admesh2D 0.2.1

ADMESH: an advanced, automatic unstructured mesh generator for 2D shallow-water models.

ADMESH

An advanced, automatic unstructured mesh generator for 2D shallow-water models.
Python port of the MATLAB ADMESH library, with native ADCIRC fort.14 round-trip and a Pythonic API.

Western North Atlantic / Gulf / Caribbean — meshed with curvature-driven sizing and dominant-tide refinement.

---

Contents

• Why ADMESH
• Install
• Quickstart
• The pipeline
• Boundary types
• Status & roadmap
• Documentation
• Citation
• Upstream & related projects
• Contact
• License

---

Why ADMESH

For shallow-water modelers who need ADCIRC-ready meshes from Python:

• MATLAB-faithful port. 13 stages reproduced 1:1 from the OSU CHIL Lab 01_ADMESH_Library, with numerical agreement tracked by a 250+ test suite. Switching from MATLAB to this library does not change your meshes.
• Native ADCIRC fort.14 I/O. Read, mesh, write — bit-faithful round-trip including paired-edge boundary records (IBTYPE 3 / 4 / 13 / 24).
• Curvature + medial-axis + bathymetry + tide-aware sizing. Size field is a min-stack of physical drivers, not a hand-tuned scalar. Custom contributions compose on top.
• Pythonic surface, faithful internals. Domain / Mesh / BoundarySegment are frozen dataclasses with typed fields; the gnarly numerics stay inside the faithful-port modules and stay testable.
• Cross-repo by design. Pairs with ADMESH-Domains (mesh registry) and the upstream MATLAB reference for lineage tracking.

Not the right tool if you need 3-D, anisotropic, or non-triangular elements — use gmsh for those.

Install

pip install admesh2D            # core
pip install admesh2D[viz]       # adds matplotlib for mesh.plot()

From source:

git clone https://github.com/domattioli/ADMESH.git
cd ADMESH
pip install -e ".[dev]"

Requires Python ≥ 3.10. Core deps: NumPy, SciPy, Numba, Shapely. The import name is admesh (the admesh2D on PyPI is the distribution name — the admesh namespace on PyPI is an unrelated STL library).

Install hiccups (Numba on Apple Silicon, SciPy wheels on older Python): see open issues and file a new one if you hit a fresh failure.

Quickstart

Built-in domain

import admesh
from admesh import domains

mesh = admesh.triangulate(domains.UNIT_DISK, h_max=0.1)
mesh.to_fort14("disk.14")

mesh is a frozen Mesh dataclass — typed nodes, elements, boundaries (each a BoundarySegment with a BoundaryType code), optional bathymetry, per-element quality.

Round-trip with ADCIRC fort.14

import admesh

mesh = admesh.read_fort14("input.14")
mesh.to_fort14("output.14")
assert mesh.equals(admesh.read_fort14("output.14"))     # bit-faithful

Re-mesh an existing fort.14

import admesh
from admesh.api import Domain

source = admesh.read_fort14("coarse.14")
domain = Domain.from_mesh(source)
refined = admesh.triangulate(domain, h_max=500.0, h_min=50.0)
refined.to_fort14("refined.14")

Custom size-field contribution

import numpy as np
import admesh

def refine_near_breaker(pts: np.ndarray) -> np.ndarray:
    return 50.0 + 0.2 * np.abs(pts[:, 0] - 1500.0)

mesh = admesh.triangulate(
    "coast.14",
    user_contribs=(refine_near_breaker,),
)

Built-in size-field stages (curvature, medial axis, bathymetry, tide) min-stack identically to MATLAB. User contributions compose on top via combine= (default: elementwise minimum).

Build a Domain directly from an SDF

import numpy as np
from admesh.api import Domain, triangulate

def sdf_disk(p: np.ndarray) -> np.ndarray:
    return np.linalg.norm(p, axis=1) - 1.0

mesh = triangulate(Domain(sdf=sdf_disk, bbox=(-1, -1, 1, 1)), h_max=0.1)

The pipeline

Each call to triangulate(...) flows through the 13-stage ADMESH pipeline (faithful port of the MATLAB modules under 01_ADMESH_Library):

