Chronicle

Record-and-replay for agent decision graphs. Chronicle records what your agent did at each decision boundary (its LLM calls, tool calls, and routing choices) so you can reproduce a production failure as a committed regression test and re-run your fix without live LLM calls. The target is one specific, real problem: control-flow and tool-safety regressions in multi-agent systems, caught deterministically from recorded incidents.

Demo

Architecture

Chronicle is two systems that share one artifact, the Envelope: a recorder that captures boundary crossings during a live run, and a test bench that replays them without touching the model.

flowchart LR
    subgraph REC["Record (LIVE run)"]
        A["Your agent<br/>llm · tool · router calls"] -->|"@boundary"| B["Envelope Recorder"]
        B --> C["Append-only<br/>envelope store (.jsonl)"]
        C --> D["Execution graph<br/>(side graph, no topology change)"]
    end

    D -->|"export / extract"| E["fixtures/ committed to git<br/>envelopes/ · traces/"]

    subgraph REP["Replay & Verify (no live LLM)"]
        E --> F["ReplayPlan<br/>stub upstream · run one boundary live"]
        F --> G["Layer 1: structural replay<br/>control flow &amp; tool safety"]
        E --> H["Layer 2: LLM-as-judge<br/>grounding · safety · refusal"]
    end

    G --> I["pytest / CI<br/>regression tests"]
    H --> I
    D -.->|"on_crossing hook"| J["Cost / governance<br/>(external, e.g. TokenOps)"]

The Envelope is an immutable, append-only record of one boundary crossing:

Field	Contents
Contextual metadata	Model version, sampling parameters, runtime build ID
Input state	Assembled prompt, graph state, retrieved context chunks
Action / result	Structured tool calls and model completion
Graph linkage	parent_envelope_id, sequence, invocation_index for retries

Optional OpenInference and Arize Phoenix integrations feed framework-agnostic tracing into this same envelope format.

Install

# From source (development):
pip install -e ".[dev]"

# From PyPI:
pip install agent-chronicle

Quick start

The primary API is one decorator. Annotate a decision boundary once; it records in live mode and stubs from a fixture in replay mode.

from chronicle import boundary, reset_session, ReplayPlan
from chronicle.envelope.store import EnvelopeStore

@boundary("agent", kind="llm")
def agent_plan(state: dict) -> dict:
    ...

@boundary("delete_file", kind="tool")
def delete_file(path: str, environment: str) -> dict:
    ...

# 1. Record a run (live mode is the default)
session = reset_session()
session.store = EnvelopeStore(".chronicle/runs/incident.jsonl")
session.begin_trace("trace-001")
run_agent(...)

# 2. Freeze it as a committed fixture
session.export_trace("fixtures/traces/incident-001/")

Cut-point replay

Test a fix in one boundary while the rest of the incident stays frozen. Upstream boundaries are stubbed from the fixture, your changed boundary runs live, and you assert on its captured result.

session = reset_session()
session.load_trace("fixtures/traces/deletion-incident-001/")
session.enable_replay(
    ReplayPlan()
    .stub("agent", 1)          # upstream: frozen from fixture
    .live("delete_file", 1)    # cut-point: run new code
    .live("agent", 2)          # downstream: observe the effect
)
run_agent(...)

assert session.captured_result("delete_file", 1)["blocked"] is True

One decorator, two behaviors: in live mode your function runs and its input/output are recorded into an Envelope; in replay + stub mode it does not run and Chronicle returns the recorded output. A cut-point is the one boundary you flip back to live to test new code against real upstream inputs.

Verification layers

Layer	Goal	Mechanism
Layer 1: replay	Validate control flow and tool safety	Structural assertions over recorded fixtures; never calls the LLM
Layer 2: evaluation	Validate generation quality	LLM-as-a-judge on meaning (grounding, safety, refusal), not bitwise equality
Cut-point replay	Test a change in one boundary	Stub upstream from fixtures, run the target boundary live

Layer 1 (single-envelope injector)

from chronicle.replay import ReplayInjector
from chronicle import Envelope

envelope = Envelope.from_file("fixtures/envelopes/incident-2026-06-17-001.json")
injector = ReplayInjector(envelope)

def agent(state, inj):
    inj.stub_llm()
    inj.stub_tool("search_docs", {"query": "reset API key"})
    return {"finish_reason": "tool_calls"}

_, _, assertions = injector.replay(agent)
assert all(a.passed for a in assertions)

Layer 2 (LLM-as-judge)

from chronicle.judge import JudgeRunner, OpenAIJudgeClient

runner = JudgeRunner(OpenAIJudgeClient(model="gpt-4o-mini"))
result = runner.evaluate(envelope)
assert result.overall_passed

Demos

Each demo records an incident from an ungated tool, then a cut-point test verifies the gated fix. All use the same agent@1 -> tool@1 -> agent@2 shape.

