arca-agent 0.3.1

ARCA — Recursive GNN+RL Autonomous Cyber Agent with Local LLM reflection

ARCA — Autonomous Reinforcement Cyber Agent

A fully local, pip-installable RL-powered cyber pentesting simulation framework featuring GNN policies, curriculum learning, mixed-precision PPO, persistent memory with RAG, local LLM reflection, self-play evaluation, offline RL, and an interactive Dash visualizer.

---

What is ARCA?

ARCA trains autonomous agents to discover and exploit vulnerabilities in synthetic computer networks using Graph Neural Networks + Reinforcement Learning. It provides a complete local red-team simulation pipeline — from training and curriculum progression, to LLM-guided reflection, interactive visualization, and automated security reports.

Everything runs 100% locally. No external APIs, no data leaving your machine.

---

What's New in v3.6 (vs. the old SB3-based version)

Area	Before (v0.2.x)	Now (v3.6)
RL Engine	Stable-Baselines3 (PPO/A2C/DQN)	Custom CleanRL-style PPO, purpose-built for graph observations
Policy	Flat MLP via SB3	3-layer GCN/GATv2 with dual graph pooling — understands network topology natively
Curriculum	None	5-tier progressive training: micro → small_office → medium → hard → enterprise
Action Masking	None	Dynamic AMP-safe masking — prevents invalid actions across all curriculum tiers
Training Speed	Standard	Mixed Precision (AMP) on CUDA + --fast mode for rapid iteration
Memory	None	EpisodeBuffer + VectorMemory (FAISS/numpy RAG) with lifelong reward shaping
LLM Reflection	Basic LangGraph over Ollama/Groq	Local Llama-3.2-3B (fully offline, GGUF, GPU offload) with RAG-enriched prompts and ethical framing
Self-Play	None	BlueTeamDefender patches vulnerabilities and adds firewalls between rounds
Offline RL	None	Behavioral Cloning fine-tune on top-K episodes from the replay buffer
Visualizer	Static Plotly/Matplotlib files	Interactive Dash dashboard: real-time topology, attack replay, clickable host details, live metrics
Reporting	None	Automated markdown reports: executive summary, attack chains, lessons, remediation checklist
C++ Backend	pybind11 BFS/Floyd-Warshall	Preserved as optional accelerator with graceful pure-Python fallback
API	Basic FastAPI stub	Full REST server: /train, /audit, /reflect, /presets

---

Installation

From PyPI (Recommended)

pip install arca-agent[all]

From Source (Development)

git clone https://github.com/DipayanDasgupta/arca.git
cd arca

python -m venv venv
source venv/bin/activate      # Windows: venv\Scripts\activate

pip install -e ".[all]"       # All extras: GPU, SB3, C++, Dash, Groq
pip install -e ".[dev]"       # Dev tools: pytest, black, ruff, mypy

GPU note: CUDA 11.8+ recommended for AMP mixed-precision training (~30–40% speedup). CPU fallback works seamlessly on all platforms.

C++ note: If g++ or clang is available, the BFS/Floyd-Warshall extension builds automatically. Otherwise ARCA uses the pure-Python fallback silently.

---

Quick Start

Recommended first run

# Fast curriculum run with local LLM + interactive visualizer
python quickstart_v3.py --curriculum --local-llm --fast --viz

The Dash dashboard launches automatically at http://127.0.0.1:8051.

Other useful invocations

# Full run: curriculum + self-play + offline RL (no viz)
python quickstart_v3.py --curriculum --local-llm --self-play --offline-rl

# Skip curriculum, train directly on enterprise preset
python quickstart_v3.py --preset enterprise --no-curriculum

# Direct red-team framing (advanced — skips ethical guardrails in prompts)
python quickstart_v3.py --local-llm --no-ethical

