astromesh-rag

Every RAG pattern, one set of parts.

Leer en español

Retrieval-augmented generation (RAG) gives a model the documents it needs to answer, at the moment it answers. Every RAG system does the same four things:

1. Ingest. Split your documents into chunks, turn each chunk into a vector, store it.
2. Retrieve. Turn the question into a vector and find the nearest chunks; optionally search keywords too, or let an LLM rewrite the question first.
3. Rank. Merge the lists, rerank the candidates with a sharper model, keep the best k.
4. Answer. Join the winners into a context block your model reads before it answers.

astromesh-rag builds each of those steps from small, swappable parts, in Python or in YAML. The patterns (naive, hybrid, multi_query, hyde) are just different wirings of the same parts, so you can switch pattern by changing one line and see exactly what each stage did in the trace. The library itself depends only on PyYAML; every model and database is an optional extra.

%%{init: {"theme": "base", "themeVariables": {"primaryColor": "#0a2463", "primaryTextColor": "#ffffff", "cScale0": "#1d4ed8", "cScale1": "#0369a1", "cScale2": "#1e40af", "cScale3": "#0f766e", "cScale4": "#2563eb", "cScale5": "#0e7490", "cScaleLabel0": "#ffffff", "cScaleLabel1": "#ffffff", "cScaleLabel2": "#ffffff", "cScaleLabel3": "#ffffff", "cScaleLabel4": "#ffffff", "cScaleLabel5": "#ffffff"}}}%%
mindmap
  root((astromesh-rag))
    Ingest
      splitters: fixed, recursive, sentence, semantic
      embedders: Ollama, Hugging Face, sentence-transformers
      stable chunk ids
      re-ingesting replaces
    Retrieve
      vector search with a cosine threshold
      BM25 keyword search
      RRF or weighted fusion
      cross-encoder or Cohere rerank
      a trace entry per stage
    Patterns
      naive
      hybrid
      multi_query
      hyde
    Integrations
      memory, FAISS, Chroma
      Qdrant, pgvector
      any OpenAI-compatible LLM
      kind: RAGPipeline YAML
    Make it yours
      registry.register
      use it by name from YAML
      typed stage contracts
      HashEmbedder and FakeLLM for tests

Patterns

A pattern decides how the question becomes candidates. Everything after that (fusion, optional reranking, the top k, the context) is shared.

Reranking is a switch on any pattern: a cross-encoder (or Cohere) rescores the candidates, which costs one extra model pass over candidates texts. Every vector search drops hits below similarity_threshold when you set one. In the diagrams, dashed boxes are optional and violet boxes call the LLM.

naive

Embed the question, take the nearest chunks.

%%{init: {"theme": "base", "themeVariables": {"primaryColor": "#e0f2fe", "primaryTextColor": "#0a2463", "primaryBorderColor": "#1d4ed8", "lineColor": "#1d4ed8"}}}%%
flowchart TB
    Q([question]) --> E[embed the question]
    E --> V[vector search: candidates nearest chunks]
    V --> T[drop hits below similarity_threshold]
    T --> R[rerank]:::opt
    R --> K[keep the best k]
    K --> C([context and trace])
    classDef opt stroke-dasharray: 5 4

hybrid

Vector search and BM25 keyword search run at the same time; reciprocal rank fusion (RRF) merges the two rankings. BM25 is what finds ERR-4012 when the embedding cannot tell it from ERR-4013.

%%{init: {"theme": "base", "themeVariables": {"primaryColor": "#e0f2fe", "primaryTextColor": "#0a2463", "primaryBorderColor": "#1d4ed8", "lineColor": "#1d4ed8"}}}%%
flowchart TB
    Q([question]) --> E[embed the question]
    Q --> B[BM25 keyword search]
    E --> V[vector search]
    V --> T[drop hits below similarity_threshold]
    T --> F[fuse: RRF or weighted]
    B --> F
    F --> R[rerank]:::opt
    R --> K[keep the best k]
    K --> C([context and trace])
    classDef opt stroke-dasharray: 5 4

multi_query

An LLM rewrites the question N ways (3 by default). The original and every rewrite are searched, and RRF rewards the chunks that several wordings agree on.

%%{init: {"theme": "base", "themeVariables": {"primaryColor": "#e0f2fe", "primaryTextColor": "#0a2463", "primaryBorderColor": "#1d4ed8", "lineColor": "#1d4ed8"}}}%%
flowchart TB
    Q([question]) --> L[LLM writes N rewrites]:::llm
    Q --> V0[vector search: original]
    L --> V1[vector search: rewrite 1]
    L --> VN[vector search: rewrite N]
    V0 --> F[fuse: RRF]
    V1 --> F
    VN --> F
    F --> R[rerank]:::opt
    R --> K[keep the best k]
    K --> C([context and trace])
    classDef opt stroke-dasharray: 5 4
    classDef llm fill:#ede9fe,stroke:#7c3aed,color:#3b0764

hyde

Hypothetical document embeddings: an LLM writes the passage that would answer the question, and that passage is searched next to the question itself. A paragraph looks more like a paragraph than a one-line question does.

