A Compositional Operation Toolbox for Gradient-based Bi-Level Optimization

Home | Installation | Docs | Tutorials | Examples

BOAT is a compositional OperAtion-level Toolbox for gradient-based BLO. Unlike existing libraries that typically encapsulate fixed solver routines, BOAT factorizes the BLO workflow into atomic, reusable primitives. Through a unified constraint reconstruction perspective, it empowers researchers to automatically compose over 85+ solver variants from a compact set of 17 gradient operations.

This is the Jittor-based version of BOAT (boat-jit). It leverages Jittor’s Just-In-Time (JIT) compilation and efficient CUDA/cuDNN backends to significantly accelerate large-scale gradient-based BLO experiments.

BOAT supports unified execution across backends via separate branches:

• PyTorch-based: The widely-used standard version.
• MindSpore-based: Optimized for ascending chips and industry scenarios.

🔑 Key Features

• 🧩 Compositional Operation-Level Abstraction: Deconstructs BLO solvers into three modular stages: Gradient Mapping (GM), Numerical Approximation (NA), and First-Order (FO).
• ⚡ Accelerated JIT Execution: Built on Jittor, enabling meta-operator fusion and high-performance execution on NVIDIA GPUs.
• 🏭 Generative Solver Construction: Supports dynamic serialization of operations. Users can recover classical algorithms or discover novel hybrid solvers simply by changing configurations.
• 🛠 Configuration-Driven: Define complex optimization strategies via simple JSON configurations, decoupling algorithmic logic from model definitions.
• ✅ Comprehensive Testing: Achieves 99% code coverage through rigorous testing with pytest, ensuring software robustness.

📚 Supported Operation Libraries

🔨 Installation

BOAT-jit is built on top of Jittor. Please ensure Jittor is installed correctly before installing BOAT.

1. Install Jittor

Follow the Official Installation Guide or use the commands below:

Linux (Ubuntu / CentOS)

sudo apt install python3.8-dev libomp-dev
python3.8 -m pip install jittor
# Verify installation (Optional)
python3.8 -m jittor.test.test_example

Windows

python -m pip install jittor
python -m jittor.test.test_core

macOS

brew install libomp
python3.8 -m pip install jittor

2. Install BOAT-jit

Once Jittor is ready, install BOAT-jit via PyPI or Source:

# Install from PyPI
pip install boat-jit

# Or install from Source (Specific Branch)
git clone -b boat_jit --single-branch https://github.com/callous-youth/BOAT.git
cd BOAT
pip install -e .

Note: examples/L2_Reg_jit additionally requires scikit-learn (pip install scikit-learn).

✅ Quick Verification

Run the following commands from the root directory of the BOAT repository:

python examples/L2_Reg_jit/l2_regularization.py

python examples/neural_architecture_search/neural_architecture_search.py

⚡ How to Use BOAT

BOAT separates the problem definition from the solver configuration. Below is a Jittor-based example.

1. Load Configurations

import json
import boat_jit as boat

# Load algorithmic configurations
with open("configs/boat_config.json", "r") as f:
    boat_config = json.load(f)

# Load objective configurations
with open("configs/loss_config.json", "r") as f:
    loss_config = json.load(f)

2. Define Models and Optimizers

Use standard Jittor models and optimizers.

import jittor as jit

# Define models
upper_model = MyUpperModel()
lower_model = MyLowerModel()

# Define optimizers (Jittor syntax)
upper_opt = jit.nn.Adam(upper_model.parameters(), lr=1e-3)
lower_opt = jit.nn.SGD(lower_model.parameters(), lr=1e-2)

3. Customize & Initialize Problem

Inject runtime objects into the configuration.

# Configure BOAT with Jittor models/optimizers
boat_config["lower_level_model"] = lower_model
boat_config["upper_level_model"] = upper_model
boat_config["lower_level_opt"] = lower_opt
boat_config["upper_level_opt"] = upper_opt

# Initialize the BOAT core
b_optimizer = boat.Problem(boat_config, loss_config)

4. Build Solvers

Inject runtime objects into the configuration.

# Pass optimizers explicitly if needed by the solver backend
b_optimizer.build_ll_solver(lower_opt)
b_optimizer.build_ul_solver(upper_opt)

5. Run Optimization Loop

# Training loop
for x_itr in range(1000):
    # Prepare data (Jittor Arrays or dicts)
    ul_feed_dict = {"data": ul_data, "target": ul_target}
    ll_feed_dict = {"data": ll_data, "target": ll_target}

    # Run one iteration
    loss, run_time = b_optimizer.run_iter(ll_feed_dict, ul_feed_dict, current_iter=x_itr)

    if x_itr % 100 == 0:
        print(f"Iter {x_itr}: UL Loss {loss:.4f}")

🌍 Applications

BOAT covers a wide spectrum of BLO applications, categorized by the optimization target:

• Data-Centric: Data Hyper-Cleaning, Synthetic Data Reweighting, Diffusion Model Guidance.
• Model-Centric: Neural Architecture Search (NAS), LLM Prompt Optimization, Parameter Efficient Fine-Tuning (PEFT).
• Strategy-Centric: Meta-Learning, Hyperparameter Optimization (HO), Reinforcement Learning from Human Feedback (RLHF).

📝 Citation

If you find BOAT useful in your research, please consider citing our paper:

@article{liu2025boat,
  title={BOAT: A Compositional Operation Toolbox for Gradient-based Bi-Level Optimization},
  author={Liu, Yaohua and Pan, Jibao and Jiao, Xianghao and Gao, Jiaxin and Liu, Zhu and Liu, Risheng},
  journal={Submitted to Journal of Machine Learning Research (JMLR)},
  year={2025}
}
