No project description provided

Project description

(Aperture Masking Interferometry Calibration and Analysis Library)

PyPI Supported Python Versions Licence

CI CI (bleeding edge) status

Code style: black


$ python3 -m pip install amical

What can AMICAL do for you ?

AMICAL is developed to provide an easy-to-use solution to process Aperture Masking Interferometry (AMI) data from major existing facilities: NIRISS on the JWST (first scientific interferometer operating in space), SPHERE and VISIR from the European Very Large Telescope (VLT) and VAMPIRES from SUBARU telescope (and more to come).

We focused our efforts to propose a user-friendly interface, though different sub-classes allowing to (1) Clean the reduced datacube from the standard instrument pipelines, (2) Extract the interferometrical quantities (visibilities and closure phases) using a Fourier sampling approach and (3) Calibrate those quantities to remove the instrumental biases.

In addition (4), we include two external packages called CANDID and Pymask to analyse the final outputs obtained from a binary-like sources (star-star or star-planet). We interfaced these stand-alone packages with AMICAL to quickly estimate our scientific results (e.g., separation, position angle, contrast ratio, contrast limits, etc.) using different approaches (chi2 grid, MCMC, see for details).

Getting started

Looking for a quickstart into AMICAL? You can go through our tutorial explaining how to use its different features.

You can also have a look to the example scripts made for NIRISS and SPHERE or get details about the CANDID/Pymask uses with

⚡ Last updates (08/2022) : New example script for IFS-SPHERE data is now available here.

Use policy and reference publication

If you use AMICAL in a publication, we encourage you to properly cite the reference paper published during the 2020 SPIE conference: The James Webb Space Telescope aperture masking interferometer. The library explanation is part of a broader description of the interferometric mode of NIRISS, so feel free to have a look at the exciting possibilities of AMI!


This work is mainly a modern Python translation of the very well known (and old) IDL pipeline used to process and analyze Sparse Aperture Masking data. This pipeline, called "Sydney code", was developed by a lot of people over many years. Credit goes to the major developers, including Peter Tuthill, Mike Ireland and John Monnier. Many forks exist across the web and the last IDL version can be found here.

Project details

Download files

Download the file for your platform. If you're not sure which to choose, learn more about installing packages.

Source Distribution

amical-1.5.0.tar.gz (155.0 kB view hashes)

Uploaded source

Built Distribution

amical-1.5.0-py3-none-any.whl (165.5 kB view hashes)

Uploaded py3
