astrovello 2.0.0

AsTrovello

AsTrovello builds multi-survey datacubes of a galaxy for spatially-resolved SED fitting. It takes PHANGS-HST, PHANGS-JWST and S4G (Spitzer/IRAC) imaging and produces a single FITS cube in Jy/pixel, at a common angular resolution, on a common pixel grid.

What it does

1. PSF matching and convolution. Every band is degraded to the resolution of the worst-resolved band (the master, chosen by the r80 of its PSF). Kernels are built with PyPHER on the grid where they are applied.
2. Reprojection. Every band is resampled onto the master's pixel grid.
3. Unit conversion. ELECTRONS/S (HST), MJy/sr (JWST, Spitzer) to Jy/pixel.
4. Datacube. Bands are stacked by wavelength, sky-subtracted, masked and cropped.

Two validation gates abort the run on failure: PSF matching (r50 ratio within 5%) after the kernels are built, and flux conservation (< 1%) after reprojection.

The pipeline trusts the input WCS: it reprojects, it does not measure or correct astrometric offsets between surveys.

Installation

Python >= 3.10. A dedicated Conda environment is recommended.

conda create -n astrovello python=3.11
conda activate astrovello
pip install astrovello

Latest development version, from GitHub:

pip install git+https://github.com/andretrovello/AsTrovello.git

From a local clone (editable, for development):

git clone https://github.com/andretrovello/AsTrovello.git
cd AsTrovello
pip install -e .

This installs three commands: astrovello (the pipeline), astrovello-check-psf and astrovello-check-flux (standalone validation reports). PyPHER is installed as a dependency and is called as the pypher command, so run AsTrovello with its environment activated.

Running

AsTrovello works on a project directory of your choice. Put your data in an Input/ folder there and run the command from that directory; the pipeline builds Output/ next to it.

my_project/                      <- run `astrovello` from here
├── Input/
│   ├── PHANGS-HST/
│   │   ├── galaxies/<galaxy>/   hlsp_phangs-hst_..._<filter>_v1_exp-drc-sci.fits
│   │   └── PSF/                 PSFSTD_WFC3UV_<FILTER>.fits
│   ├── PHANGS-JWST/
│   │   ├── galaxies/<galaxy>/   hlsp_phangs-jwst_jwst_<instr>_..._v1p1_img.fits
│   │   └── PSF/                 WebbPSF PSFs (*PSF*.fits)
│   └── S4G/
│       ├── galaxies/<galaxy>/   <GALAXY>.phot.1.fits, <GALAXY>.phot.2.fits
│       └── PSF/                 IRAC PRFs (*_col129_row129.fits)
└── Output/                      created by the pipeline

The survey directory names must be exactly PHANGS-HST, PHANGS-JWST and S4G: the survey of each file is identified from its path. You only need the surveys you want to combine.

cd my_project
astrovello --galaxy ngc1087 --surveys PHANGS-HST,PHANGS-JWST --create_kernel

--surveys chooses which surveys to combine: a comma-separated list, or all for every configured survey found in Input/. The choice sets the master filter and so the whole cube, so a name that is not available stops the run instead of being skipped. Without --surveys the pipeline asks interactively. That needs a terminal, so pass --surveys for batch or background runs. Use --root /path/to/my_project to run it from elsewhere, and --preflight_only to validate the configuration in seconds without processing anything. astrovello --help lists every option.

Several galaxies in a row:

for g in ngc1087 ngc1433 ngc2903; do
  astrovello --galaxy $g --surveys PHANGS-HST,PHANGS-JWST --create_kernel || break
done

Keep --create_kernel for every galaxy: Output/PSF_Kernels/ is shared between galaxies, and the convolution grids are derived from each galaxy's images.

Modes

Use --create_kernel the first time, and whenever the combination of surveys (and therefore the master) changes. It regenerates PSFs and kernels and forces reconvolution.

Outputs

Input/<SURVEY>/PSF_CLEAN/          PSFs resampled onto each convolution grid
Output/PSF_Kernels/                kernel_<filter>_to_<master>.fits
Output/convolved_fits/<galaxy>/    convolved bands and the master
Output/reprojected_files/<galaxy>/ reprojected bands and *_Jy_per_pixel.fits
Output/datacubes/<galaxy>/         <galaxy>_datacube_sci_<ny>x<nx>_Jy_per_pixel.fits
Output/checks/<check>/             standalone check outputs

Standalone checks

Run from the same project directory, after the pipeline:

astrovello-check-psf                     # PSF matching, every kernel
astrovello-check-flux --galaxy ngc1087   # flux conservation through reprojection

Data sources

• PHANGS-HST: https://archive.stsci.edu/hlsp/phangs
• PHANGS-JWST: https://archive.stsci.edu/hlsp/phangs
• S4G (Spitzer): https://irsa.ipac.caltech.edu/data/SPITZER/S4G/

Project structure

src/astrovello/
├── astrovello_cli.py              pipeline orchestrator (`astrovello`)
├── config.py                      per-survey constants
├── drivers.py                     per-survey behaviour (HDU, masks, units)
├── convolution.py                 PSF widths, PSF cleaning, kernels, convolution
├── reprojection.py                reprojection onto the master grid
├── units.py                       conversion to Jy/pixel
├── cube.py, mask.py               datacube assembly, masks, sky subtraction
├── validation.py                  in-pipeline validation gates
├── preflight.py                   configuration checks before any compute
├── utils.py                       pixel scales, wavelength ordering
├── check2_psf_matching.py         `astrovello-check-psf`
└── check3_flux_conservation.py    `astrovello-check-flux`
