Automated Vulnerability Management Program (AVMP)

A collection of tools for managing and automating vulnerability management.

Streamline the way vulnerability management programs are created and run. This project is made to be modular so automation can be put into place at any program level.

Table of Contents

• Things to Note
• Intallation
• Running the tests
• Deployment
• How to use
  • Folder Structure
  • Main configuration file "config.json"
  • Dynamic process config "dynamic_process_config.json
  • Static process config "static_process_config.json"
• TO-DO
• Authors
• License

Things to Note

1. API keys for both Tenable IO and Jira are required.

2. I developed this tool using Jira on-prem and assume it would work for the cloud version as well however am unable to verify that.

3. There is a bit of setup to use the tool as it is in development, I am planning on creating a quick start script but until then please see How to use.

Installation

pip install git+https://github.com/RackReaver/AVMP

Running the tests

Check code coverage

>>> coverage run -m pytest
>>>
>>> coverage report

Deployment

At this time the tool can only be deployed locally.

How to use

$ avmp --help
      __      ____  __ _____
     /\ \    / /  \/  |  __ \
    /  \ \  / /| \  / | |__) |
   / /\ \ \/ / | |\/| |  ___/
  / ____ \  /  | |  | | |
 /_/    \_\/   |_|  |_|_|

A collection of tools for managing and automating vulnerability management.

Usage:
    avmp run [--config filepath] <process_config>
    avmp update [--config filepath] <ticket_db_filepath>
    avmp -h | --help
    avmp --version

Options:
    -h --help           Show this screen.
    --version           Show version.
    --config=filepath   AVMP configuration file [default: config.json]

Folder Structure vuln_manager:

vuln_manager
|
+-- process_configs
|  |
|  +-- dynamic/     # Configurations for generating vulnerability tickets
|  +-- static/      # Configurations for generating repetitive project/task tickets
|
+-- config.json
+-- tickets.db      # This is generated automatically and is mapped to in the process_configs

Main configuration file config.json:

{
    "creds": {
        "tenable": {
            "access_key": "",
            "secret_key": ""
        },
        "jira": {
            "server": "",
            "username": "",
            "password": ""
        }
    },
    "types": {
        "JIRA_PROJECT_ID": ["JIRA_FIELD_1", "JIRA_FIELD_2", "JIRA_FIELD_3"]
    },
    "due_dates": {
        "Critical": "DAYS_TO_PATCH",
        "High": "DAYS_TO_PATCH",
        "Medium": "DAYS_TO_PATCH",
        "Low": "DAYS_TO_PATCH",
    },
    "priorities": {
        "Critical": "JIRA_ID",
        "High": "JIRA_ID",
        "Medium": "JIRA_ID",
        "Low": "JIRA_ID"
}

Dynamic process config dynamic_process_config.json:

See examples for context on use cases.

{
  "process_type": "dynamic",
  "allow_ticket_duplication": "False",
  "scan_name": "TENABLE_SCAN_NAME",
  "max_tickets": 10,
  "assignee": "",
  "min_cvss_score": 6.0,
  "ticket_db_filepath": "tickets.db",
  "default_ticket_status": "Open",
  "time_saved_per_ticket": "10m",
  "root_ticket": "",
  "comments": [],
  "data": {
    "project": { "key": "JIRA_PROJECT_KEY" },
    "summary": "Vuln: ",
    "description": "",
    "issuetype": { "id": "JIRA_ISSUE_TYPE_ID" },
    "priority": { "id": "" },
    "duedate": ""
  }
}

Static process config static_process_config.json:

See examples for context on use cases.

{
  "process_type": "static",
  "time_saved_per_ticket": "5m",
  "time_saved_comment": "Time saved through automation",
  "parent_ticket": {
    "project": { "key": "JIRA_PROJECT_KEY" },
    "summary": "SUMMARY",
    "description": "DESCRIPTION",
    "issuetype": { "name": "ISSUE_TYPE_NAME" },
    "assignee": { "name": "" },
    "priority": { "id": "PRIORITY_ID" }
  },
  "sub_tasks": {
    "sub_task_1": {
      "project": { "key": "JIRA_PROJECT_KEY" },
      "summary": "SUMMARY",
      "description": "DESCRIPTION",
      "issuetype": { "name": "Sub-task" },
      "assignee": { "name": "" }
    },
    "sub_task_2": {
      "project": { "key": "JIRA_PROJECT_KEY" },
      "summary": "SUMMARY",
      "description": "DESCRIPTION",
      "issuetype": { "name": "Sub-task" },
      "assignee": { "name": "" }
    }
  }
}

TO-DO

• Add persistent logging to wrapper.main() as a return value
• Add ticket reference table to database
  • Track project and process ticket numbers for automated linking
• Add support for SecurityScorecard
• Build tests for code base
• [x]Add example dynamic and static process configs
• Add database tracking of static_process tickets

Authors

• Matt Ferreira - Developer - RackReaver

License

This project is licensed under the Apache License - see the LICENSE file for details