Scenario	Command	Incident
Refund equals order ID	refund	$9.8M refund on a $47 order
Invoice currency mismatch	invoice	EUR 2M invoice sent as USD
Trade notional vs shares	trade	~$190k sell instead of ~$1k
Deletion agent	(see below)	Ungated delete_file wipes prod

# Financial incidents: record, then cut-point test
python examples/financial_incidents/run.py refund record
python examples/financial_incidents/run.py refund test
python examples/financial_incidents/run.py all test      # all three in sequence
pytest tests/test_financial_incidents.py -v

# Deletion agent: record, visualize, cut-point test
python examples/deletion_agent/record_incident.py
python examples/deletion_agent/show_trace.py --ui        # interactive timeline + graph
python examples/deletion_agent/run_cutpoint_demo.py
pytest tests/test_deletion_cutpoint.py -v

The gated fix in each tool refuses when an amount exceeds a flat cap (MAX_REFUND_CENTS, MAX_INVOICE_CENTS, MAX_ORDER_NOTIONAL_CENTS). Source lives under examples/financial_incidents/ and examples/deletion_agent/.

CLI

chronicle record                                    # bootstrap tracing + instrumentation
chronicle extract --trace-id ID                     # export envelopes to fixtures/
chronicle replay FIXTURE.json                       # Layer 1 deterministic replay
chronicle verify FIXTURE.json --layer2 --mock-judge # Layer 1 + Layer 2
chronicle show-graph fixtures/traces/TRACE --ui     # interactive trace visualization
chronicle show-graph TRACE --html out.html          # static HTML export
chronicle schema                                    # print Envelope JSON Schema
chronicle list-fixtures                             # list committed envelope fixtures

LangGraph integration (optional)

For LangGraph-specific node wrapping as an alternative to @boundary:

from chronicle.envelope.capture import EnvelopeRecorder
from chronicle.envelope.store import EnvelopeStore
from chronicle.instrumentation import instrument_graph_nodes

recorder = EnvelopeRecorder(
    store=EnvelopeStore(".chronicle/runs/envelopes.jsonl"),
    model_version="gpt-4o-2024-08-06",
    build_id="deploy-abc123",
)
wrapped_nodes = instrument_graph_nodes(recorder, {"agent": agent_node})

See examples/langgraph_demo/agent.py.

Cost and governance observers (on_crossing)

Chronicle does not embed cost management. External systems (for example TokenOps) attach an observer that fires after each live crossing:

session = reset_session()
session.on_crossing = my_observer  # (boundary_id, kind, input_state, result) -> None

It runs after a live envelope record and a live cut-point capture, and does not run on stub replay. See tests/test_cost_management_e2e.py for an end-to-end ledger and budget pattern.

Environment variables

Variable	Purpose
CHRONICLE_BUILD_ID	Pin runtime build ID in envelope metadata
CHRONICLE_STORE	Default envelope store path
PHOENIX_COLLECTOR_ENDPOINT	Phoenix OTLP endpoint (default http://localhost:4317)

Project structure

Only chronicle/ is the installable library. Demos and interactive benches stay under examples/; committed regression traces live in fixtures/.

chronicle/                 # installable package
├── boundary.py            # @boundary decorator (record + replay + cut-point)
├── session.py             # runtime session, on_crossing hook, stub/live modes
├── execution_graph.py     # side graph builder (load/save/render)
├── visualizer.py          # HTML trace UI (library + CLI)
├── envelope/              # schema, capture, append-only store
├── replay/                # ReplayPlan, ReplayInjector, structural assertions
├── judge/                 # Layer 2 rubric + LLM-as-judge runner
├── instrumentation/       # OpenInference + LangGraph hooks
└── cli.py
fixtures/                  # committed regression data (envelopes/ · traces/)
examples/                  # demos and test benches (not imported by the package)
scripts/                   # demo and test runners
tests/                     # unit + e2e

Contributing

Contributions are welcome. See CONTRIBUTING.md for dev setup, the DCO sign-off, and the record-and-replay reviewer checklist, and please read our Code of Conduct.

Security

Chronicle captures prompts, agent state, and retrieved context, so a recording can contain secrets. Turn on redaction before recording production traffic, so nothing sensitive reaches a committed fixture:

import chronicle

session = chronicle.reset_session()
session.redactors = chronicle.default_redactors()   # mask API keys, tokens, JWTs

Redaction runs at record time and keeps the structure your tests assert on (message roles, tool names, argument keys) while masking the values. Add your own (str) -> str redactors for PII. Read the data-handling guidance in SECURITY.md and report vulnerabilities privately per that policy.
