air-rs 0.1.0

High-performance, memory-fluid LLM inference engine — Rust speed, Python convenience.

Air.rs

S.L.I.P. — Slipstream Layer Inference Protocol
Run models larger than your VRAM — streaming weights from NVMe via mmap.

---

The Problem

Large language models don't fit in VRAM. A 70B-parameter model at FP16 needs 140 GB of GPU memory. Even quantized to Q4, that's 35 GB — more than an RTX 4090's 24 GB.

Current solutions force painful tradeoffs:

• CPU offloading — 10-50× slower inference
• Model parallelism — requires multiple expensive GPUs
• Aggressive quantization — degrades output quality

The Air.rs Solution

Air.rs implements S.L.I.P. (Slipstream Layer Inference Protocol): the GGUF file is memory-mapped but only one layer's worth of quantized weights is resident in physical RAM at any time. Weights stay compressed in GGUF block formats — QMatMul performs dequantize-on-the-fly during matrix multiplication.

  +--------------------------------------------------------------+
  |                     S.L.I.P. Pipeline                        |
  |                                                              |
  |  GGUF on NVMe --mmap--> Virtual Address Space (RSS ~ 0)     |
  |                              |                               |
  |  Per token, per layer:       v                               |
  |    prefetch(layer N+1)  <-- SSD reads ahead (madvise)        |
  |    load_layer(N)        <-- QTensor -> QMatMul (RSS += 1)    |
  |    transformer_block()  <-- quantized forward pass           |
  |    drop(weights)        <-- Rust drops QBlockWeights         |
  |    release(layer N-1)   <-- madvise(DONTNEED), pages freed   |
  +--------------------------------------------------------------+

  Steady-state RSS:  ~400 MB for 7B  |  ~1.5 GB for 70B
  (vs 4 GB / 40 GB file sizes)

Result: Run 70B+ models on a single consumer GPU with minimal RAM.

---

Install

Python (recommended)

pip install air-rs          # PyPI — abi3 wheel, Python ≥ 3.11

import air_rs

engine = air_rs.Engine.from_gguf("llama-3.2-3b-q4_k_m.gguf")
print(engine.generate("Explain attention in one sentence."))

Rust / CLI

cargo build --release
cargo run --release -- --model path/to/model.gguf --prompt "Hello!"

---

Features

Category	Feature
Core	Layer-streamed inference — one transformer block in memory at a time
Quantization	Weights stay in GGUF block format; QMatMul dequantizes during matmul (21 formats: F32→IQ4_XS)
File Format	GGUF, SafeTensors, PyTorch (.bin/.pt), ONNX — auto-detected
Memory	madvise / PrefetchVirtualMemory page control + mmap storage HAL
KV Cache	1-bit key + Q8 value compression; tiered eviction with triage scoring
OCS Attention	SageAttention3 FP4 E2M1 microscaling + KIMI linear O(N·D²) + per-head gating
OCS KV	QJL 1-bit JL-transform key compression + Fast cosine-merge compaction
OCS Eviction	HERMES hierarchical importance-score eviction (recency + density + position)
OCS Routing	ConceptMoE confidence-threshold adaptive top-1/top-k expert routing
Pipeline	Adaptive circular-buffer pipeline — overlaps NVMe reads, PCIe, GPU
API	OpenAI-compatible /v1/chat/completions (streaming SSE) via Axum
Compute	NVIDIA CUDA + AMD ROCm + Vulkan + Apple Metal + CPU backends
GPU Offload	STRIX 3-tier hierarchy (VRAM → RAM → Storage) with residency scoring
GPUDirect	NVMe → GPU DMA via cuFile FFI (zero CPU copies)
Multi-GPU	NVLink/PCIe peer-to-peer topology, layer-parallel + tensor-parallel sharding
Security	VRAM zeroing (hardware-native), bounds-checked pointers, owner tokens, audit log
Decoding	Speculative decoding (draft-verify acceleration, 2-3× speedup)
Ghost Drafting	Automated ghost model selection (1B/3B) with EMA-based adaptive batching
Scheduling	Continuous batching + adaptive request batcher (ARB)
Sampling	Temperature, top-p, top-k, repetition penalty, min-p
Tokenizer	BPE tokenizer built from GGUF vocabulary
Models	Llama 3 / 3.1 / 3.2, Mistral, Phi-3, Qwen2, Gemma — auto-detected from GGUF
GBNF	Grammar-constrained generation — JSON mode, integer, identifier, choice, raw
Model Hub	Download models from Hugging Face with SHA-256 verification
Monitoring	Real-time TUI dashboard + Prometheus-compatible metrics
Templates	Chat template engine (ChatML, Llama3, Mistral, Gemma, Phi-3)
Python	Production-ready PyO3 bindings — pip install air-rs
Benchmarks	Criterion throughput suite + 4-engine comparison harness (scripts/)

