Simple circuit builder only using logic gates
Project description
Logic Circuit
LogicCircuit is a program that helps build simple circuits using logic gates. It is meant to teach people the basics of how logic gates work.
📃 Table of Content
🟢 Example
📦 Installation
➡️ pip3 install LogicCircuit ⬅️
❓ How To
| Gate | Switch | Led | Wire | |
|---|---|---|---|---|
| Create | Left click logic type(bottom). Press anywhere to place | Left click green "+Switch" Button | Left click green "+LED" Button | Left click output gate by pressing on it. Press anywhere on screen while output gate selected to create "bends" to wire. Left click on any gates and leds input square |
| Delete | Right click on gate | Left click red "-Switch" Button | Left click red "-LED" Button | Wires will automatically when connected gate, switch, or led is deleted |
| Modify | N/A | Middle press on switch | N/A | N/A |
👽 Future
- Main Menu
- Save Project
- Tutorial
⚖️ License
MIT
