Berry Oximeter 🫀

A simple Python library for real-time data collection from BerryMed pulse oximeters via Bluetooth LE. Get heart rate, SpO2, and perfusion index readings with just a few lines of code!

[!WARNING] This library is for educational and research purposes only. It is not intended for medical diagnosis or treatment. Always consult with a qualified healthcare provider for medical advice.

Features ✨

• 🔌 Auto-discovery - Automatically finds and connects to your BerryMed device
• 📊 Real-time streaming - Get live readings with customizable callbacks
• 📈 Data collection - Collect readings over time for analysis
• 💾 CSV logging - Built-in data logging to CSV files
• 🎯 Signal filtering - Filter readings by signal quality
• 🐍 Pythonic API - Simple, intuitive interface
• 🧪 Type hints - Full type hint support for better IDE experience

Installation 📦

Install via pip:

pip install berry-oximeter

Or using uv:

uv add berry-oximeter

Quick Start 🚀

Basic Usage

from berry_oximeter import BerryOximeter

# Create instance and connect
oximeter = BerryOximeter()
oximeter.connect()

# Enable console output
oximeter.log_to_console(True)

# Let it run for 30 seconds
import time

time.sleep(30)

# Disconnect
oximeter.disconnect()

Callback-based Streaming

def handle_reading(reading):
    if reading.is_valid:
        print(f"♥ SpO2: {reading.spo2}%, Pulse: {reading.pulse_rate} BPM")
    else:
        print(f"Status: {reading.status}")


oximeter = BerryOximeter()
oximeter.connect()
oximeter.start_streaming(handle_reading)

# Stream for 60 seconds
time.sleep(60)

oximeter.stop_streaming()
oximeter.disconnect()

Data Collection & Analysis

# Collect 60 seconds of data
oximeter = BerryOximeter()
oximeter.connect()

readings = oximeter.get_readings(duration_seconds=60)

# Analyze the data
valid_readings = [r for r in readings if r.is_valid]
avg_spo2 = sum(r.spo2 for r in valid_readings) / len(valid_readings)
avg_pulse = sum(r.pulse_rate for r in valid_readings) / len(valid_readings)

print(f"Average SpO2: {avg_spo2:.1f}%")
print(f"Average Pulse: {avg_pulse:.1f} BPM")

oximeter.disconnect()

CSV Logging

oximeter = BerryOximeter()
oximeter.connect()

# Start logging (auto-generates filename with timestamp)
filename = oximeter.start_logging()
print(f"Logging to: {filename}")

# Or specify your own filename
# oximeter.start_logging("patient_123.csv")

# Collect data
oximeter.log_to_console(True)
time.sleep(300)  # 5 minutes

# Stop logging
oximeter.stop_logging()
oximeter.disconnect()

Context Manager (Auto-cleanup)

with BerryOximeter() as oximeter:
    oximeter.connect()
    oximeter.log_to_console(True)
    time.sleep(30)
    # Automatically disconnects when done

API Reference 📚

BerryOximeter Class

The main interface for interacting with the pulse oximeter.

Connection Methods

• connect(device_address=None, timeout=10.0) - Connect to device
• disconnect() - Disconnect from device
• is_connected - Property to check connection status

Data Access Methods

• start_streaming(callback) - Start streaming with callback function
• stop_streaming() - Stop streaming
• get_reading(timeout=5.0) - Get a single reading
• get_readings(duration_seconds) - Collect readings for specified duration

Logging Methods

• start_logging(filename=None) - Start CSV logging
• stop_logging() - Stop logging and return filename
• log_to_console(enabled=True) - Enable/disable console output

Configuration

• set_filter(min_signal_strength=None) - Filter by signal quality (0-8)

OximeterReading Object

Each reading contains:

• timestamp - When the reading was taken
• spo2 - Oxygen saturation (%) or None
• pulse_rate - Heart rate (BPM) or None
• pleth - Plethysmograph value or None
• signal_strength - Signal quality (0-8)
• is_valid - True if SpO2 and pulse are valid
• status - Human-readable status ("reading", "no_finger", "searching", etc.)

Exceptions

• DeviceNotFoundError - No BerryMed device found
• ConnectionError - Failed to connect to device
• NoDataError - No data received within timeout

Advanced Usage 🔧

Filtering Low-Quality Signals

# Only accept readings with signal strength >= 5
oximeter.set_filter(min_signal_strength=5)


def quality_callback(reading):
    print(f"High quality: SpO2 {reading.spo2}%, Signal: {reading.signal_strength}/8")


oximeter.start_streaming(quality_callback)

Custom Logging

import csv


def custom_logger(reading):
    if reading.is_valid:
        with open('custom_log.csv', 'a', newline='') as f:
            writer = csv.writer(f)
            writer.writerow([
                reading.timestamp,
                reading.spo2,
                reading.pulse_rate,
                reading.pleth,
                reading.signal_strength
            ])


oximeter.start_streaming(custom_logger)

Async Integration

Since the library runs BLE operations in a separate thread, it works well with async code:

import asyncio


async def monitor_patient(patient_id, duration):
    oximeter = BerryOximeter()
    oximeter.connect()
    oximeter.start_logging(f"patient_{patient_id}.csv")

    await asyncio.sleep(duration)

    oximeter.stop_logging()
    oximeter.disconnect()


# Run multiple monitors concurrently
async def main():
    await asyncio.gather(
        monitor_patient("001", 300),
        monitor_patient("002", 300)
    )

Troubleshooting 🔍

Device Not Found

• Make sure your BerryMed oximeter is turned on
• Check that Bluetooth is enabled on your computer
• The device name should be "BerryMed" - if yours is different, you'll need to modify the code
• On Linux, you may need to run with sudo or add your user to the bluetooth group

Connection Issues

• Ensure the device isn't already connected to another application
• Try moving closer to the device
• Some devices may need to be in pairing mode

No Readings

• Make sure your finger is properly inserted
• Keep your hand still - movement affects readings
• Warm up cold fingers first
• Check the signal strength indicator

Supported Devices 📱

This library is tested with:

• BerryMed BM1000C
• Other BerryMed pulse oximeters using the BCI protocol

The library should work with any Berry device that:

• Advertises as "BerryMed" over Bluetooth LE
• Uses the standard BCI protocol (5-byte packets)

Contributing 🤝

Contributions are welcome! Please feel free to submit a Pull Request. For major changes, please open an issue first to discuss what you would like to change.

1. Fork the repository
2. Create your feature branch (git checkout -b feature/AmazingFeature)
3. Commit your changes (git commit -m 'Add some AmazingFeature')
4. Push to the branch (git push origin feature/AmazingFeature)
5. Open a Pull Request

Acknowledgments 🙏

• Thanks to the Bleak project for the excellent BLE library
• Inspired by the need for simple, reliable pulse oximeter data collection in research settings