%%{init: {"theme": "base", "themeVariables": {"primaryColor": "#e0f2fe", "primaryTextColor": "#0a2463", "primaryBorderColor": "#1d4ed8", "lineColor": "#1d4ed8"}}}%%
flowchart TB
    Q([question]) --> L[LLM writes a hypothetical answer]:::llm
    Q --> V0[vector search: question]
    L --> V1[vector search: hypothetical answer]
    V0 --> F[fuse: RRF]
    V1 --> F
    F --> R[rerank]:::opt
    R --> K[keep the best k]
    K --> C([context and trace])
    classDef opt stroke-dasharray: 5 4
    classDef llm fill:#ede9fe,stroke:#7c3aed,color:#3b0764

Ideas, stages, YAML and failure modes for each one: docs/patterns.md.

One hybrid query, stage by stage

Every query returns a QueryResult with the hits, the context and a trace: one entry per stage (the green notes below) with its name, time in milliseconds, how many items went in and out, and the error if it failed. In hybrid, a failing retriever is recorded in the trace and the other one's hits are used; only both failing raises StageError.

%%{init: {"theme": "base", "themeVariables": {"primaryColor": "#e0f2fe", "primaryTextColor": "#0a2463", "primaryBorderColor": "#1d4ed8", "lineColor": "#1d4ed8", "signalColor": "#1d4ed8", "signalTextColor": "#0a2463", "noteBkgColor": "#ccfbf1", "noteBorderColor": "#0f766e", "noteTextColor": "#134e4a"}}}%%
sequenceDiagram
    autonumber
    participant App
    participant P as QueryPipeline
    participant V as VectorRetriever
    participant B as BM25Index
    participant F as RRF
    participant R as Reranker
    App->>P: query("What does ERR-4012 mean?", k=5)
    par in parallel, candidates each
        P->>V: retrieve(question, 10)
        V->>V: embed, search the index, drop below threshold
        V-->>P: up to 10 hits
    and
        P->>B: retrieve(question, 10)
        B-->>P: up to 10 hits
    end
    Note over P: trace: retrieve vector, retrieve bm25
    P->>F: fuse both lists
    F-->>P: 10 hits, score = RRF
    Note over P: trace: fuse RRF, in 20, out 10
    P->>R: rerank(question, hits, 5)
    R-->>P: 5 hits, score = cross-encoder
    Note over P: trace: rerank, in 10, out 5
    P->>P: keep k, join the texts
    Note over P: trace: context
    P-->>App: QueryResult with hits, context and trace

Each hit keeps every score it collected in details (vector, bm25, rrf, rerank) and says who found it in source (vector, bm25 or bm25+vector).

Benchmark

Which pattern should you use? The repo ships a simulated corpus built to make retrieval fail in specific, labeled ways, and a script that ranks the four patterns on it, with and without a reranker.

The corpus. Nimbus is the documentation of a fictional cloud-storage service: 200 documents (Spanish first, about 20 % English) and 60 hand-labeled questions.

The questions are typed the same way: 15 exact ("¿Qué significa ERR-4012?"), 20 paraphrase ("me cobraron dos veces este mes"), 15 distractor (only the 2026 policy counts as correct) and 10 noise. Each type carries a hypothesis (BM25 wins on codes, rewrites win on paraphrases, a reranker separates versions and pushes noise down) that the run confirms or refutes.

Metrics. Rankings are scored per document (chunk hits deduplicated to their document): recall@5, precision@5 and hit rate@5, MRR@10 and nDCG@10, plus p50/p95 latency of one query() call and LLM calls per query.

Models. Embeddings: sentence-transformers/all-MiniLM-L6-v2. Reranker: cross-encoder/ms-marco-MiniLM-L-6-v2. LLM for multi_query and hyde: Kimi through an OpenAI-compatible gateway.

Reproduce it.

git clone https://github.com/monaccode/astromesh-rag && cd astromesh-rag
uv sync --extra sentence-transformers --extra openai
export RAG_BENCH_BASE_URL=https://your-gateway/v1 RAG_BENCH_API_KEY=... RAG_BENCH_MODEL=...
uv run python examples/benchmark.py --embedder st --rerank both --k 5 --out results/

It prints the overall and per-type tables and writes results/<date>-st.json with the config, the corpus hash and every per-query row. Without RAG_BENCH_* it falls back to a fake LLM, and --embedder hash uses a test embedder: both run offline and both print a warning, because their scores mean nothing.