# Profile with TensorBoard
tensorboard --logdir arca_outputs/tensorboard

Python API

from arca import ARCAAgent, NetworkEnv, ARCAConfig

# Load a preset environment
env = NetworkEnv.from_preset("small_office")

# Train with the GNN + CleanRL-PPO pipeline (default)
agent = ARCAAgent(env=env)
agent.train(timesteps=50_000)

# Run a masked, deterministic evaluation episode
result = agent.run_episode()
print(result.summary())

# Curriculum training — auto-advances through 5 difficulty tiers
history = agent.run_curriculum(timesteps_per_tier=30_000)

# Enable semantic memory (FAISS RAG over past episodes)
agent.enable_vector_memory()

# LangGraph reflection with RAG-enriched LLM prompts
agent.enable_langgraph()
report = agent.reflect(env.get_state_dict())
print(report["plan"])
print(report["remediation"])

CLI

arca train --timesteps 50000 --preset small_office
arca audit --preset small_office --langgraph
arca viz --output ./figures
arca serve                         # FastAPI REST server on :8000
arca scan --subnet 192.168.1       # Discover local Ollama endpoints
arca info                          # Version, CUDA, SB3 status

---

Network Presets

Preset	Hosts	Subnets	Vuln Density	Max Steps
small_office	8	2	~50%	150
enterprise	25	5	~35%	300
dmz	15	3	~45%	200
iot_network	20	4	~60%	250

Custom topologies can be defined in YAML via CustomNetworkBuilder:

from arca.sim.custom_network import CustomNetworkBuilder

# Generate a YAML template, edit it, then load
CustomNetworkBuilder.generate_template("my_network.yaml", preset="home")
env = CustomNetworkBuilder.from_yaml("my_network.yaml")

The YAML CVE library includes: EternalBlue, Log4Shell, BlueKeep, ZeroLogon, PrintNightmare, PwnKit, Spring4Shell, IoTDefaultCreds, Shellshock, Heartbleed, RouterDefaultPwd, SQLInjection, and more.

---

Curriculum Learning

ARCA trains through five progressive difficulty tiers. The scheduler advances the agent when performance exceeds a reward or goal-rate threshold (OR logic), and demotes it if performance drops.

Tier	Hosts	Firewalled Subnets	Promote (reward ≥)	Window
micro	4	0	700	8 eps
small_office	8	0	600	15 eps
medium	12	1	500	20 eps
hard	18	2	400	25 eps
enterprise	25	3	— (max tier)	30 eps

history = agent.run_curriculum(
    timesteps_per_tier=30_000,
    eval_episodes=10,
    start_tier=0,
    max_tiers=5,
)

---

Actions

Action	Description
SCAN	Discover reachable hosts and enumerate their services and CVEs
EXPLOIT	Attempt to compromise a discovered host using a specific CVE
PIVOT	Relocate the attacker's foothold to a compromised host
EXFILTRATE	Extract data value from a compromised host

Action masking ensures the policy only selects actions that are valid given the current network state, host discovery status, and exploit availability. The mask is computed dynamically each step and is safe to use under mixed-precision (fp16) training.

---

Core Components

arca.core — Training Engine

• GNNPolicy — 3-layer GCN (or GATv2) with dual mean+max global pooling, orthogonal init, and masked actor-critic head. AMP-safe: fill values for masked logits are computed from torch.finfo(logits.dtype).min / 2 to avoid fp16 overflow.
• CleanRLPPO — Custom PPO trainer with rollout buffer, GAE, gradient clipping, AMP autocast, TensorBoard logging, and reflection callbacks.
• ARCATrainer — Wraps Stable-Baselines3 for the non-GNN path (PPO/A2C/DQN) with EvalCallback and CheckpointCallback.
• ARCAAgent — High-level interface for training, evaluation, curriculum, save/load, and reflection.
• ARCAConfig — Dataclass-based config covering env, RL, LLM, memory, offline RL, reporting, API, and visualization.

arca.sim — Network Simulation

• NetworkEnv — Gymnasium-compatible environment with presets, procedural generation, action masking, PyG data export, and LLM reward shaping hooks.
• CustomNetworkEnv — User-defined YAML topologies with a rich CVE library and subnet-level firewall simulation.
• NetworkGenerator — Procedural OS/service/CVE assignment with realistic subnet topology.
• Host, Action, ActionResult — Core simulation primitives.

