atunapy 1.1.1

A Python toolkit for mining the biomedical literature: search PubMed for articles, extract structured information from their text with an LLM, look up the compounds mentioned in PubChem, and curate the resulting SMILES strings.

Table of contents

• Installation
• Setup
  • API keys
  • Where to get API keys
• Usage
  • Step 1 — Search PubMed
  • Step 2 — Extract text
  • Step 3 — Query PubChem
  • Step 4 — Curate SMILES
• Next steps

Installation

It is recommended to create a virtual environment first:

conda create --name atunapy_new "python>=3.8" pip
conda activate atunapy_new

Install from PyPI:

pip install atunapy

Or install from source:

git clone https://github.com/aylindmm/aTUNApy.git
cd aTUNApy
pip install -e .

Setup

from atunapy import PubMedSearcher, PubChemSearcher, TextExtract, SMILEScuration

API keys

To use any of the LLMs supported by aTUNApy you need to provide your own API keys. You can set them as environment variables in your terminal:

export OPENAI_API_KEY="your_openai_api_key"
export GROQ_API_TOKEN="your_groq_api_token"
export ANTHROPIC_API_KEY="your_anthropic_api_key"
export GEMINI_API_KEY="your_gemini_api_key"

Or save them in a .env file in the root directory of your project:

OPENAI_API_KEY=your_openai_api_key
GROQ_API_TOKEN=your_groq_api_token
ANTHROPIC_API_KEY=your_anthropic_api_key
GEMINI_API_KEY=your_gemini_api_key

For the .env approach, install python-dotenv:

pip install python-dotenv

and load the file at the top of your script:

from dotenv import load_dotenv
load_dotenv()  # Load environment variables from .env file

Note: Keep your API keys secure and never share them publicly or commit them to version control.

Where to get API keys

Provider	Link
OpenAI	https://openai.com/es-419/api/
Groq	https://console.groq.com/home
Gemini	https://aistudio.google.com/api-keys
Anthropic	https://platform.claude.com/docs/en/get-api-key

Note: Some LLM providers have usage limits or costs associated with their APIs. Be sure to review the terms and conditions of each provider.

Usage

A typical aTUNApy workflow has four steps: search PubMed, extract text with an LLM, retrieve compound information from PubChem, and curate the SMILES strings.

import os
import pandas as pd
from atunapy import PubMedSearcher, PubChemSearcher, TextExtract, SMILEScuration

Step 1 — Search PubMed

Use atunapy.PubMedSearcher to query PubMed and collect article identifiers and metadata.

articles = PubMedSearcher.fetch_articles(
    search_terms=['ototoxicity', 'hearing loss', '(inner ear) AND (drug induced damage)'],
    email=os.environ.get('EMAIL_ADDRESS'),
    api_key=os.environ.get('NCBI_API_KEY'),
)

Note: NCBI E-utilities do not require an API key or email address, but they do apply rate limits. Providing both is recommended for large queries.

Step 2 — Extract text

atunapy.TextExtract retrieves and cleans the text of the articles found in the previous step, then uses an LLM to extract the information you ask for.

You need two things: a prompt describing the task (clear, specific prompts give the best results) and a DataFrame of variables to extract. Each variable has a name, a description, and a type ("List" or "String"):

df = pd.DataFrame({
    'Name': ['ototoxic drugs', 'otoprotective drugs', 'effects', 'mechanism of ototoxicity'],
    'Description': [
        "Any ototoxic drugs or molecules",
        "Any drugs or molecules mentioned as protective against ototoxicity or used to treat drug-induced hearing loss.",
        'Classify the ototoxicity as "Cochleo-toxicity", "Vestibulo-toxicity", "Dizziness", "not mentioned" or "Other"',
        "Note the described mechanism for the ototoxic compounds mentioned (e.g., cochlear hair cell damage, vasoconstriction). Give a very short answer.",
    ],
    'Type': ["List", "List", "String", "String"],
})

Define the extractor with a prompt. The template below can be adapted to your needs:

tool = TextExtract.LLMTextExtractor(
    prompt="""You are an expert pharmacologist specializing in otolaryngology.
    Your task is to extract drug information from the following research article.

    Definitions:
    - Ototoxic Agent: A drug or molecule that causes damage to the inner ear (cochleotoxicity or vestibulotoxicity), hearing loss or dizziness.
    - Otoprotective Agent: A compound that prevents or mitigates such damage.

    Instructions:
    1. Identify all drugs, molecules, or experimental compounds mentioned.
    2. Determine their role: "Ototoxic" or "Otoprotective".
    """,
    variables=df,
)

Then run the extraction on the articles retrieved from PubMed:

results = tool.process_articles(
    df=articles[:10],  # Test with a small subset first
    LLM="Gemini",
    api_key=os.environ.get('GEMINI_API_KEY'),
    model="gemini-3.5-flash-lite",
)
print("Extraction complete.")

Note: To avoid exceeding usage limits, test with a small subset of articles first. Once you are satisfied with the results, process the entire dataset.

Step 3 — Query PubChem

atunapy.PubChemSearcher looks up the compound names found in the text and returns PubChem records (CID, IUPAC name, SMILES, InChIKey and synonyms).

compounds = PubChemSearcher.fetch_compound_info(
    df=results,
    columns=["ototoxic_drugs", "otoprotective_drugs"],  # columns of `results` containing compound names
)

Step 4 — Curate SMILES

atunapy.SMILEScuration standardises and validates the SMILES strings obtained from PubChem.

compounds["Clean_SMILES"] = [SMILEScuration.standardize(x) for x in compounds["smiles"]]

Next steps

See the API documentation for the full list of functions and parameters in each module.
