BlenderLens: game assets built, checked and exported by Blender itself

An MCP server that lets an AI agent work in Blender itself: build and shape objects with Blender's own operations, look at a rendered preview, check the asset against a triangle budget and your project's rules, and export a .glb that is read back from disk and judged for Godot or three.js.

A short animated scene that an AI agent made in Blender through BlenderLens, shown at double speed.

Why

An agent that models through Blender Python is working blind. It cannot see what it built, cannot tell whether the exported file holds what it meant, and learns about a part that did not export, or an import hint it never intended, only when the game shows it.

BlenderLens never judges an asset from what the agent intended. It asks Blender, and the written file. Measured on Blender 5.0.1, on a scene with a 0.5 m crate, a lid named Lid_col parented to it, and a metaball:

Approach	Result
bpy.ops.export_scene.gltf(...) from a script	{'FINISHED'} and a 3,244-byte file. Nothing more
check_asset	passed: false: the metaball is an error (surface_not_exported), and the crate's origin sits in its middle, not on its base (origin_not_at_base)
export_glb with target: "godot"	The file read back from disk: one root, Crate, 24 triangles. Warnings that the metaball was written with no mesh, that Godot gives Lid_col a StaticBody3D because of its name, and that the root stands 0.25 m off the origin

That principle, ask Blender and the file, never assume, runs through every tool. The building tools return what Blender now holds. render_preview renders the scene with Blender. check_asset reads the mesh as the exporter will write it. export_glb reads back the file it wrote.

Requirements

	Needed for
Blender 4.2 LTS or later (tested on 4.2 and 5.0)	everything; found through BLENDER_BIN, PATH, or the usual install folders
Python 3.10+, or Node.js 18+ for npx	running this server, which has no dependencies
The BlenderLens add-on in Blender	only to watch the agent work in a Blender window

Blender 4.2 is the floor because it is the oldest LTS release with the extension system the add-on installs through. An older Blender is refused with a clear message. No GPU is needed: previews and bakes render with Cycles on the CPU.

Install

npx (recommended). The package bundles the server, and needs Python 3.10 or later on PATH.

{
  "mcpServers": {
    "blenderlens": {
      "command": "npx",
      "args": ["-y", "blenderlens-mcp"],
      "env": { "BLENDER_BIN": "C:\\Program Files\\Blender Foundation\\Blender 5.0\\blender.exe" }
    }
  }
}

pip

pip install blenderlens-mcp

{
  "mcpServers": {
    "blenderlens": { "command": "blenderlens-mcp", "env": { "BLENDER_BIN": "/path/to/blender" } }
  }
}

In Claude Code this goes in a project's .mcp.json. That is all a headless pipeline needs: the first call that needs Blender starts blender --background, and the server keeps it until the server exits.

Watching it work in Blender

To have the agent work in a Blender window you watch, and can undo, install the add-on:

blenderlens-mcp install-addon       # or: npx -y blenderlens-mcp install-addon; --blender PATH picks the Blender

Then, in the 3D viewport, press N, open the BlenderLens tab and press Start. The add-on listens on this machine only, and serves only a server that holds its token, which it writes to a file the server reads.

The loop

The tools are designed around one cycle. Read it once and the rest of this document is a reference.

flowchart LR
    B["<b>Build</b><br/>create_object<br/>edit_mesh<br/>set_material"]
    L["<b>Look</b><br/>render_preview<br/>get_object"]
    C["<b>Check</b><br/>check_asset<br/>measure_objects"]
    D["<b>Deliver</b><br/>export_glb<br/>save_file"]

    B --> L --> C --> D
    L -- "not right yet" --> B
    C -- "an issue" --> B

    classDef step fill:#f5f7fa,stroke:#4a6785,stroke-width:1px,color:#1b2733;
    class B,L,C,D step;

1. Build. create_object makes a part with its size built into the mesh, edit_mesh shapes it, set_material colours it, and join_objects and set_parent assemble parts. An existing build script runs as it is with run_script.
2. Look. render_preview renders the part, or a sheet of several angles, as a PNG to look at. get_object gives exact sizes and counts.
3. Check. check_asset finds broken geometry, unapplied scale, a misplaced origin, UV and texture problems, parts passing through each other, and anything over budget or against your rules, each with the faces concerned. measure_objects says what touches what.
4. Deliver. export_glb writes the file for your target engine, reads it back and warns. save_file keeps the .blend.

