AxisDB

AxisDB is a tiny embedded document database for Python, designed for simple, reliable storage of JSON documents addressed by N-dimensional coordinate keys.

It is library-first, requires no server and stores all data in a single JSON file with atomic, crash-safe commits.

See also:
USE_CASES.md: a concise overview of practical applications and patterns enabled by this multidimensional JSON storage model.
ARCHITECTURE.md: the engine, the storage format and the locking model.
TECH_DEBT.md: what is still open, what is deliberately left and what only looks like debt.

MIT licensed. AxisDB is free and open source under the MIT licence, so it can be imported into closed-source and commercial code with no further agreement. Releases up to and including 1.0.6 were published under GPL-3.0 and stay under it.

---

Key properties

• Library-first design (usable without any server)
• Single-file JSON storage
• Atomic, crash-safe commits via temp-file replace
• Safe multi-process access (single writer, multiple readers) via file locks
• Minimal but useful query + indexing support (correctness-first)

---

Features

• Embedded JSON document database
• N-dimensional coordinate keys
• Atomic commit and recovery
• Key listing (list) and multidimensional slicing (slice)
• Basic querying (find) with optional persisted field indexes
• Optional FastAPI wrapper with Swagger (/docs) and ReDoc (/redoc)

---

Installation

Core library

pip install axisdb

Optional server components

pip install "axisdb[server]"

---

Basic library usage

Create a database, write a value and commit:

from axisdb import AxisDB

db = AxisDB.create("./mydb.json", dimensions=2)
db.set(("user1", "orders"), {"count": 3})
db.commit()

ro = AxisDB.open("./mydb.json", mode="r")
print(ro.get(("user1", "orders")))

Notes:

• Dimensions are fixed at database creation time; all keys must be a tuple[str, ...] of that length.
• Values must be JSON-serializable (validated by default on set).
• mode="rw" writes are staged in-memory until commit(); rollback() discards uncommitted changes.
• mode="r" reloads from disk on each operation to reflect the latest committed state.

---

Query and indexing (MVP)

AxisDB is optimized for correctness and predictable behavior over complex query planning.

• Indexes are materialized and persisted in the DB file.
• Indexes are rebuilt on each commit (correctness-first MVP).
• find() can use indexes only when there are no pending writes in the current session.

Index types

• Prefix index: always maintained; used by find(prefix=...) to reduce scan work (note: list(prefix=...) currently filters materialized keys directly).
• Field indexes: optional, user-defined; can accelerate simple equality predicates of the form Field(("path", "to", "field"), "==", literal).

Define a field index:

from axisdb import AxisDB

db = AxisDB.create("./mydb.json", dimensions=2)
db.define_field_index("by_customer_id", ("customer_id",))

Query with an expression:

from axisdb import AxisDB
from axisdb.query.ast import Field

db = AxisDB.open("./mydb.json", mode="r")
rows = db.find(prefix=("orders",), where=Field(("customer_id",), "==", "c2"))

---

Running the FastAPI wrapper (optional)

After installing the server extras:

pip install "axisdb[server]"

Run the server:

python -m uvicorn axisdb.server.app:app --reload

The server will start at:

http://localhost:8000

---

API documentation

FastAPI automatically exposes interactive documentation:

• Swagger UI: http://localhost:8000/docs
• ReDoc: http://localhost:8000/redoc

REST endpoints (thin wrapper)

The server is intentionally a minimal translation layer over the library:

• GET /info?path=...
• POST /init?path=...&dimensions=...&overwrite=false
• POST /item?path=... (body: { "coords": [...], "value": ... })
• GET /item?path=...&coords=...&coords=...
• DELETE /item?path=... (body: { "coords": [...] })
• GET /list?path=...&prefix=...&depth=...
• GET /find?path=...&prefix=...&field=...&op===&value=...&limit=...

/find reads value as JSON when it parses, so value=10 matches the number 10, value=true a boolean and value=null a null; anything that is not valid JSON, such as value=c1, is matched as a plain string. To match a string that looks like a number or a keyword, quote it: value="10" matches the string "10".

The wrapper does not bypass durability or locking: it opens the database in mode="r" or mode="rw" as needed and uses the same commit semantics.

---

Concurrency model (locking)

By default (lock=True), AxisDB uses two lock files next to the database file:

• *.writer.lock: exclusive lock held for the lifetime of a writer session (mode="rw")
• *.rw.lock: shared during reads; exclusive during commit()

This supports single-writer / multiple-reader access across processes.

---

Versioning and compatibility

This project follows semantic versioning.

Guaranteed stable within a major version:

• Public AxisDB API: open, create, get, set, delete, exists, list, slice, find, commit, rollback
• Public exception types in axisdb.errors
• On-disk file format (format=axisdb, format_version=2)

May change in minor versions:

• Internal module structure and private attributes
• Index query planning details

Breaking changes will only occur in the next major version.

---

Development

Run tests:

python -m pytest -q

• DEVELOPMENT.md: working from source, versioning and cutting a release.
• TESTING.md: the checks, what the suite covers and leaves out; how a test is written.
• ARCHITECTURE.md: the storage format, durability, locking, indexing and the query system.

---

Supporting the project

AxisDB is free and stays free. There is no paid tier, no licence key and no feature held back behind a donation. If it has saved you time or simply been useful, a donation supports its maintenance and continued development.

---

Licence

MIT. See LICENSE.

AxisDB moved from GPL-3.0 to MIT after 1.0.6, a deliberate choice for adoption. A library is only useful to the teams that are allowed to import it; a GPL library is off limits to most commercial Python codebases. Its dependencies (portalocker, plus fastapi and uvicorn behind the server extra) are all under permissive licences, so nothing it pulls in contradicts the change. Releases up to and including 1.0.6 remain under GPL-3.0.
