquisition Pipeline

Capture only one app's network traffic — scoped by its Linux UID.

AppTap

Capture only one application's network traffic, scoped by its Linux UID, using the kernel's authoritative knowledge of which UID owns each socket — something tcpdump/BPF alone cannot do (UID is a socket property, absent from the wire).

AppTap is both an importable library and a standalone CLI tool. It acquires an app-scoped pcap (plus the matching connection set). It deliberately does not decrypt TLS or handle keys — that is the consumer's job (e.g. friTap, which embeds decryption keys onto AppTap's pcap).

How it works — two tiers, auto-selected

Two kernel mechanisms can scope capture by UID, and neither is universally available, so AppTap probes and picks the best one at runtime:

• Tier 1 — interface capture + kernel socket-table UID filter (robust default). Capture on the interface, then keep only packets whose 5-tuple belongs to the target UID(s), resolved from the kernel's authoritative socket→UID table (SOCK_DIAG / /proc/net/{tcp,tcp6,udp,udp6}). Works on every Android/Linux version.
• Tier 2 — iptables owner + CONNMARK + NFLOG in-kernel pre-filter (opportunistic). The kernel selects only the app's packets and copies them to userspace. Cleanest and most private, but depends on the kernel's nfnetlink_log delivery, which is disabled on most stock Android 12–14 GKI kernels. Used only where a capability probe (plus a delivery liveness check) confirms it works.

Requires root on the target (Android: rooted device + adb; Linux: root/sudo).

Install

pip install AppTap

CLI

apptap com.example.app --device <serial> -o app.pcap        # Android (adb)
apptap 1234 --local -o app.pcap                             # Linux (pid)
apptap com.example.app --device <serial> --tier sockdiag --strict -d 30
apptap --probe   --device <serial>                          # report capabilities + chosen tier
apptap --cleanup --device <serial>                          # remove any leftover APPTAP_* rules

Library

import apptap

result = apptap.capture(
    target=apptap.Target(package="com.example.app"),
    executor=apptap.AdbExecutor(device_id="<serial>"),   # or apptap.LocalExecutor()
    output="app.pcap",
    breadth=apptap.Breadth.APP_ISOLATED_DNS,             # default
    tier=apptap.Tier.AUTO,
)
print(result.tier, result.uids, result.pcap_path)

Drive the lifecycle yourself (capture while you run/instrument the app):

with apptap.CaptureSession(target=..., executor=..., output="app.pcap") as cap:
    cap.start()
    ...            # launch the app / attach your instrumentation
    cap.stop()
result = cap.result

Bring your own transport by implementing the apptap.Executor protocol (or wrapping an existing one): AppTap runs every command through it, so it can reuse a host tool's adb/root plumbing.

License

MIT © Daniel Baier
