benlink 0.1.1

A cross-platform library for Bluetooth communication with Benshi radios like the Vero VR-N76, RadioOddity GA5WB, and BTech UV-Pro.

benlink

benlink is a cross-platform Python library for communicating with and controlling Benshi radios (e.g. Vero VR-N76, RadioOddity GA-5WB, BTech UV-Pro) over BLE and Bluetooth Classic (RFCOMM).

In addition to providing a high-level async Python interface for controlling Benshi radios, the larger goal of this project is to document their BLE / RFCOMM protocol. An understanding of the protocol used by these radios will empower Benshi radio owners and the wider open source community to:

1. Control their radios without relying on proprietary apps or software.

2. Extend the functionality of their radios through custom software and integrations.

3. Preserve the usability of their radios, even when the official "HT" app is no longer supported or updated.

It is a work in progress and is nowhere close to feature complete. Pull requests are welcome!

Software / Hardware Support

benlink uses bleak for BLE communication, making it compatible with Windows, macOS, and Linux. RFCOMM support is via python's built-in socket module, and also works on Windows, macOS, and Linux. (Although automatic service discovery for RFCOMM isn't supported yet).

The following radios should work with this library:

• BTech UV-Pro
• RadioOddity GA-5WB
• Vero VR-N76 (untested)
• Vero VR-N7500 (untested)
• BTech GMRS-Pro (untested)

If you know of other radios that use the same Benshi BLE / RFCOMM protocol, please open an issue to let me know!

Installation

To install the latest stable version of benlink from PyPI:

pip install benlink

If you're wanting to contribute to the project, clone the repository and install it in "editable" mode with

pip install -e .

Quick Start

First, make sure your radio is paired with your computer, and get its device UUID (e.g. XX:XX:XX:XX:XX:XX).

The following will connect to the radio and print its device info:

import asyncio
from benlink.controller import RadioController

async def main():
    async with RadioController.new_ble("XX:XX:XX:XX:XX:XX") as radio:
        print(radio.device_info)

asyncio.run(main())

Next Steps

To see what else you can do with this library, check out the examples in the benlink.controller module documentation.

Other Projects

Benlink has already begun to inspire other projects! Here are some that I know of so far:

• HTCommander

If you've found benlink's documentation of the Benshi protocol helpful, or use benlink in your own project, please let me know so I can add it to this list.

Known issues

If you don't have the audio RFCOMM socket open, and try to send any data with benlink.controller.RadioController.send_tnc_data, it will immediately reply with a INCORRECT_STATE error. If you immediately retry the command within two seconds, it will work. I plan to add a higher-level interface for sending / receiving TNC data that will automatically retry failed commands and queue / combine message fragments. See this open issue for more info.

Audio sending / receiving is a awkward because it relies on pyav for decoding / encoding. In the long run, I hope to make Python bindings for libsbc.

Roadmap

Things to do:

• Improve audio sending / receiving with bindings to libsbc (issue)
• Make a higher-level interface for sending / receiving TNC data (auto retry, queue message fragments) (issue)
• Figure out firmware flashing process / protocol (this is key for long-term independence from the HT app) (issue)
• Implement more commands and settings
• Find more radios that use this protocol and test them with this library

Acknowledgements

@spohtl for help figuring out audio transmit / receive

@na7q for early testing and feedback

Disclaimer

This project is an independent grassroots effort, and is not affiliated with or endorsed by Benshi, Vero, RadioOddity, BTech, or any other company.

Use this library at your own risk. I am not responsible for any damage caused to your radio or any other equipment while using this library.
