amiga-grn 0.1.0

Learning-to-rank for post-Pareto selection of consensus gene regulatory networks

AMIGA

AMIGA (Automated Multi-objective Individual GRN Assessment) is a Python package and command-line tool for ranking candidate consensus Gene Regulatory Networks (GRNs) produced by multi-objective evolutionary algorithms.

AMIGA acts as a post-Pareto decision layer. It learns from labelled benchmark fronts where candidate quality is known, and applies the trained ranker to new fronts where no gold standard is available.

The project is distributed on PyPI as amiga-grn; the import package and CLI entry point are both named amiga.

Installation

pip install amiga-grn

For local development:

git clone https://github.com/AdrianSeguraOrtiz/AMIGA.git
cd AMIGA
poetry install

Check the CLI:

amiga --help

What AMIGA Uses

AMIGA expects one row per candidate solution in a Pareto front. A training table usually contains:

• front_id: identifier of the Pareto front used as a learning-to-rank group;
• item_id: candidate identifier, generated when absent;
• a target column such as AUPR for labelled benchmark fronts;
• numerical predictors describing the candidate, objectives, expression context and consensus network.

At prediction time, the target column is not required. The new front must provide the same predictor schema expected by the trained model.

Quickstart

The usual AMIGA workflow is:

flowchart LR
    subgraph IN["Input files"]
        A(["Gold standard"])
        B["Front CSV"]
        T(["target_col<br/>e.g. AUPR"])
        C["Expression CSV"]
        D["Base GRNs<br/>GRN_*.csv"]
    end

    A -.-> T
    B -.-> T
    B --> E(["amiga build-data<br/>--target-col AUPR"])
    T -. "labelled benchmark" .-> E
    C --> E
    D --> E

    B --> F(["amiga build-data<br/>--allow-unlabeled"])
    C --> F
    D --> F

    E --> G["Labelled table<br/>target + features"]
    F --> H["Unlabelled table<br/>features only"]
    S{{"Required for ranking:<br/>same feature columns<br/>as the trained model"}}

    subgraph CV["Model selection"]
        I(["amiga train-cv"]) --> J(["amiga summarize-cv"]) --> K(["amiga plot-cv"])
    end

    subgraph FINAL["Final ranking"]
        L(["amiga train-full"]) --> M["trained model<br/>feature schema"]
        M --> N(["amiga rank-csv"])
    end

    G --> I
    G --> L
    H --> N
    S -.-> H
    S -.-> M
    N --> O["Ranked front<br/>score + rank"]

    classDef input fill:#eef6ff,stroke:#5083c7,color:#1d2b3a;
    classDef command fill:#14796f,stroke:#0a4f49,color:#ffffff,font-weight:bold;
    classDef artifact fill:#fff8e6,stroke:#d39b28,color:#3a2b10;
    classDef report fill:#f4edff,stroke:#8065bd,color:#2d2148;
    classDef chip fill:#fff3d9,stroke:#d39b28,color:#3a2b10;
    classDef note fill:#f8fafc,stroke:#64748b,stroke-dasharray: 4 3,color:#334155;
    classDef group fill:#ffffff,stroke:#cbd5e1,color:#334155;

    class B,C,D input;
    class A,T chip;
    class E,F,I,J,K,L,N command;
    class G,H,M,O artifact;
    class J,K report;
    class S note;
    class IN,CV,FINAL group;

1. Build AMIGA Tables

build-data is the main adapter between a consensus front and AMIGA. It takes a candidate table, the expression matrix used to generate the front, and the folder of base GRNs. The front table must contain one row per candidate and weight columns named like GRN_*.csv.

For labelled benchmark fronts:

amiga build-data front.csv expression.csv base_networks/ \
  --front-id 1 \
  --target-col AUPR \
  --out labelled_front.csv

For real or unlabelled fronts:

amiga build-data front.csv expression.csv base_networks/ \
  --front-id 1 \
  --allow-unlabeled \
  --out unlabelled_front.csv

build-data preserves candidate/objective columns, assigns front_id and item_id, extracts expression-level descriptors once per front, reconstructs each weighted consensus GRN from the base networks and appends network descriptors as grn_* columns. Useful options include:

• --drop-front-cols: remove columns from the original front before training;
• --threads: parallelize per-candidate consensus reconstruction;
• --target-col: choose the supervised quality column in labelled fronts;
• --allow-unlabeled: allow inference tables without a target column.

If you already have a complete AMIGA-compatible table, you can skip build-data and train directly from that CSV.

2. Train And Evaluate With Grouped CV

train-cv trains one model per fold using fronts as groups. This is useful for model selection, parameter tuning and reporting.

amiga train-cv labelled_fronts.csv \
  --model LGBMRanker \
  --label-mode continuous \
  --n-splits 5 \
  --model-params-json params.json \
  --out-dir cv_results/

Common options:

• --model: LGBMRanker, XGBRanker or CatBoostRanker;
• --label-mode: label construction strategy inside each front;
• --label-quantiles: number of bins when using quantile labels;
• --front-col, --target-col, --id-col: control-column names;
• --drop-cols: extra columns excluded from the feature matrix;
• --model-params-json: backend-specific hyperparameters;
• --random-state: base seed for reproducibility.