---

Python API

Install

pip install air-rs                          # from PyPI (abi3, Python ≥ 3.11)

# or build from source
pip install maturin
maturin develop --features python

Quick start

import air_rs

# Load any GGUF model
engine = air_rs.Engine.from_gguf("llama-3.2-3b-q4_k_m.gguf")

# Generate text
print(engine.generate("Explain attention in one sentence."))

# Custom sampling
cfg = air_rs.GenerateConfig(temperature=0.0, max_tokens=64)
print(engine.generate("2 + 2 =", config=cfg))

# Structured output — force valid JSON
cfg = air_rs.GenerateConfig(
    grammar=air_rs.GbnfConstraint.json_mode(),
    max_tokens=128,
)
print(engine.generate("Extract name and age from: Bob, 42", config=cfg))

# Constrain to a fixed set of words
cfg = air_rs.GenerateConfig(
    grammar=air_rs.GbnfConstraint.choice(["yes", "no", "maybe"]),
)
print(engine.generate("Is Python slow?", config=cfg))

# Performance metrics
m = engine.metrics()
print(f"{m.tokens_per_second:.1f} tok/s  |  TTFT {m.time_to_first_token_ms:.0f} ms")

# Chat template formatting
from air_rs.utils import format_chat

prompt = format_chat(
    [{"role": "user", "content": "Hello!"}],
    template="llama3",
)
print(engine.generate(prompt))

# Reset KV cache between conversations
engine.reset()

API reference

Symbol	Description
Engine.from_gguf(path, **sampler_defaults)	Load GGUF — CUDA if available, else CPU
Engine.generate(prompt, config=None)	Synchronous generation → str
Engine.stream_to_list(prompt, config=None)	Token list (wrap in run_in_executor for async)
Engine.set_grammar(constraint)	Attach persistent grammar for all calls
Engine.clear_grammar()	Remove persistent grammar
Engine.reset()	Clear KV cache between conversations
Engine.metrics()	Returns Metrics snapshot
GenerateConfig(max_tokens, temperature, top_p, top_k, stop_strings, grammar)	Per-call sampling config
GbnfConstraint.json_mode()	Force valid JSON output
GbnfConstraint.integer()	Single integer output
GbnfConstraint.identifier()	C-style identifier [a-zA-Z_][a-zA-Z0-9_]*
GbnfConstraint.choice(options)	Restrict to one of N strings
GbnfConstraint.from_grammar(src)	Raw GBNF grammar string
Metrics.tokens_per_second	Decode throughput
Metrics.time_to_first_token_ms	Prefill latency
Metrics.total_time_ms	Full generation wall time
format_chat(messages, template, add_generation_prompt)	ChatML / Llama3 / Mistral / Gemma / Phi-3
count_tokens_approx(text)	Fast token-count estimate (÷4 chars)

Supported models (Python + CLI)

Family	Architecture key	Tested
Llama 3 / 3.1 / 3.2	llama	✅ Q8 + Q4
Mistral / Mixtral	mistral	✅
Phi-3	phi3	✅
Qwen 2 / 2.5	qwen2	✅
Gemma / Gemma 2	gemma / gemma2	✅

