anisodactyl 0.1.0

One CRUD to rule them all

Anisodactyl

One CRUD to rule them all.

This tries to solve the following problems:

• Headless CRUD Wrapper - Programmatic and configurable CRUD system for models.
• Automatic CRUD API Endpoints - Create, Get, Get All, Patch Update and Delete REST API Endpoints for any database table.
• Schema Driven URL Sorting and Filtering - URL based sorting and filtering automatically available to all properties listed in schema.
• Swappable URL Conventions - Pick and choose between different URL conventions.
• Nested Database Mutations - Generic CRUD for nested databases. Eliminate N+1 network requests.

👀 Vision

A typical CRUD interfaces db structure in a way where each table is a node:

Parent? --- Current --< Children?

Every table in your interconnected database sits at the center of it's own relationship graph; optional Parent pointing inwards and optional Children pointing outwards.

graph TD

c1(
  <b>Child 1</b>
  Timetable
  Appointments
)
c2(
  <b>Child 2</b>
  Schedule
  Designations
)
c3(
  <b>Child N</b>
  Address
  Contacts
)
s(
  <b>Self</b>
  Staffs,Teachers
  Employees,Trainees
  Students,etc.
)
p(
  <b>Parent</b>
  Company
  School
  Library
  Bakery
  etc.
)

c1 & c2 & c3 === s === p

The diagram above forms the shape of an anisodactyl "crow foot" - digits (children), hallux (parent), connected through the central tarsometatarsus self.

Current object can be anything. It can be one of the children as well, being able to create any graph like structure imaginable.

📚 Notes

Query Parameter Conventions

JSON API

// ?filter[key_name][operator]=value&[key_name][operator]=value
?filter%5Bkey_name%5D%5Boperator%5D=value&%5Bkey_name%5D%5Boperator%5D=value

but [ and ] gets encoded into %5B and %5D which makes URLs ugly and unreadable.

Django REST Framework

// ?post_tag=fiction&comment_count__gt=10
?key_name__operator=value&key_name__operator=value

The python standard due to Django influence.

Anisodactyl

// ?post_tag=fiction&comment_count=gt:10
?key_name=operator:value&key_name=operator:value
// ?fields=name,email
?fields=key1,key2,key3
// ?sort=-name
?sort=-field,field

Super clean, simple and developer centric.