Three conventions apply throughout:

• Units are metres, rotations degrees, and Z is up. A model's front faces -Y; export_glb converts to glTF's Y-up, where the front faces +Z.
• Face indices are what get_mesh lists, and change after any edit that adds or removes faces. edit_mesh returns the faces it made.
• A refusal changes nothing. It is a structured error with error, exit, kind and hint. The kinds, with their exit codes: blender_error 1, not_found 2, bad_argument 3, python_error 4, unsaved_changes 5, blender_missing 6, not_connected 7, connection_lost 8, start_failed 9, version_mismatch 10, token_mismatch 11, busy 12, not_allowed 13, internal_error 70, deadline 124.

Tools

Session

Tool	Description
get_status	Which Blender the server is using and what it is busy with, without starting one. Start here if anything behaves oddly.
open_session	Connect to the Blender window running the add-on, or start a background Blender, optionally opening a .blend.
close_session	Disconnect. A background Blender exits; a window stays open. Refused while there are unsaved changes, unless discard.

Inspecting

Tool	Description
get_scene	Every object with its type, parent, location, dimensions, counts, materials and modifiers.
get_object	One object in full: transform, bounds, counts before and after modifiers, and every modifier setting.
get_mesh	An object's faces with index, centre, normal, the side they face and material: the indices other tools take.
list_materials	Every material's values and the objects using it.

Building

Tool	Description
create_object	A primitive, a tube along a path, a lathed profile, 3D text, or an empty. Sizes go into the mesh, so scale stays 1.
create_mesh	A mesh from vertices and faces, for shapes no primitive gives.
edit_mesh	Extrude, inset, bevel, bisect, solidify, subdivide and more, on faces picked by index or by the way they face.
add_modifier	Add any Blender modifier, with settings by Blender's own names.
set_modifier	Change a modifier's settings, place in the stack, or visibility.
apply_modifier	Make a modifier's result part of the mesh.
remove_modifier	Remove a modifier without applying it.
set_material	Create or update a PBR material, with emission, transparency, culling and images, on an object or picked faces.
set_vertex_color	Paint faces into a color attribute, wired so the file carries it as COLOR_0.
unwrap_uv	Unwrap into a UV map, and report islands, overlaps and texel density.
join_objects	Join meshes into one part, each piece keeping its materials.
animate_object	Key transforms and shape keys into a named clip, exported as one glTF animation. Warns when Godot will loop it by name.
create_collision	A box, convex or decimated collision proxy, named so Godot makes a static body of it.
bake_texture	Bake colour, ambient occlusion, normals or lighting into a PNG with Cycles, and wire it into the material.

Arranging

Tool	Description
set_transform	Location, rotation, scale or dimensions. With drop, the object falls until it rests on what is below.
apply_transform	Apply rotation and scale to the mesh, or move the origin, for example to the bottom centre.
set_parent	Parent or unparent, keeping the world position.
set_collection	Move objects into a collection.
set_object	Rename, hide, or set custom properties, which export as glTF extras.
duplicate_object	Copy an object with its modifiers, materials and children.
delete_object	Delete objects.

Checking

Tool	Description
check_asset	Check the asset as it will export, against a triangle budget and your project's rules. Returns passed and each issue with its faces. Changes nothing.
measure_objects	Distances between parts, whether they touch, overlap or sit inside each other, or a ray cast into the scene.

Seeing

Tool	Description
render_preview	A framed PNG from any angle, or a sheet of several views; clay, wireframe and per-part colour styles; cutaways and fixed game cameras. The scene is left as it was.

Files

Tool	Description
export_glb	Write a .glb for godot, threejs or generic, read it back from disk, and warn about what the target will make of it.
export_file	Write FBX, OBJ, STL, PLY or USD, and read it back.
import_file	Import a glTF, OBJ, FBX, STL or PLY file, or append objects from a .blend.
save_file	Save the .blend, or a checkpoint copy.
open_file	Open a .blend.
create_file	Start a new, empty file.

Python and undo

Tool	Description
run_python	Python inside Blender, for anything no tool covers.
run_script	Run a build script file, with its helper modules importable.
undo_change	Step back through the calls that changed the scene, one undo step each.