---

Architecture

src/
├── main.rs              # CLI entry point (clap)
├── lib.rs               # Module declarations, constants
│
│── loader.rs            # GGUF parser — tensor offsets + model config
│── weight_streamer.rs   # S.L.I.P. core — mmap + per-layer QMatMul streaming
│── manifest.rs          # Execution planner — page-aligned DMA chunks
│── pipeline.rs          # Adaptive D-deep circular slot pipeline
│
│── model.rs             # Transformer block — QBlockWeights + forward pass
│── ops.rs               # Math ops — RMSNorm, RoPE, SiLU, GQA, softmax
│── generator.rs         # Inference loop — layer-streamed token generation
│── speculative.rs       # Speculative decoding (draft-verify)
│
│── kv_cache.rs          # KV-cache manager — RAM/VRAM shuttle
│── kv_tier.rs           # Tiered eviction policy (HERMES)
│── kv_compress.rs       # 1-bit key + Q8 value KV compression (M.I.S.T. v3)
│── ghost_drafting.rs    # Ghost model selection + ColdLog + prefetch
│
│── sampler.rs           # Token sampling — temperature/top-p/top-k/min-p
│── tokenizer.rs         # BPE tokenizer from GGUF vocabulary
│── chat_template.rs     # Chat template engine (ChatML/Llama3/Mistral/Gemma/Phi-3)
│── gbnf.rs              # GBNF grammar parser + stack machine
│
│── api.rs               # OpenAI-compatible HTTP API (Axum, SSE streaming)
│── scheduler.rs         # Continuous batching request scheduler
│── arb.rs               # Adaptive Request Batcher
│── metrics.rs           # Prometheus-compatible metrics collector
│── tui.rs               # Real-time terminal dashboard
│
│── ucal.rs              # Metal compute backend (macOS Apple Silicon)
│── gpu_pipeline.rs      # GPU pipeline orchestration
│── uploader.rs          # Async triple-buffered NVMe→VRAM transfers
│── orchestrator.rs      # VRAM pointer → Candle tensor hydration
│
│── model_hub.rs         # Hugging Face model downloader + SHA-256 verify
│── drive_inquisitor.rs  # Storage/compute profiler + protocol routing
│
│── python.rs            # PyO3 bindings (--features python)
│
└── strix/               # STRIX — Streamed Tensor Residence & Intelligent eXchange
    ├── mod.rs             # Module registry + re-exports
    │── types.rs           # Core types (GpuPtr, DType, ResidencyState, TensorClass)
    │── hal.rs             # HAL trait contracts + secure_zero_vram()
    │── config.rs          # Runtime configuration (StrixConfig)
    │── meta.rs            # Per-tensor metadata (TensorMeta)
    │── score.rs           # Residency scoring function R(t,τ)
    │── cpu_hal.rs         # CpuHal — host memory backend
    │── cuda_hal.rs        # CudaHal — NVIDIA CUDA Runtime API
    │── vulkan_hal.rs      # VulkanHal — Vulkan 1.2 + command buffer staging
    │── metal_hal.rs       # MetalHal — Apple Metal framework
    │── rocm_hal.rs        # ROCmHal — AMD ROCm/HIP
    │── gpu_alloc.rs       # RAII VRAM allocation + DMA staging
    │── gpu_tensor_view.rs # Lifetime-bound zero-copy VRAM tensor view
    │── arena.rs           # VRAM budget allocation (VramArena)
    │── registry.rs        # Central tensor tracking (TensorRegistry)
    │── scheduler.rs       # Residency tick loop (ResidencyScheduler)
    │── scheduler_thread.rs # Dedicated 2ms scheduler tick thread
    │── vram_pressure.rs   # 5-level VRAM pressure manager
    │── security.rs        # SecureAllocator, ShardedRwLock, BoundsCheckedPtr
    │── session.rs         # StrixSession — open(), open_unified()
    │── bridge.rs          # StrixBridge — high-level orchestrator
    │── cold_boot.rs       # Staged cold-start loading sequence
    │── compat.rs          # GGUF/UnifiedModel parser + tensor classification
    │── safetensors.rs     # SafeTensors format reader
    │── pytorch.rs         # PyTorch .bin/.pt reader (ZIP + pickle)
    │── onnx.rs            # ONNX protobuf reader
    │── io_engine.rs       # Priority async I/O queue
    │── async_io.rs        # Platform I/O: io_uring / IOCP + stress tests
    │── std_storage_hal.rs # Synchronous StorageHal fallback
    │── mmap_storage.rs    # MmapStorageHal with platform prefetch hints
    │── ram_pool.rs        # Recycling RAM buffer pool
    │── streamer_adapter.rs # WeightStreamer → STRIX adapter
    │── execution_cursor.rs # ExecutionCursor + MoE expert activation hook
    │── gpu_direct.rs      # GPUDirect Storage NVMe→GPU DMA integration
    │── cufile_ffi.rs      # cuFile API FFI bindings (cuda+linux)
    │── multi_gpu.rs       # Multi-GPU topology, NVLink, shard strategies
    │── backend_detect.rs  # Sub-100ms GPU/storage backend detection
    │── integration_tests.rs # Lifecycle, budget, inference simulation tests
    │── chaos_tests.rs     # Stress, fragmentation, edge case tests
    │── benchmarks.rs      # Scheduler, scoring, arena, I/O benchmarks
    └── e2e_validation.rs  # Real GGUF model end-to-end validation

