ariadnepy 0.2.0

Python interface to the ariadne multi-omic knowledge graph

ariadnePy: a Python interface to the ariadne database network

ariadnePy brings the biological database integration and graph-theory tools of the R package ariadne to Python users. It downloads biological resources (Gene Ontology, KEGG, UniProt, BugSigDB, ChocoPhlAn, and more) from Zenodo and assembles them into a single igraph Graph that can be queried, filtered, and visualised directly in Python.

---

Installation

pip install ariadnepy

RDS-backed resources (e.g. MSigDB) are supported out of the box — pyreadr is installed as a core dependency.

To also use the AnnData integration helpers (add_modules, get_modules, process_gene_families):

pip install "ariadnepy[anndata]"

For development:

git clone https://github.com/Minotau-R/ariadnePy
cd ariadnePy
pip install -e ".[dev]"

---

Quick start

import ariadnepy

# Build the knowledge graph using default resource versions
# (downloads GML files from Zenodo on first run; cached locally afterwards)
graph = ariadnepy.ariadne()

print(graph)
# IGRAPH U--- <N vertices> <M edges> --

# List all available resource versions
df = ariadnepy.list_resource_versions()
print(df.head())

# Select specific versions
graph = ariadnepy.ariadne(versions={"GO": "2026-01-23", "KEGG": "latest"})

# Explore a few candidate paths between two resources
ariadnepy.search_path(graph, "ko ~ ec", k=3)

# Weave a linkmap along a chosen path
linkmap = ariadnepy.weave_path(graph, "taxname ~ bugsig", init=["s__Bacteroides_fragilis"])

# weave_path / weave_complex also accept an existing pathway DataFrame
# (e.g. from draw_path(), or the bundled pathMeta example) instead of the
# full graph, skipping path search entirely and re-running just those steps:
pathmeta = ariadnepy.load_pathmeta()
chebi2gmm = ariadnepy.weave_path(pathmeta, init=[15377, 30616, 4167])

# Visualise a path on the graph
fig = ariadnepy.plot_path(graph, "ko ~ ec", k=1)
fig.savefig("path.png")

---

Supported resources

Resource	Description
GO	Gene Ontology
KEGG	KEGG Pathways & Modules
UniProt	UniProt protein database
OTT	Open Tree of Life Taxonomy
Rhea	Rhea biochemical reactions
WoL	Web of Life phylogenetic tree
TIGRFAMs	TIGRFAM protein families
GM	Gut Metabolic Modules
BugSigDB	Bug Signatures Database
ChocoPhlAn	MetaPhlAn gene families
MSigDB	Molecular Signatures Database

Run ariadnepy.list_resource_versions() for the exact versions available at any time.

---

Project structure

ariadnePy/
├── src/
│   └── ariadnepy/
│       ├── __init__.py        # public API
│       ├── core/               # ariadne() graph builder, GML download/cache, resource versions
│       ├── graph/               # weave_path, weave_complex, draw_path, search_path, link_names
│       ├── io/                  # SPARQL (UniProt/Rhea) and Open Tree of Life query backends
│       ├── plot/                 # plot_path, add_resource
│       ├── resources/             # resource file caching/parsing, bundled example datasets
│       ├── anndata/                # AnnData integration (add_modules, get_modules, process_gene_families)
│       └── exceptions.py
├── tests/                          # mirrors the src/ package layout
├── pyproject.toml
└── README.md

---

Running tests

pytest

---

License

Artistic License 2.0, matching the ariadne R package.
