Overview

arize-otel provides Arize-aware OpenTelemetry defaults for instrumenting LLM applications and exporting their traces to Arize.

Uploading large blobs from OpenInference

OpenInference instrumentors can capture images as base64-encoded span attributes. arize-otel can upload oversized images to Arize and replace the inline content with a lightweight arize:// reference. This avoids sending large image payloads through the trace exporter while preserving the image in Arize.

Blob uploading requires Python 3.10 or newer and openinference-instrumentation>=0.1.56. Python 3.8 and 3.9 remain supported for tracing without blob uploading.

For zero-code configuration, set the normal Arize tracing variables and select the registered uploader:

export ARIZE_API_KEY="..."
export ARIZE_SPACE_ID="..."
export ARIZE_PROJECT_NAME="my-project"
export OPENINFERENCE_BLOB_UPLOADER="arize"

Use OPENINFERENCE_BASE64_IMAGE_MAX_LENGTH to configure the maximum image data URI length that OpenInference keeps inline.

You can also configure the uploader explicitly:

from arize.otel import ArizeBlobUploader
from openinference.instrumentation import TraceConfig

config = TraceConfig(blob_uploader=ArizeBlobUploader())

Uploads run in the background after a bounded one-second grant request. If a grant cannot be obtained, OpenInference falls back to redacting the oversized value. A failure after an arize:// reference has been emitted is logged but cannot rewrite the exported span.

Use ARIZE_BLOB_ENDPOINT to override the blob upload endpoint independently of ARIZE_COLLECTOR_ENDPOINT, such as for an on-prem deployment. The uploader also honors set_routing_context(...) for applications that route traces dynamically between spaces and projects.

Installation

Install arize-otel using pip

pip install arize-otel

Quickstart

The arize.otel module provides a high-level register function to configure OpenTelemetry tracing by returning a TracerProvider. The register function can also configure headers and whether or not to process spans one by one or by batch.

The following examples showcase how to use register to setup Opentelemetry in order to send traces to a collector. However, this is NOT the same as instrumenting your application. You can instrument installed OpenInference instrumentors automatically with auto_instrument=True, or manually call a specific instrumentor after register.

Automatically instrument installed OpenInference packages

Set auto_instrument=True to discover installed OpenInference instrumentors and call instrument(tracer_provider=...) for each one:

from arize.otel import register

tracer_provider = register(
    space_id="your-arize-space-id",
    api_key="your-arize-api-key",
    project_name="your-model-id",
    auto_instrument=True,
)

auto_instrument=True only instruments libraries with a corresponding OpenInference instrumentation package installed in your Python environment.

To instrument one library explicitly instead, run instrument() after using register:

from arize.otel import register
# Setup OTel via our convenience function
tracer_provider = register(
    # See details in examples below...
)

# Instrument your application using OpenInference AutoInstrumentators
from openinference.instrumentation.openai import OpenAIInstrumentor
OpenAIInstrumentor().instrument(tracer_provider=tracer_provider)

The above code snippet will yield a fully setup and instrumented application. It is worth noting that this is completely optional. The usage of this package is for convenience only, you can set up OpenTelemetry and send traces to Arize without installing this or any other package from Arize.

In the following sections we have examples on how to use the register function:

Add pre-export span processors

Some OpenInference integrations, such as processor-style integrations that transform native OpenTelemetry spans into OpenInference attributes, expose a SpanProcessor instead of an instrument() method. Pass those processors to register(span_processors=[...]) so they run before the Arize exporter while register continues to configure Arize authentication headers, endpoint, transport, batching, and project metadata:

from arize.otel import register
from openinference.instrumentation.pydantic_ai import OpenInferenceSpanProcessor

tracer_provider = register(
    space_id="your-arize-space-id",
    api_key="your-arize-api-key",
    project_name="your-model-id",
    span_processors=[OpenInferenceSpanProcessor()],
)

Use span_processors for processors that enrich or transform spans before export. You do not need to create a separate Arize SpanExporter just to preserve Arize headers.

Send traces to Arize

To send traces to Arize you need to authenticate via the Space ID and API Key. You can find them in the Space Settings page in the Arize platform. In addition, you'll need to specify the project name, a unique name to identify your project in the Arize platform.

from arize.otel import register

tracer_provider = register(
    space_id = "your-arize-space-id",
    api_key = "your-arize-api-key",
    project_name = "your-model-id",
)

If you are located in the European Union, you'll need to specify the corresponding Endpoint (the default endpoint is Endpoint.ARIZE):

from arize.otel import register, Endpoint

tracer_provider = register(
    endpoint=Endpoint.ARIZE_EUROPE,
    space_id = "your-arize-space-id",
    api_key = "your-arize-api-key",
    project_name = "your-model-id",
)

If you would like to configure your tracing using environment variables instead of passing arguments, read Using Environment Variables.