65+ modules · ~32,000 lines of Rust · 976+ tests

---

Project Status

Beta — All subsystems implemented and tested (976+ tests, 0 warnings). Compiles on Windows, Linux, and macOS. All protocol specifications (STRIX, S.L.I.P., M.I.S.T. v3, DriveInquisitor v3) at 100% coverage. E2E validation passes against real Llama 3.2 3B Q8 GGUF models. Multi-model support (Llama/Mistral/Phi-3/Qwen2/Gemma), GBNF grammar-constrained generation, and production Python bindings (pip install air-rs) are all complete.

Current Status

Aspect	Status
Compiles on Windows / Linux / macOS	✅
Unit + integration tests (976+)	✅ All passing, 0 warnings
Multi-format model support	✅ GGUF, SafeTensors, PyTorch, ONNX
Multi-model auto-detection	✅ Llama / Mistral / Phi-3 / Qwen2 / Gemma
GBNF grammar-constrained generation	✅ JSON, integer, identifier, choice, raw
S.L.I.P. layer streaming engine	✅
Transformer forward pass (quantized)	✅
KV-cache + tiered HERMES eviction	✅
KV compression (1-bit key / Q8 value)	✅ M.I.S.T. v3
Ghost drafting + cold log	✅ M.I.S.T. v3
Speculative decoding	✅
OpenAI-compatible API	✅
STRIX GPU offloading (5 backends)	✅ CUDA / ROCm / Vulkan / Metal / CPU
GPUDirect Storage (cuFile FFI)	✅
Multi-GPU (NVLink / PCIe)	✅ Topology + layer/tensor sharding
VRAM security (hardware zeroing)	✅
Mmap storage HAL + prefetch	✅
DriveInquisitor v3	✅ Protocol routing matrix
E2E validation (Llama 3.2 3B real model)	✅
Criterion throughput benchmarks	✅
4-engine benchmark harness	✅ scripts/run_benchmarks.sh
Correctness validator vs llama.cpp	✅ scripts/validate_correctness.py
OCS — SageAttention3 FP4	✅ fp4_attention, ops.rs
OCS — KIMI Linear Attention	✅ linear_attention_kimi, ops.rs
OCS — Gated Attention	✅ gated_attention, ops.rs
OCS — QJL 1-bit KV Keys	✅ QjlKey, kv_compress.rs
OCS — Fast KV Compaction	✅ kv_compress.rs
OCS — HERMES Eviction	✅ HermesTierManager, kv_tier.rs
OCS — ConceptMoE Routing	✅ moe.rs
Python package (pip install air-rs)	✅ v0.1.0 on PyPI
CI/CD — multi-platform wheels	✅ manylinux / macOS / Windows
OIDC Trusted Publisher (no secret)	✅

STRIX Subsystem

STRIX (Streamed Tensor Residence & Intelligent eXchange) manages a 3-tier memory hierarchy (VRAM → RAM → Storage) with intelligent eviction scoring for 70B+ models on consumer GPUs.

