AnimatePlot
Making video from plot's
Examples
sigmoid function
import matplotlib.pyplot as plt
from animateplot import AnimatePlot as Ap
import numpy as np
plt.style.use('seaborn')
def sig(x):
return 1/(1+np.exp(-x))
x = np.linspace(-10,10,100)
y = sig(x)
def call_plt(it,plt):
plt.plot(x[:it],y[:it])
plt.title('sigmoid function')
plt.xlabel('x')
plt.ylabel('y')
plt.xlim(-10,10)
plt.ylim(0,1)
return plt
anime = Ap(x,callback_plot=callback_plot)
anime.render_cache()
anime.render_mp4('sigmoid.mp4',fps=15)
results:
Example 2
from animateplot import AnimatePlot as ap
import numpy as np
x = np.linspace(0,10,100)
def call(i,plt):
s = x[:i]
plt.xlim(x[0],x[-1])
plt.ylim(x[0]**2,x[-1]**2)
plt.plot(s,s**2)
return plt
animat = ap(x,call)
animat.render_cache()
animat.render_mp4(path_video="test_2.mp4",fps=15)