Send traces to Custom Endpoint

Sending traces to a collector on a custom endpoint is simple, you just need to provide the endpoint as a string. In addition, it is worth noting that the default is to use a GRPCSpanExporter. If you'd like to use a HTTPSpanExporter instead, specify the transport as shown below:

from arize.otel import register

tracer_provider = register(
    endpoint = "https://my-custom-endpoint"
    # any other options...
)

Specify exporter type

If you're using endpoints from the Endpoint enum, you do not need to do this, since we know what exporter to use. However, if you're using a custom endpoint, it is worth noting that the default is to use a GRPCSpanExporter. If you'd like to use a HTTPSpanExporter instead, specify the transport as shown below:

from arize.otel import register, Transport

tracer_provider = register(
    endpoint = "https://my-custom-endpoint"
    transport = Transport.HTTP,
    # any other options...
)

Turn off batch processing of spans

We default to using BatchSpanProcessor from OpenTelemetry because it is non-blocking in case telemetry goes down. In contrast, "SimpleSpanProcessor processes spans as they are created." This can be helpful in development. You can use SimpleSpanProcessor with the option use_batch_processor=False.

from arize.otel import register

tracer_provider = register(
    # other options...
    batch=False
)

Debug

As you're setting up your tracing, it is helpful to print to console the spans created. You can achieve this by setting log_to_console=True.

from arize.otel import register

tracer_provider = register(
    # other options...
    log_to_console=True
)

Routing Traces to Different Arize Spaces and Projects

The register_with_routing function enables dynamic routing of traces to different Arize spaces and projects. This is useful when you need to route traces from a single application to multiple Arize spaces (e.g., based on the team or service generating the request).

Usage

First, set up the tracer provider with routing enabled via register_with_routing. Note that unlike the standard register() function, you don't need to specify a single space_id or project_name upfront.

Then, call with set_routing_context() to set the space id and project to which traces should be routed. The set_routing_context() context manager uses OpenTelemetry's context API to set routing attributes that automatically propagate to all child spans within that context. This works seamlessly with auto-instrumentors (OpenAI, LangChain, LlamaIndex, etc.) because the routing attributes are inherited by all spans created within the context.

from arize.otel import register_with_routing, set_routing_context
from openinference.instrumentation.openai import OpenAIInstrumentor

tracer_provider = register_with_routing(
    api_key="your-arize-api-key",
    # endpoint and transport are optional and default to Arize's GRPC endpoint
)

OpenAIInstrumentor().instrument(tracer_provider=tracer_provider)

current_project_id = "project-123"
current_space_id = "current-space"

# Both space_id and project_name must be provided for routing to work;
# otherwise, spans will be skipped and not sent to Arize
with set_routing_context(space_id=current_space_id, project_name=current_project_id):
    # All OpenAI calls and spans within this context will be routed to the specified space and project
    response = openai_client.chat.completions.create(
        model="gpt-4",
        messages=[{"role": "user", "content": "Hello!"}]
    )
    # Traces automatically go to "current-space" with project name "project-123"

Performance Considerations

The routing processor creates a dedicated span processor (with its own exporter) for each unique space_id encountered. These processors are cached in memory for the lifetime of the application. If your application routes to many different spaces (e.g., hundreds or thousands), memory usage will grow accordingly.

Using Environment Variables

register and the tracing constructors read environment defaults when called. Set or update environment variables after importing the package and before constructing a provider or exporter. Omitting an environment-backed argument, or passing None, uses the current environment value. Existing providers and exporters retain their original configuration.

from arize.otel import register

tracer_provider = register()

register accepts application, harness, or experiment for project_type and sets it on the provider resource as arize.project.type. Explicit arguments take precedence over environment values. Empty strings are explicit values and fail validation; an unset or empty environment endpoint uses Endpoint.ARIZE. Processors with a custom span_exporter do not require Arize configuration.

Using OTel Primitives

For more granular tracing configuration, these wrappers can be used as drop-in replacements for OTel primitives:

from opentelemetry import trace as trace_api
from arize.otel import HTTPSpanExporter, TracerProvider, SimpleSpanProcessor

tracer_provider = TracerProvider()
span_exporter = HTTPSpanExporter(endpoint=...)
span_processor = SimpleSpanProcessor(span_exporter=span_exporter)
tracer_provider.add_span_processor(span_processor)
trace_api.set_tracer_provider(tracer_provider)

Wrappers have Arize-aware defaults to greatly simplify the OTel configuration process. A special endpoint keyword argument can be passed to either a TracerProvider, SimpleSpanProcessor or BatchSpanProcessor in order to automatically infer which SpanExporter to use to simplify setup.

Specifying the endpoint directly

from opentelemetry import trace as trace_api
from arize.otel import TracerProvider

tracer_provider = TracerProvider(endpoint="https://your-desired-endpoint.com")
trace_api.set_tracer_provider(tracer_provider)

Configuring resources

# export ARIZE_COLLECTOR_ENDPOINT=https://your-desired-endpoint.com

from opentelemetry import trace as trace_api
from arize.otel import Resource, PROJECT_NAME, TracerProvider

tracer_provider = TracerProvider(resource=Resource({PROJECT_NAME: "my-project"}))
trace_api.set_tracer_provider(tracer_provider)

Using a BatchSpanProcessor

# export ARIZE_COLLECTOR_ENDPOINT=https://your-desired-endpoint.com

from opentelemetry import trace as trace_api
from arize.otel import TracerProvider, BatchSpanProcessor

tracer_provider = TracerProvider()
batch_processor = BatchSpanProcessor()
tracer_provider.add_span_processor(batch_processor)

Specifying a custom GRPC endpoint

from opentelemetry import trace as trace_api
from arize.otel import TracerProvider, BatchSpanProcessor, GRPCSpanExporter

tracer_provider = TracerProvider()
batch_processor = BatchSpanProcessor(
    span_exporter=GRPCSpanExporter(endpoint="https://your-desired-endpoint.com")
)
tracer_provider.add_span_processor(batch_processor)

Questions?

Find us in our Slack Community or email support@arize.com

Copyright, Patent, and License

Copyright 2024 Arize AI, Inc. All Rights Reserved.

This software is licensed under the terms of the 3-Clause BSD License. See LICENSE.