Component	Status
Tensor registry + lifecycle	✅ Production
RAII VRAM allocations	✅ Production
CUDA HAL + cudaMemsetAsync zeroing	✅ Production
ROCm HAL (AMD GPUs)	✅ Production
Vulkan HAL + staging transfers	✅ Production
Metal HAL (Apple Silicon)	✅ Production
VRAM pressure manager (5 levels)	✅ Production
Security (bounds, audit log)	✅ Production
Zero-copy tensor views	✅ Production
Async I/O (io_uring / IOCP)	✅ Production
Multi-format model parsing	✅ Production
Mmap storage + prefetch	✅ Production
ExecutionCursor + MoE routing	✅ Production
GPUDirect Storage + cuFile FFI	✅ Production
Multi-GPU topology + NVLink	✅ Production
Layer-parallel + tensor-parallel	✅ Production
Sub-100ms backend detection	✅ Production
Integration + chaos tests	✅ Production
E2E validation (real models)	✅ Production

Roadmap

✅ Completed (v0.1.0 — Beta)

• E2E validation with real GGUF model (Llama 3.2 3B Q8)
• Performance benchmarks (scheduler, scoring, I/O)
• Multi-GPU topology and sharding strategies
• GPUDirect Storage FFI bindings
• Hardware-verified VRAM zeroing
• Validate output correctness against llama.cpp
• CUDA tested on RTX 3060 12 GB (CUDA 12.0) — docs/benchmarking_guide.md §7
• Tokens/sec measurement with full inference pipeline
• Multi-model support (Llama, Mistral, Phi-3, Qwen2, Gemma)
• GBNF grammar-constrained generation
• Python package release — pip install air-rs (PyPI v0.1.0)
• Multi-platform CI/CD (manylinux + macOS + Windows wheels)
• OIDC Trusted Publisher (no long-lived secrets)

✅ Completed (v0.2.0)

• Flash Attention 2 kernel integration — #[cfg(feature="flash-attn")] fused attention in ops.rs with causal masking via candle_flash_attn
• Python token streaming — engine.stream_to_list(prompt) returns ordered token list; wrap in asyncio.run_in_executor for non-blocking use
• Model download shorthand — model_hub::download_model() + parse_model_spec() + ModelRegistry with alias lookup (air pull TheBloke/Llama-2-7B-GGUF)
• Quantized KV-cache — 1-bit key compression + Q8 value quantization (BF16→Q8, 2× compression) fully implemented in M.I.S.T. v3 (kv_compress.rs)
• ROCm backend — src/strix/rocm_hal.rs fully implements GpuHal via AMD HIP Runtime API FFI, feature-gated as --features rocm

🔜 Next (v0.3.0)

• LoRA / PEFT adapter loading from GGUF (standalone fine-tuned adapters, not RWKV internal decay)
• Native async Python streaming iterator (async for token in engine.astream(prompt) without executor)
• Vision / multimodal input (llava, moondream, image tokens)
• air-rs CLI tool (standalone binary wrapping the Rust engine)
• Windows ROCm validation (HIP on Windows + AMD GPU hardware test)

---

Build

Build Scripts (Recommended)

Air.rs ships two platform-native build scripts that auto-detect hardware and run cargo build.