Quickstart

pip install 'astromesh-rag[sentence-transformers]'

Python. Ingest two documents, ask with hybrid, read the context:

import asyncio

from astromesh_rag import Document
from astromesh_rag.embedders import SentenceTransformersEmbedder
from astromesh_rag.indexes import MemoryIndex
from astromesh_rag.patterns import hybrid
from astromesh_rag.pipeline import IngestPipeline
from astromesh_rag.retrievers import BM25Index
from astromesh_rag.splitters import RecursiveSplitter

docs = [
    Document("ERR-4012: your upload link expired. Request a new one.", id="err-4012"),
    Document("ERR-4013: your storage quota is full. Free space or upgrade.", id="err-4013"),
]


async def main():
    embedder, index, bm25 = SentenceTransformersEmbedder(), MemoryIndex(), BM25Index()
    await IngestPipeline(RecursiveSplitter(), embedder, index, bm25).ingest(docs)
    result = await hybrid(embedder, index, bm25).query("What does ERR-4012 mean?", k=1)
    print(result.context)  # ERR-4012: your upload link expired. Request a new one.
    print(result.trace)  # retrieve vector, retrieve bm25, fuse, context


asyncio.run(main())

YAML. The same kind: RAGPipeline format the Astromesh runtime loads:

# support.rag.yaml
apiVersion: astromesh/v1
kind: RAGPipeline
metadata:
  name: support-docs
spec:
  chunking: { strategy: recursive, chunk_size: 800, overlap: 80 }
  embeddings: { provider: sentence_transformers, model: all-MiniLM-L6-v2 }
  vector_store: { backend: memory }
  reranking: { enabled: true, provider: cross_encoder, top_k: 5 }
  retrieval:
    pattern: hybrid
    top_k: 5
    candidates: 20

from astromesh_rag.spec import build, load_spec_file

pipeline = build(load_spec_file("support.rag.yaml"))
await pipeline.ingest(docs)
result = await pipeline.query("What does ERR-4012 mean?")

multi_query and hyde need a model: build(spec, llm=OpenAICompatLLM(base_url, api_key, model)) works with any OpenAI-compatible endpoint (a gateway, Ollama, vLLM, OpenAI). Every key and default: docs/spec.md.

Extras

Splitters, BM25, fusion, the memory index and the test doubles need nothing beyond PyYAML. Everything else is an extra; a missing one raises MissingExtraError with the exact pip install 'astromesh-rag[...]' to run, when the pipeline is built.

Make it yours

Every stage is a small async protocol (Splitter, Embedder, VectorIndex, Retriever, QueryTransform, Reranker, LLM) and every name in the YAML comes from one registry. Register a factory and your component is usable by name, with no fork:

from astromesh_rag import registry
from astromesh_rag.indexes import MemoryIndex


class LoggingIndex(MemoryIndex):
    async def search(self, vector, k, filters=None):
        hits = await super().search(vector, k, filters)
        print(f"search returned {len(hits)} hits")
        return hits


registry.register("index", "logging", lambda cfg, ctx: LoggingIndex())

vector_store: { backend: logging }

Registering an existing name replaces the built-in, which is how a runtime can put a faster chunker behind chunking.strategy: recursive. astromesh_rag.testing ships HashEmbedder and FakeLLM so your tests run without a network or a model. A full vector database adapter and a custom query rewrite, step by step: docs/extending.md.

How Astromesh uses it

This library started as the RAG layer inside the Astromesh agent runtime and was extracted so that anyone can use it, the same move made with astromesh-okf. The plan for the next core release (not shipped yet) is that the core delegates all of its RAG to this library and keeps only the wiring: astromesh/rag becomes a thin facade with today's names, every existing kind: RAGPipeline file keeps loading unchanged, the core's model router becomes the LLM for multi_query and hyde, and its Rust chunker registers over chunking.strategy: recursive.

Porting the code out surfaced bugs in the core's implementation. They are fixed here and listed in the CHANGELOG:

A second ingestion overwrote the first. Chunk ids were doc_0, doc_1… for every document, so ingesting document B replaced document A. Ids are now <doc_id>#<n>, and re-ingesting a document deletes its old chunks first instead of leaving stale ones behind.

Two YAML keys were accepted and ignored. retrieval.similarity_threshold now drops vector hits below that cosine (never applied to reranker scores, which are not on a 0–1 scale), and reranking.top_k now caps the reranker's output.

Each backend failed differently. Qdrant rejected string point ids (they are now UUIDv5 of the chunk id), pgvector built filters by interpolating SQL (now bound parameters), Chroma ranked by L2 distance (now cosine, like the others), and semantic chunking from YAML silently fell back to sentence splitting because no embedder reached it.

An overlap at least as large as the chunk hung the splitter. overlap >= chunk_size is now a SpecError at build time.

Roadmap

v0.1 is the foundation: the stage contracts, the port of the core, four patterns, retrieval metrics and the benchmark. Each later phase gets its own spec and release.

Contributing

Issues and pull requests are welcome. CONTRIBUTING.md covers setup, tests (including the integration jobs) and how to add a backend.

License

Apache-2.0. Part of the Astromesh ecosystem.