3. Summarise And Plot CV Results

summarize-cv aggregates one or more cv_report.json files into CSV tables.

amiga summarize-cv <cv_reports_dir>/*/cv_report.json \
  --out summary/ \
  --stats metric_rank_stats

plot-cv renders generic figures from the summaries:

amiga plot-cv --input-dir summary/ --plot dotplot_overview

Available plot names include dotplot_overview, topk_curves, metric_rank_heatmap and metric_scatter.

4. Train A Final Model

amiga train-full labelled_fronts.csv \
  --model LGBMRanker \
  --label-mode continuous \
  --model-params-json params.json \
  --out-dir trained_model/

train-full uses the complete labelled table and stores model.pkl, feature_columns.json and model metadata.

5. Rank A New Front

amiga rank-csv unlabelled_front.csv trained_model/model.pkl \
  --out-csv ranked_front.csv

When feature_columns.json is present next to the model, rank-csv uses the same feature order learned during training.

Optional Feature Utilities

extract-expr-features and extract-grn-features are standalone diagnostics for inspecting descriptor blocks. They are not required before build-data, because build-data calls the same feature extractors internally.

amiga extract-expr-features expression.csv --out expression_features.json
amiga extract-grn-features network.csv --out network_features.json

Rankers And Labels

AMIGA currently supports three tree-based learning-to-rank backends:

• LGBMRanker
• XGBRanker
• CatBoostRanker

Labels are constructed within each front, never across unrelated fronts. Supported label modes include continuous intra-front normalization, dense ranks, average ranks, quantiles and negative-control modes for validation experiments.

Ranker-specific hyperparameters can be passed with --model-params-json in training commands. This keeps AMIGA's CLI stable while still allowing advanced configuration of the underlying backend.

Reporting Metrics

train-cv evaluates rankings per front and then aggregates across fronts. The main top-k metrics include:

• Regret@k: gap between the best true quality in the front and the best true quality found among the top-k recommendations;
• BestAUPR@k: best true AUPR recovered in the top-k;
• Hit@k: whether at least one true best candidate appears in the top-k;
• NDCG@k, Spearman and Kendall as complementary ranking diagnostics.

This design focuses on the practical decision problem: placing high-quality candidate networks near the top of a short recommendation list.

Research Workflow

The installable amiga package contains the reusable software core: feature extraction, data construction, model training, cross-validation, reporting and ranking.

The repository also contains an article-oriented workflow called amiga-exp under scripts/experiments/amiga_exp/. It is not published as part of the PyPI package in this release. It is tied to the repository layout, versioned case manifests and publication plots, so it should be treated as a reproducible research protocol rather than as a stable public API.

To use it, clone the repository and install the experiment dependency group:

git clone https://github.com/AdrianSeguraOrtiz/AMIGA.git
cd AMIGA
poetry install --with experiments
scripts/experiments/amiga-exp --help

The expected case directory contains a data/ folder with data_*.csv files and an audit/ subfolder. The wrapper sets the repository on PYTHONPATH, so it can call the local amiga implementation without requiring a separate PyPI-only install.

Recommended command order:

scripts/experiments/amiga-exp inspect <case_dir>
scripts/experiments/amiga-exp validate <case_dir>
scripts/experiments/amiga-exp init-results <case_dir>
scripts/experiments/amiga-exp run-all <case_dir>
scripts/experiments/amiga-exp plot-all --case-dir <case_dir> --force

Useful lower-level commands:

scripts/experiments/amiga-exp run-phase <case_dir> 01_model_screening
scripts/experiments/amiga-exp run-phase <case_dir> 02_hyperparameter_tuning
scripts/experiments/amiga-exp run-phase <case_dir> final_test
scripts/experiments/amiga-exp run-phase <case_dir> 03_ablation
scripts/experiments/amiga-exp run-phase <case_dir> 04_decision_baselines
scripts/experiments/amiga-exp summarize-paper <case_dir>
scripts/experiments/amiga-exp plot-phase --case-dir <case_dir> --phase 01_model_screening

The standard phases are:

• 01_model_screening: compare ranker families and label modes;
• 02_hyperparameter_tuning: tune shortlisted configurations on development fronts;
• final_test: evaluate the frozen selected configuration on held-out fronts;
• 03_ablation: quantify feature-block contributions;
• 04_decision_baselines: compare AMIGA with post-Pareto decision baselines.

For now, amiga-grn[exp] is intentionally not provided. An optional PyPI extra would install dependencies, but it would not make the article-specific case manifests, plots and workflow a clean reusable API. If the experiment runner is generalized later, it should become either a documented extra or a separate research package.

See docs/experiments.md for the article-specific workflow.

Citation

If you use AMIGA, please cite the corresponding software release. A related manuscript is currently in preparation.

License

AMIGA is released under the MIT License.