Platform	Script	Shell
Windows	build_air.ps1	PowerShell
macOS / Linux	build_air.sh	bash

# macOS / Linux
chmod +x build_air.sh
./build_air.sh               # interactive feature selection
./build_air.sh --skip-prompt # auto-enable everything detected
./build_air.sh --debug       # debug build
./build_air.sh --features cuda,flash-attn

# Windows
.\build_air.ps1
.\build_air.ps1 -SkipPrompt
.\build_air.ps1 -DebugBuild

Manual Build

Prerequisites

	Windows 11	Linux	macOS
Rust	1.75+ via rustup.rs	1.75+ via rustup	1.75+ via rustup
C++ Toolchain	VS 2022 (Desktop C++ workload)	build-essential	Xcode CLI Tools
GPU (optional)	CUDA 12.x + NVIDIA GPU	CUDA 12.x + NVIDIA GPU	Metal (Apple Silicon)

# Linux — CPU
sudo apt install -y build-essential pkg-config libssl-dev
cargo build --release

# Linux — NVIDIA GPU
export CUDA_HOME=/usr/local/cuda
cargo build --release --features cuda,flash-attn

# macOS — Apple Silicon
xcode-select --install
cargo build --release --features metal

# Windows (from VS Developer Command Prompt)
.\setup_build_env.ps1
cargo build --release --features cuda,flash-attn

Feature Flags

Flag	What It Enables	Platforms
cuda	NVIDIA GPU via CUDA Runtime API (STRIX CudaHal)	Windows, Linux
rocm	AMD GPU via ROCm/HIP (STRIX ROCmHal)	Linux
vulkan	Vulkan 1.2 GPU compute (STRIX VulkanHal)	Windows, Linux
flash-attn	Flash Attention 2 kernels	Windows, Linux
metal	Apple Metal GPU compute (STRIX MetalHal)	macOS
python	PyO3 Python bindings (pip install air-rs)	All

Run

# Basic generation
cargo run --release -- --model path/to/model.gguf --prompt "Hello, world!"

# Custom sampling
cargo run --release -- \
  --model path/to/model.gguf \
  --prompt "Tell me a joke" \
  --temperature 0.9 \
  --top-p 0.95 \
  --top-k 40 \
  --max-tokens 256

---

Troubleshooting

LNK1181: cannot open 'kernel32.lib' (Windows)

The Windows SDK LIB path is not set. Run the setup script:

.\setup_build_env.ps1

Or build from a VS Developer Command Prompt which sets paths automatically.

stdc++.lib not found (Windows + flash-attn)

build.rs auto-creates a stub stdc++.lib for MSVC. Clean and rebuild:

cargo clean && cargo build --release --features cuda,flash-attn

CUDA not detected

1. Verify: nvcc --version
2. Build with: cargo build --release --features cuda
3. Linux: export CUDA_HOME=/usr/local/cuda
4. Windows: echo $env:CUDA_PATH

Metal not available (macOS)

Metal requires Apple Silicon (M1/M2/M3/M4). On Intel Mac, use CPU build:

cargo build --release  # Accelerate framework still accelerates matmuls

externally-managed-environment (Python / pip)

Use a virtual environment:

python3 -m venv .venv
.venv/bin/pip install air-rs

Or with pipx: pipx install air-rs

---

How It Works

1. Parse — loader.rs reads GGUF header for tensor offsets, model config, tokenizer
2. Map — weight_streamer.rs opens file via mmap (virtual address space, RSS ≈ 0)
3. Stream — for each transformer layer:
   • prefetch_layer(N+1) — madvise / PrefetchVirtualMemory reads ahead from SSD
   • load_layer(N) — creates QTensor from mmap bytes, wraps in QMatMul
   • transformer_block() — attention + SwiGLU FFN using quantized matmul
   • drop(weights) — Rust drops QBlockWeights, frees heap
   • release_layer(N-1) — madvise(DONTNEED) / VirtualUnlock evicts pages
4. Cache — kv_cache.rs saves attention KV state; kv_tier.rs evicts cold entries
5. Sample — sampler.rs picks next token via temperature / top-p / top-k
6. Speculate — speculative.rs generates K tokens with draft model, verifies in batch

---

Acknowledgments

• candle — Rust ML framework with CUDA and quantized inference
• llama.cpp — GGUF format and quantization reference
• AirLLM — original layer-streaming concept in Python

License

MIT © Sunay Hegde
