Binade

Bit-exact compression of BF16 LLM weights for Apple Silicon (MLX), and for NVIDIA GPUs through MLX's CUDA backend.

A BF16 weight keeps its sign and mantissa as one raw byte. Its 8-bit exponent (the weight's binade) is replaced by its frequency rank in a per-tensor table, stored on disk in Rice codes at about 10.75 bits per weight instead of 16. At load, the ranks become a 4-bit runtime layout that Metal kernels read directly during inference.

The outputs are bit-identical to the original model, not merely close. The kernels reproduce the summation order of MLX's own BF16 kernels, so prompt logits and generated tokens match the uncompressed model exactly.

Results

Apple M4 Max, 48 GB, MLX 0.32.2. Every number comes from a script in scripts/; its output is in results/.

The 26B exactness check compares against a BF16 reference that reads one layer at a time from disk, since BF16 does not fit in memory.

• Matvec kernel. Batch-1 matvec on the 12B's shapes runs at 100% of BF16's bandwidth efficiency, 1.33x BF16 per token (kernel test).
• Prompt processing (12B matmuls). 1.30x BF16 at 16 prompt rows, 0.77 to 0.90x at 32 to 128, and 0.95x at 2048 (prefill_bench).

NVIDIA GPUs

MLX 0.32.2's CUDA backend. Exactness: logits at all 16,352 WikiText-2 positions per model identical to BF16; for Gemma 4 12B and 26B-A4B on every GPU listed, also with the fused prompt kernels forced onto every prompt length.

Multi-row products in MLX's CUDA backend go to cuBLAS, which is closed. Its BF16 GEMM order can still be reproduced: each output is a sequence of tensor-core MMA steps along K, split-K partitions follow a fixed rule, and cuBLASLt reports which algorithm and split it chose. The algorithms differ by GPU (one of them, on the A100 and L4, sums K in two slices), so the fused prompt kernels run only for algorithms verified on that GPU (binade/mlx/cublas_plan.py, tests/test_cuda_gemm.py); anything else rebuilds BF16 weights for cuBLAS, which is exact by construction.

How it works

• No exponent locality. Neighbouring weights do not share exponents: per-tile palettes gain only 0.011 to 0.027 bits per weight over a shuffled tensor on four models (comparison). Binade therefore codes frequency ranks from one table per tensor.
• Two file formats. Format 1 uses fixed width per 128-weight tile with escapes (11.27 bits per weight). Format 2, the default, uses Rice codes (10.75 bits per weight).
• Runtime layout. At load a GPU kernel turns either format into R4: every rank in 4 bits, with rare escapes. R4 takes 12.07 bits per weight in memory, and its matvec streams at full bandwidth.
• Exactness. The matvec, the MoE expert gather and the GEMM mirror MLX's own kernels step for step. Where they cannot, the runtime rebuilds the BF16 weight and calls MLX, which is exact by construction.

DESIGN.md has the formats, the runtime layout and the exactness argument.

Install

Python 3.11 or newer on Apple Silicon (or Linux with CUDA 12). Exactness depends on MLX's own kernels, so MLX and mlx-lm are pinned (0.32.2 and 0.31.3).

pip install binade               # Apple Silicon
pip install "binade[cuda]"       # Linux + CUDA 12

To run the tests or reproduce the results, install from a clone with the extras (requirements.lock has the exact versions the results used):

git clone https://github.com/GuyShafir/binade && cd binade
pip install -e ".[dev,eval,figures]"                  # add cuda on Linux: ".[dev,eval,figures,cuda]"

Use

Load a published Binade model straight from the Hugging Face Hub (the Binade organization), or pack one yourself from the Hugging Face cache or a local directory:

hf download google/gemma-4-12B-it
binade pack google/gemma-4-12B-it --out models/gemma-4-12B-it-binade

Run it with mlx-lm:

from mlx_lm import generate
from binade.mlx.r4 import load

model, tokenizer, _ = load("Binade/gemma-4-12B-it")      # or a local packed directory
messages = [{"role": "user", "content": "Why is the sky blue?"}]
prompt = tokenizer.apply_chat_template(messages, add_generation_prompt=True)
print(generate(model, tokenizer, prompt, max_tokens=200))

binade unpack <packed-dir or Hub repo id> --out DIR rebuilds the original BF16 checkpoint, bit for bit.

Verify and reproduce

• scripts/roundtrip_test.py: every tensor of a packed model against the original, bit for bit.
• scripts/generate_check.py: greedy decoding against the BF16 model (--reference streamed for models that do not fit).
• scripts/exactness_scale.py: logits at 16,352 positions and 32 generations against BF16 (resident or streamed), optionally with the fused kernels forced.
• scripts/decode_speed.py, scripts/matvec_bench.py, scripts/prefill_bench.py, scripts/prompt_speed.py, scripts/cuda_gemm_bench.py: speed.
• scripts/fit_probe.py: which variants load on a GPU; scripts/reference_check.py: MLX against the reference implementation.
• scripts/histogram.py, scripts/mutual_info.py, scripts/iid_model.py, scripts/compare.py, scripts/exponent_patch.py: the exponent statistics.
• pytest: unit and kernel tests, including order-sensitive data that exposes any change in summation order.

Result files record the commit of the development repository that produced them; that history is not published. Early result files use the project's working name, xp.

Limitations

• Tied to MLX's internals. Exactness relies on MLX 0.32.2's kernels and dispatch rules. A different MLX version or GPU generation can change the summation order, and the tests would catch it. The fused GEMM is enabled only on M3 and M4 GPUs.
• Validated models. Gemma 4 12B, E4B and 26B-A4B, Llama 3.1 8B and Qwen3.5 9B: bit-identical to BF16 at every one of 16,352 WikiText-2 positions per model, and in greedy generation (results/*/exactness_scale.md).
• E-models. Gemma 4 E-models keep their per-layer embedding tables in BF16.
• Prompt processing. Prefill at 32 to 128 prompt rows runs at 0.77 to 0.90x BF16. On long prompts, a model without memory headroom for rebuilding weights runs the fused GEMM at 0.75x the speed of MLX's.
• Quantization is faster. Lossy 8-bit quantization is faster and smaller; Binade's case is exactness.
• CUDA. Decoding runs at 1.01 to 1.10x BF16; prompts take longer (1.3x BF16's time to the first token after 40 tokens on the RTX PRO 6000). The fused prompt kernels cover dense products up to 128 rows and every expert product, on the RTX PRO 6000, L4 and A100; longer dense prompts, and dense prompts on other GPUs, rebuild BF16 weights for cuBLAS.

Related work

Binade codes the same exponent redundancy as:

• DFloat11 (Huffman, arXiv 2504.11651);
• ZipServ (fixed-width exponent windows fused into GEMM, arXiv 2603.17435);
• Unweight (per-tensor palettes, Cloudflare);
• ENEC (frequency ranks, arXiv 2604.03298);
• NeuZip (arXiv 2410.20650) and ZipNN (arXiv 2411.05239).

We found no public implementation of lossless compressed inference on Metal.

Paper

paper/binade.pdf: the exponent statistics behind the format, the exactness argument, and the evaluation on Apple Silicon and NVIDIA GPUs. The LaTeX source is in paper/latex; paper/latex/make_assets.py generates its tables and figures from results/.

License

Apache-2.0 (LICENSE). Model weights keep their own licenses.