Checking in CI

blenderlens-mcp check runs the same checks from the command line, with no agent. It exits 0 when the asset passes, 1 when it fails, and 2 when it could not be checked; --json prints the full result. A .glb is read on its own, with no Blender; a .blend is opened in a background Blender.

blenderlens-mcp check crate.glb --budget 2000 --target godot --rules rules.json

A project's rules are a JSON object. Each key is optional:

Key	Fails when
required	a named object, or a "Parent/Child" path, is missing
single_root	the asset does not have exactly one root object
retired	an object or material has a name the project no longer uses
palette, palette_only	a material's colour or values differ from the palette, or a material is not in it
extras	a custom property is missing or of the wrong type
size	an object measures outside its range, in metres
origin_at_base	an origin is not at the bottom of the object
budget	the asset, or a named part, has too many triangles
apart	two parts that must not touch pass through each other

A name may also be a pattern, "re:<regular expression>". examples/rules.json is a complete rule set, and examples/build_lantern.py builds, checks and exports a prop through the server from start to finish.

What Blender cannot tell you

Worth knowing before you trust a result:

• Python is unrestricted. run_python and run_script can do anything Python can inside Blender, including quitting it. Set BLENDERLENS_ALLOW_PYTHON=0, or turn off Allow Python from the agent in the add-on, where that matters.
• Blender's glTF exporter writes a metaball as an empty node. check_asset reports metaballs as errors, and export_glb warns about them.
• drop finds supports at vertices. When the only contact would be edge against edge, such as one bar lying across another, that support is missed and the object drops past it.
• A Principled BSDF inside a node group is invisible to BlenderLens, so it will not change that material's values.
• In a Blender window, a preview marks the file as changed, because Blender does so whenever the render engine is set, even back to the same one.
• Godot 4.7.0 to 4.7.2 ignore vertex colours on a mesh's first primitive. export_glb warns about affected meshes when the target is godot.

Architecture

Two ways to reach Blender, one set of commands.

flowchart TD
    Agent["AI Agent"]
    BL["<b>BlenderLens</b><br/>MCP server · JSON-RPC 2.0<br/>Python 3.10+ · no dependencies"]

    Agent <-- "stdio" --> BL

    BL -- "TCP 9877<br/>with its token" --> Window
    BL -- "starts and owns" --> Background

    Window["<b>Blender window</b><br/>add-on started<br/><i>you watch, and can undo</i>"]
    Background["<b>blender --background</b><br/>no window<br/><i>lives as long as the server</i>"]

    classDef svc fill:#eef4fb,stroke:#4a6785,stroke-width:1px,color:#1b2733;
    classDef blender fill:#f3f0fb,stroke:#6b5b95,stroke-width:1px,color:#1b2733;
    class Agent,BL svc;
    class Window,Background blender;

BLENDERLENS_MODE chooses: auto uses the window when its add-on is started, and a background Blender otherwise. Both run the same command code, on Blender's main thread, where bpy may be used; mesh work goes through bmesh, so it behaves the same with or without a window. Each call that changes the scene is one undo step.

The MCP protocol and the link to Blender are implemented on the standard library, so the package has no runtime dependencies. docs/architecture.md maps the modules, and docs/decisions/ records why each part is built as it is.

Configuration

Variable	Default	Description
BLENDER_BIN	auto	Blender executable, for background sessions, check and install-addon
BLENDERLENS_MODE	auto	auto, live (the window only) or background
BLENDERLENS_HOST	127.0.0.1	Where the server connects to the add-on: localhost or a loopback IPv4 address
BLENDERLENS_PORT	9877	The add-on's port, as set in its preferences
BLENDERLENS_TOKEN	from the add-on's file	Overrides the token the add-on writes for the server
BLENDERLENS_TIMEOUT	120	Seconds to wait for one call; render_preview, bake_texture, run_python and run_script also take timeout
BLENDERLENS_START_TIMEOUT	90	Seconds to wait for a background Blender to start
BLENDERLENS_RENDER_DIR	a temp folder	Where previews go when given no path; in the default folder they are kept 7 days
BLENDERLENS_ALLOW_PYTHON	1	0 removes run_python and run_script
BLENDERLENS_ALLOWED_DIRS	not set	Folders every path given to a tool must be inside; ; separates them on Windows, : elsewhere
BLENDERLENS_RUNTIME_DIR	per user	Where the add-on's token file and recovery copies of unsaved background work are kept

License

Apache License 2.0 — see LICENSE and NOTICE. BlenderLens is not affiliated with or endorsed by the Blender Foundation.