arca.training — Advanced Training Utilities

• CurriculumScheduler — OR-logic promotion (goal rate or mean reward), demotion protection, per-tier entropy coefficient tuning.
• SelfPlayEvaluator — Red vs. blue rounds: the BlueTeamDefender patches top CVEs, adds firewalls to neighbours, and reduces exploit probabilities between rounds.
• offline_bc_finetune — Behavioural cloning on the top-K episodes from the replay buffer, reconstructing (obs, action) pairs by replaying stored attack paths.

arca.memory — Persistent Episodic Memory

• EpisodeBuffer — JSON-persisted ring buffer (up to 1000 episodes) with reward/goal-rate stats, attack-path fingerprinting, and infer_reward_mods() for heuristic shaping.
• VectorMemory — 13-dimensional episode embeddings (reward, compromise ratio, efficiency, OS fingerprint, severity, path length) indexed by FAISS or pure numpy. Semantic search feeds the top-k most similar past episodes into every LLM prompt as RAG context.

arca.agents — LangGraph Orchestrator

Six-node multi-agent graph: analyst → attacker → critic → reflector → planner → remediator.

• Local-first LLM priority: LocalLLM (llama-cpp-python GGUF) → Ollama → Groq → rule-based fallback.
• Ethical framing: All system prompts include an authorized-assessment header that prevents small models from refusing to respond.
• Refusal detection: Responses matching known refusal phrases automatically fall back to rule-based output.
• RAG injection: VectorMemory semantic search results are prepended to every node's user prompt.

arca.llm — LLM Providers

• LocalLLM — llama-cpp-python wrapper supporting Llama-3.2-3B-Q4, Phi-3-mini, and Gemma-2-2B. GPU offload via n_gpu_layers=-1. C-level stderr noise suppressed via OS-level fd redirect.
• auto_detect_provider() — Priority chain: Ollama → Groq → Anthropic → OpenAI → rule-based.

arca.viz — Visualization

• ARCAVisualizer — Static Plotly network topology, vulnerability heatmap, attack path overlay, and training curves (HTML output).
• Interactive Dash Dashboard — Real-time network graph with status coloring, clickable host details, live reward/compromise metrics, curriculum progress, and attack replay controls. Launch with --viz.

arca.reporting — Automated Reports

ARCAReportGenerator assembles a markdown report with: executive summary, curriculum progression table, top episode attack chains, LLM lessons learned, self-play results, offline RL stats, and a defensive remediation checklist.

arca.graph — LLM Red-Team Workflow

Separate from the RL simulation — adversarially red-teams an LLM target using a LangGraph attacker/evaluator/defender/reporter loop. Tests 8 attack vectors: direct_prompt_injection, role_play_hijack, system_prompt_extraction, pii_extraction, jailbreak_prefix, indirect_rag_injection, delimiter_confusion, context_overflow.

arca.api — REST Server

FastAPI server (arca serve) exposing /train, /audit, /reflect, /presets, and /status. CORS-enabled, fully self-contained.

arca.cpp_ext — C++ Acceleration (Optional)

pybind11 module exposing compute_reachability (BFS), floyd_warshall, and batch_exploit. Built automatically if a C++ compiler is present; otherwise all three fall back to pure Python transparently.