#	Stage	Module	Purpose
1	Distance	admesh.distance	Signed-distance grid from the domain SDF
2	Curvature	admesh.curvature	Refines near sharp boundary curvature
3	Medial axis	admesh.medial_axis	Adds sizing pressure in narrow channels
4	Bathymetry	admesh.bathymetry	Element size scales with depth gradient
5	Dominant tide	admesh.dominate_tide	Resolves tidal wavelength on the shelf
6	Boundary	admesh.boundary	Enforces BC labels at boundary edges
7	Mesh size	admesh.mesh_size	Numba-JIT iterative solver (min-stack)
8	distmesh2d	admesh.distmesh	Truss-equilibrium point placement
9	Quality	admesh.quality	Per-element shape metric, gate at q ≥ 0.3
10	In-polygon	admesh.in_polygon	Winding-number containment tests
11	Inpaint	admesh.inpaint	Fills NaN holes in bathymetry / size grids
12	Background grid	admesh.background_grid	Anisotropic background field
13	Valence	admesh.valence	Edge-flip rebalancing (new in 0.2.0, issue #27)

The Numba-JIT iterative solver replaces the C MEX from the MATLAB original — no compile step at install time.

Boundary types

BoundaryType is an IntEnum over the ADCIRC IBTYPE codes that the fort.14 reader/writer names. Unmapped codes round-trip as plain int on BoundarySegment.bc_type.

Code	Name	Meaning
0	OPEN	Open ocean / external water
1	MAINLAND (alias WALL)	Mainland boundary, no normal flux
11	ISLAND	Island boundary
20	MAINLAND_FLUX	Mainland with specified normal flux
3 / 4 / 13 / 24	(preserved as int)	Paired-edge / weir-type — read and written faithfully, not yet named in the enum
other	(preserved as int)	Round-tripped, not interpreted

from admesh import BoundaryType, read_fort14

mesh = read_fort14("coast.14")
for seg in mesh.boundaries:
    if seg.bc_type == BoundaryType.ISLAND:
        ...

Status & roadmap

• Shipped (v0.2.1). Pythonic API + fort.14 round-trip + 13-stage faithful port + valence balancing + custom size-field hooks. Published to PyPI and archived on Zenodo.
• In flight. Spec 009 release-readiness (CI workflows, mkdocs site, stage-module reorg into admesh/_stages/). Spec 008 Gmsh I/O.
• Next. Default size-field stack consolidation, paired-edge IBTYPE 3 / 4 / 13 / 24 promoted to named BoundaryType members, downstream consumer migration (MADMESHR, CHILMESH).

Open epics live as labeled issues — see planning-required.

Documentation

• API reference: docstrings on Domain, Mesh, BoundarySegment, triangulate, read_fort14, write_fort14, and the 13 stage modules.
• Architecture + porting notes: docs/ (governance, persistence journal, porting notes, domain I/O).
• Specs (design + acceptance criteria for each feature): specs/.
• Constitution (project principles + faithful-port invariants): docs/governance/CONSTITUTION.md.
• A mkdocs site with auto-generated API reference lands with spec 009 R3.

Citation

Algorithm / theory (cite the original paper):

Conroy, C.J., Kubatko, E.J., West, D.W. (2012). ADMESH: an advanced, automatic unstructured mesh generator for shallow water models. Ocean Dynamics 62, 1503–1517. https://doi.org/10.1007/s10236-012-0574-0

This software (cite the archived release):

Mattioli, D., Conroy, C.J., Kubatko, E.J., West, D.W. (2026). ADMESH: An advanced, automatic unstructured mesh generator for 2D shallow-water models (Python port). Zenodo. https://doi.org/10.5281/zenodo.20264101

The DOI 10.5281/zenodo.20264101 resolves to the latest release; version-specific DOIs are listed on the Zenodo record. A CITATION.cff is provided at the repo root for tools that consume it (GitHub's "Cite this repository" button, Zotero, etc.). Paper copy: papers/Conroy-2012-ADMESH.pdf.

Upstream & related projects

• coltonjconroy/ADMESH — reference MATLAB implementation, maintained by the original author. New functionality is pulled across as it lands upstream.
• ADMESH-Domains — federated registry of ADCIRC-compatible meshes for discovery, lineage tracking, and community contribution. Built as a companion to this library.

Contact

• Theory (algorithm, size-field formulation, ADCIRC integration): Ethan J. Kubatko — [e-mail]
• Python port (this repository): Dominik Mattioli — github.com/domattioli

License

Apache 2.0 — see LICENSE.
