axonx 0.0.1

Axon is a small, extensible framework for defining, discovering, and running ordered flows. Each flow combines a strict Pydantic configuration, Python callables executed in order, a shared runtime context, and declared outputs. Applications install their flows as providers and expose them through the same axon command.

The distribution is named axonx; the Python package and command are both named axon.

Framework at a glance

Layer	Contract	Responsibility
Configuration	BaseConfig	Validates typed inputs with unknown fields forbidden.
Flow	BaseFlow	Owns configuration, logger, shared context, steps, and outputs.
Step	Callable[[], None]	Performs one unit of work and reads or updates the flow context.
Registry	@register("name")	Maps a normalized action name to one flow class.
Discovery	axon.flows entry points	Imports installed provider modules so registration runs.
Runtime	axon --action --field value	Parses inputs, validates configuration, executes steps, and emits JSON.

Axon deliberately keeps orchestration close to Python. A concrete list builds a fixed sequence; a generator can use normal if, for, and yield from control flow to decide later steps after earlier steps update the context. There is no separate workflow DSL or scheduler.

Installation

Axon requires Python 3.11 or newer.

python -m pip install axonx

For framework development:

git clone https://github.com/FlowLLM-AI/Axon.git
cd Axon/packages
python -m pip install -e ".[dev]"

Quick start

The framework includes a small demo flow:

axon --list
axon --demo --x 1 --y 2

The successful result is written to stdout as JSON:

{"result": 3}

Every configuration argument is a --field value pair, including booleans. Hyphens in action and field names are normalized to underscores. Unknown fields, duplicate fields, missing values, malformed values, and unknown actions fail before flow execution.

Define a flow

Subclass BaseConfig for inputs and BaseFlow for orchestration. Annotating config lets Axon infer the configuration class. build_steps() returns or yields zero-argument callables, while output_keys declares which context values must exist after execution.

from collections.abc import Iterable

from axon.cli import BaseConfig, BaseFlow, Step, register


class GreetConfig(BaseConfig):
    name: str
    times: int = 1


@register("greet")
class GreetFlow(BaseFlow):
    config: GreetConfig
    output_keys = ("message",)

    def build_steps(self) -> Iterable[Step]:
        yield self.build_message

    def build_message(self) -> None:
        self.context["message"] = " ".join([f"hello {self.config.name}"] * self.config.times)

Import the module containing the class, then run:

axon --greet --name Axon --times 2

{"message": "hello Axon hello Axon"}

The execution contract is intentionally small:

Element	Rule
config annotation	Must resolve to a BaseConfig subclass.
build_steps()	Returns an iterable of zero-argument callables in execution order.
self.context	Starts with constructor keyword arguments and carries state between steps.
output_keys	Names required context keys and preserves their declared order in the result.
execute()	Runs every yielded step, then raises if any declared output is missing.

Dynamic orchestration uses ordinary Python:

Pattern	Expression
Task	yield self.step
Sequence	yield from self.build_subsequence()
Conditional	Use if while lazily yielding steps.
For each	Loop and yield a zero-argument callable; use functools.partial to bind arguments.

Because a generator resumes between steps, conditions placed after a yield can observe context written by the previous step.

Publish a flow provider

An external package exposes its flows through the axon.flows entry-point group. For example, this repository's pyproject.toml connects axon-core to the framework with:

[project.entry-points."axon.flows"]
default = "core.default"

Axon imports core.default, whose package initialization imports the modules containing @register(...). After the provider is installed, its flows appear automatically:

axon --list

Built-in flows

This table describes flows shipped by axonx. Provider packages should document their own flows in the same format, making the catalog easy to extend as new flows are added.

Flow	Config	Inputs	Output	Purpose
demo	DemoConfig	x: int, y: int	result	Demonstrates task, sequence, conditional, and loop-based step generation by adding two integers.

Utilities

The supported helpers are exported from axon.utils. Add one row when a new public utility is introduced so this table remains the compact public catalog.

Utility	Signature	Configuration	Behavior
load_env	load_env(path=None, *, override=True) -> dict[str, str]	Optional file path	Loads an explicit file or the nearest .env in the working directory or first five parents. Returns only values written to the environment.
get_logger	get_logger()	AXON_LOG_DIR	Lazily creates the shared Loguru INFO logger with stderr and daily rotating file sinks; file retention is seven days.
send_dingtalk_message	send_dingtalk_message(title, text, msgtype="markdown", timeout=10.0) -> str	DINGTALK_CLIENT_ID, DINGTALK_CLIENT_SECRET, DINGTALK_CONVERSATIONS	Sends Markdown or text through a DingTalk application robot to every configured, deduplicated conversation.

DINGTALK_CONVERSATIONS must be a JSON object whose non-empty names map to non-empty conversation IDs, for example {"research":"cidxxx","operations":"cidyyy"}. Credentials and group IDs are omitted from transport errors. Network calls occur only when send_dingtalk_message() is invoked.

Environment variables

Axon calls load_env() before CLI provider discovery, allowing provider imports to resolve environment-based defaults.

Variable	Used by	Default	Purpose
AXON_LOG_DIR	Shared logger	logs	Directory for timestamped process log files.
DINGTALK_CLIENT_ID	DingTalk helper	Required on use	Application key and robot code.
DINGTALK_CLIENT_SECRET	DingTalk helper	Required on use	Application secret used to obtain an access token.
DINGTALK_CONVERSATIONS	DingTalk helper	Required on use	JSON object mapping names to group conversation IDs.

Provider-specific variables belong in the provider's documentation rather than the framework package.

Package layout

Path	Contents
axon/cli.py	Configuration and flow bases, registry, provider discovery, argument parsing, execution, and CLI.
axon/flows/	Built-in flows; importing the package registers them.
axon/utils/	Environment, logging, and notification helpers.
tests/	Fast tests using temporary files and mocked network boundaries.

Development

python -m pytest -v --tb=long
pre-commit run --all-files
python -m build

Keep provider-specific business logic outside the framework. A provider may depend on axonx; axonx must not depend on that provider.

License

Licensed under the Apache License, Version 2.0. See LICENSE for details.