---

Project Structure

arca/
├── arca/
│   ├── agents/
│   │   └── langgraph_orchestrator.py   # 6-node LangGraph multi-agent graph
│   ├── api/
│   │   └── server.py                   # FastAPI REST interface
│   ├── cli/
│   │   └── main.py                     # Typer CLI (train/audit/viz/serve/scan/info)
│   ├── core/
│   │   ├── agent.py                    # High-level ARCAAgent
│   │   ├── cleanrl_ppo.py              # CleanRL PPO trainer (AMP, masking, memory)
│   │   ├── config.py                   # Dataclass config (env/rl/llm/memory/report/…)
│   │   ├── gnn_policy.py               # GNNEncoder + masked actor-critic (AMP-safe)
│   │   └── trainer.py                  # SB3 trainer (non-GNN path)
│   ├── cpp_ext/
│   │   ├── __init__.py                 # Graceful fallback loader
│   │   └── sim_engine.cpp              # BFS, Floyd-Warshall, batch_exploit
│   ├── graph/
│   │   └── workflow.py                 # LLM red-team LangGraph workflow
│   ├── llm/
│   │   ├── local_llm.py                # llama-cpp-python wrapper + stderr suppression
│   │   └── providers.py                # Ollama / Groq / Anthropic / OpenAI / rule-based
│   ├── memory/
│   │   ├── episode_buffer.py           # JSON-persisted ring buffer
│   │   └── vector_memory.py            # FAISS/numpy semantic episode search
│   ├── reporting/
│   │   └── report_generator.py         # Automated markdown reports
│   ├── sim/
│   │   ├── action.py
│   │   ├── custom_network.py           # YAML topology builder + CVE library
│   │   ├── environment.py              # NetworkEnv (Gymnasium, masking, PyG)
│   │   ├── host.py
│   │   └── network_generator.py        # Procedural network generation
│   ├── targets/
│   │   └── connectors.py               # OllamaTarget, OpenAICompatibleTarget, EchoTarget
│   ├── training/
│   │   ├── curriculum.py               # CurriculumScheduler (5 tiers, OR-logic)
│   │   ├── offline_rl.py               # Behavioral cloning from replay buffer
│   │   └── self_play.py                # Red-blue self-play + BlueTeamDefender
│   ├── utils/
│   │   └── __init__.py
│   └── viz/
│       └── visualizer.py               # Plotly + Dash visualizations
├── examples/
│   ├── quickstart.py
│   └── test_my_network.py
├── tests/
│   ├── conftest.py
│   ├── test_arca.py
│   └── test_comprehensive.py
├── quickstart_v3.py                    # Main entry point with all flags
├── pyproject.toml
├── setup.py
└── README.md

---

Configuration

ARCA is fully configuration-driven. The main dataclass is ARCAConfig:

from arca.core.config import ARCAConfig

cfg = ARCAConfig.default()

# Environment
cfg.env.preset = "small_office"
cfg.env.num_hosts = 8

# RL
cfg.rl.use_gnn = True
cfg.rl.gnn_hidden_dim = 128
cfg.rl.learning_rate = 3e-4
cfg.rl.ent_coef = 0.05

# LLM
cfg.llm.use_local_llm = True
cfg.llm.local_model_key = "llama-3.2-3b"
cfg.llm.ethical_mode = True

# Memory
cfg.memory.enabled = True
cfg.memory.seed_reward_mods_from_memory = True

# Save/load YAML
cfg.to_yaml("my_config.yaml")
cfg2 = ARCAConfig.from_yaml("my_config.yaml")

---

LLM Provider Setup

ARCA auto-detects the best available provider (local-first):

# Option 1: Fully local (no internet required after download)
# Model downloads automatically to ~/.arca/models/ on first use
python quickstart_v3.py --local-llm

# Option 2: Ollama (local server)
curl -fsSL https://ollama.com/install.sh | sh
ollama pull llama3.2:3b
ollama serve
# ARCA detects Ollama automatically

# Option 3: Groq (free API, very fast)
export GROQ_API_KEY=gsk_...   # console.groq.com
# ARCA detects GROQ_API_KEY automatically

# Option 4: Always-available rule-based fallback (no setup needed)
# Used automatically when no LLM is configured

---

Running Tests

pytest tests/ -v                          # All tests
pytest tests/ -v -k "not slow"            # Skip real network tests
pytest tests/test_comprehensive.py -v     # LangGraph workflow tests only

---

Disclaimer

ARCA is an educational and research simulation tool only.

• All attacks and simulations occur in a fully sandboxed, in-memory graph.
• It does not perform real network scanning, exploitation, or generate real network traffic.
• Use only on networks you are authorized to test.

---

Author

Dipayan Dasgupta — IIT Madras, Civil Engineering GitHub · LinkedIn
