DiskAnalyzer 1.0.1

This package implements multiples libraries and tools to parse, analyze and extract informations from disk a file.

DiskAnalyzer

Description

This package implements multiples libraries and tools to parse, analyze and extract informations from disk and main partition for the live system or a full disk file.

• Pure python package
• Running on live Windows system
• Analyze MBR (Master Boot Record) and GPT (GUID Partition Table)
• List partitions
• Analyze VBR (Volume Boot Record) for NTFS partition (New Technology File System)
• Analyze MFT file and attribute (Master File Table)
• Extract MFT file
• Analyze MFT
• Extract MFT Entries
• Generate file full from path from MFT
• Extract file content from NTFS partition
• Analyze FAT32
• Extract file content from FAT32 partition
• Analyze ExFAT Boot Sector
• Repair MBR for non bootable disk and MFT/ExFAT partitions (using disk carving)

Requirements

This package require:

• python3
• python3 Standard Library

Installation

Pip

python3 -m pip install DiskAnalyzer

Git

git clone "https://github.com/mauricelambert/DiskAnalyzer.git"
cd "DiskAnalyzer"
python3 -m pip install .

Wget

wget https://github.com/mauricelambert/DiskAnalyzer/archive/refs/heads/main.zip
unzip main.zip
cd DiskAnalyzer-main
python3 -m pip install .

cURL

curl -O https://github.com/mauricelambert/DiskAnalyzer/archive/refs/heads/main.zip
unzip main.zip
cd DiskAnalyzer-main
python3 -m pip install .

Usages

Command line

DiskAnalyzer              # Using CLI package executable
python3 -m DiskAnalyzer   # Using python module
python3 DiskAnalyzer.pyz  # Using python executable
DiskAnalyzer.exe          # Using python Windows executable

NtfsAnalyzer              # Using CLI package executable
python3 -m NtfsAnalyzer   # Using python module
python3 NtfsAnalyzer.pyz  # Using python executable
NtfsAnalyzer.exe          # Using python Windows executable

MftAnalyzer               # Using CLI package executable
python3 -m MftAnalyzer    # Using python module
python3 MftAnalyzer.pyz   # Using python executable
MftAnalyzer.exe           # Using python Windows executable

Fat32Analyzer             # Using CLI package executable
python3 -m Fat32Analyzer  # Using python module
python3 Fat32Analyzer.pyz # Using python executable
Fat32Analyzer.exe         # Using python Windows executable

MbrRepair                 # Using CLI package executable
python3 -m MbrRepair      # Using python module
python3 MbrRepair.pyz     # Using python executable
MbrRepair.exe             # Using python Windows executable

ExFatAnalyzer             # Using CLI package executable
python3 -m ExFatAnalyzer  # Using python module
python3 ExFatAnalyzer.pyz # Using python executable
ExFatAnalyzer.exe         # Using python Windows executable

# Fat32Analyzer have it's own argument parser
Fat32Analyzer /path/to/fat32.img
Fat32Analyzer /path/to/fat32.img -v # verbose

# Other commands use the same argument parser:
# (only one optionale argument: filepath, defaulft: main disk file)

MbrRepair                           # main disk
MbrRepair /path/to/disk

DiskAnalyzer                        # main disk
DiskAnalyzer /path/to/disk

NtfsAnalyzer                        # main disk
NtfsAnalyzer /path/to/disk

MftAnalyzer                         # main disk
MftAnalyzer /path/to/disk

ExFatAnalyzer                       # main disk
ExFatAnalyzer /path/to/disk

Python script

from DiskAnalyzer import *

print(disk_parsing(file_path="/path/to/disk").to_partition())

file, vbr, ntfs_offset = ntfs_parse(file_path="/path/to/disk")

(
	file,
	mft_entry,
	mft_entry_raw_data,
	mft_entry_offset,
	mft_entry_size,
	ntfs_offset,
	cluster_size,
) = parse_mft(file_path=filename)

file_extract(file, mft_entry, "$MFT", mft_entry_raw_data, ntfs_offset)

with open(
		"MftEntries.csv", newline='', encoding="utf-8"              # NOTE: MftEntries.csv was generated by running DiskAnalyzer from the command line
	) as entries, open(
		"FullPath.csv", newline='', encoding="utf-8"                # NOTE: FullPath.csv was generated by running DiskAnalyzer from the command line
	) as full_path, open("SAM", 'wb') as sam, open("SYSTEM", 'wb') as system:
	file_extract_from_csv(
		r'\\.\C:\.\Windows\System32\config\SAM', sam, entries, full_path, file
	)
	file_extract_from_csv(
		r'\\.\C:\.\Windows\System32\config\SYSTEM', system, entries, full_path, file
	)


file.close()

with open("MftEntries.csv", "w", newline="", encoding="utf-8") as entries_file, open("$MFT", "rb") as mft, open("FullPath.csv", "w", newline="", encoding="utf-8") as fullpath_file:
	entries_writer = writer(entries_file, quoting=QUOTE_ALL)
	fullpath_writer = writer(fullpath_file, quoting=QUOTE_ALL)
	for mft_entry, data_positions in extracted_mft_analysis(mft, entries_writer, fullpath_writer):
		pass

>>> from DiskAnalyzer.MftAnalyzer import parse_extracted_mft, get_data_positions, save_attribute, resolve_parents, file_names
>>> from csv import writer, QUOTE_ALL
>>> filename = "$MFT"
>>> with open("MftEntries.csv", "w", newline="", encoding="utf-8") as csv_file, open(filename, "rb") as mft:
...     csv_writer = writer(csv_file, quoting=QUOTE_ALL)
...     for mft_entry in parse_extracted_mft(mft):
...         data_positions = []
...         for offset, size, resident in get_data_positions(mft_entry, 0, 0):
...             data_positions.append((offset, size, "resident" if resident else "non-resident"))
...         save_attribute(csv_writer, mft_entry, mft.tell(), data_positions)
>>> with open("FullPath.csv", "w", newline="", encoding="utf-8") as csv_file:
...     csv_writer = writer(csv_file, quoting=QUOTE_ALL)
...     for record_sequence, name in file_names.items():
...         full_path = resolve_parents(name, record_sequence, "$MFT")
...         csv_writer.writerow(
...             [
...                 str(record_sequence[0]),
...                 str(record_sequence[1]),
...                 name,
...                 full_path,
...             ]
...         )
>>>

Links

• Pypi
• Github
• DiskAnalyzer - Documentation
• DiskAnalyzer - Python executable
• DiskAnalyzer - Python Windows executable
• NtfsAnalyzer - Documentation
• NtfsAnalyzer - Python executable
• NtfsAnalyzer - Python Windows executable
• MftAnalyzer - Documentation
• MftAnalyzer - Python executable
• MftAnalyzer - Python Windows executable
• Fat32Analyzer - Documentation
• Fat32Analyzer - Python executable
• Fat32Analyzer - Python Windows executable
• ExFatAnalyzer - Documentation
• ExFatAnalyzer - Python executable
• ExFatAnalyzer - Python Windows executable
• MbrRepair - Documentation
• MbrRepair - Python executable
• MbrRepair - Python Windows executable

License

Licensed under the GPL, version 3.
