braggcalculator 0.2.1

Fast, validated and differentiable Bragg powder diffraction

BraggCalculator

BraggCalculator is a fast, validated powder X-ray and neutron diffraction engine for ideal periodic crystals. It evaluates reciprocal-space Bragg diffraction with NumPy or optional PyTorch kernels.

The current scientific scope is monochromatic, kinematic powder diffraction. It includes neutral-atom X-ray form factors, coherent elemental neutron scattering lengths, occupancies, isotropic Debye-Waller factors, the standard powder Lorentz or Lorentz-polarization correction, and area-normalized Gaussian profiles. Optional experimental-effect models can add angle-dependent instrument and sample broadening, preferred orientation, background, counting noise, missing channels, and spurious peaks to simulated profiles. These models do not cover diffuse scattering, absorption, anomalous X-ray terms, or instrumental wavelength distributions.

The accompanying paper describes the implementation, validation across the Crystallography Open Database, and CPU/GPU performance: read the ChemRxiv preprint.

Installation

Install the latest release from PyPI:

python -m pip install braggcalculator

Optional dependencies are available as extras:

python -m pip install "braggcalculator[torch]"  # Torch/autograd/CUDA backend
python -m pip install "braggcalculator[ase]"    # ASE structure input
python -m pip install "braggcalculator[all]"    # All optional dependencies

Python 3.12 and 3.13 are supported. To work from a source checkout, use python -m pip install -e ".[all]".

The API reference documents the public configuration, methods, and result conventions.

Quick start

from braggcalculator import BraggCalculator

calculator = BraggCalculator(mode="xray", wavelength="CuKa1")
calculator.load("structure.cif")

two_theta, integrated_intensity = calculator.line_pattern(scaled=True)
grid, profile = calculator.pattern()

line_pattern() returns the conventional merged powder lines. pattern() returns an area-normalized Gaussian profile on a regular grid. reflection_table() provides the corresponding HKLs, d-spacings, Q values, scattering angles, structure factors, and corrected intensities. The API reference documents lower-level reciprocal-point output and the rules for differentiable lattice changes.

The Q-space API uses inverse angstroms:

q, intensity = calculator.line_pattern(domain="q")
q_grid, profile_q = calculator.pattern(domain="q")

Experimental effects are opt-in and independently configurable:

from braggcalculator import (
    BackgroundArtifacts,
    NoiseArtifacts,
    PeakProfileArtifacts,
    SimulationArtifacts,
)

artifacts = SimulationArtifacts(
    profile=PeakProfileArtifacts(
        model="tch",
        caglioti_u=0.002,
        caglioti_w=0.004,
        crystallite_size_nm=40.0,
        microstrain=0.001,
    ),
    background=BackgroundArtifacts(constant=0.01),
    noise=NoiseArtifacts(poisson_count_scale=10_000),
    seed=7,
)
q_grid, augmented = calculator.pattern(domain="q", artifacts=artifacts)

SimulationArtifacts also supports calibration shifts, Bragg--Brentano specimen displacement, March--Dollase preferred orientation, amorphous humps, measured .xy/.xye backgrounds, correlated noise, detector gaps, saturation, quantization, and unindexed peaks. See the artifact API for the component objects, units, sampled-range controls, and background library format, and the artifact gallery for isolated examples of every effect family.

Torch and autograd

Symmetry detection and HKL enumeration are discrete preprocessing operations. Autograd therefore operates on a fixed reflection topology. Rebuild the calculator if a lattice change is large enough that reflections can enter or leave the configured Q range.

from braggcalculator import BraggCalculator
from braggcalculator.backends import TorchBackend

calculator = BraggCalculator(backend=TorchBackend(device="cpu")).load(
    "structure.cif"
)
parameters = calculator.tensor_parameters(
    requires_grad=["lattice", "frac_coords", "occupancies", "b_iso"]
)
grid, profile = calculator.pattern(parameters=parameters)
loss = profile.square().sum()
loss.backward()

Use TorchBackend(device="cuda") with a CUDA-enabled PyTorch installation to run the continuous diffraction and profile kernels on a GPU.

Species identities and reflection indices are intentionally not differentiable. Isotope-specific neutron samples can select a tabulated isotope through neutron_scattering_lengths={"H": "2H"} (or supply a measured/custom length) because pymatgen structures do not retain isotope identity.

By default, qmax is derived from the requested 2-theta and Q ranges and the physical Ewald limit. An explicit qmax that would truncate either output range is rejected instead of silently dropping reflections.

Scientific conventions

• Direct lattice vectors are rows in angstroms.
• g = 1 / d, Q = 2 pi / d, and s = sin(theta) / wavelength = g / 2.
• Isotropic displacement amplitudes use exp(-B s^2).
• Line intensities are |F|^2 times the powder Lorentz-polarization factor.
• Gaussian profile amplitudes are integrated areas, not peak heights.
• Every reciprocal point is evaluated explicitly. This makes systematic absences emerge from the full structure factor and avoids multiplicity double-counting.

X-ray coefficients, radiation wavelengths, and coherent elemental neutron lengths are read from the required pymatgen dependency. This keeps the source of physical values explicit and versioned rather than duplicating an unmaintained local table.

Validation and performance

BraggCalculator evaluates the same kinematic equations as pymatgen and does not prune the reciprocal set. In pymatgen 2026.5.4, each pattern rebuilds the reciprocal points and flattened site arrays, then a Python loop processes one reflection at a time; the site sum inside that reflection is vectorized. BraggCalculator reduces the primitive cell and constructs the exact reflection topology during load(). Its numerical kernel processes reflection-by-site chunks and merges equal-spacing lines with indexed reductions. Repeated calls reuse the topology, and reducible supercells perform numerical work on the primitive sites. These two savings are reported separately as cached and end-to-end timings.

Run the unit and analytical test suite:

python -m pytest -q

Validate X-ray and neutron peak positions and normalized intensities against pymatgen across cubic, diamond, perovskite, triclinic, disordered, and 40-atom P1 cells:

python scripts/validate_against_pymatgen.py

The frozen publication corpus extends this check to 70 CC0 CIFs from the Crystallography Open Database, balanced across all seven crystal systems and covering 62 declared space groups:

python scripts/validate_cif_corpus.py \
    --output paper/data/cif_validation_results.json

The manifest pins every COD revision and SHA-256 digest, and the result records all parser warnings and failures rather than dropping difficult cases.

Run the reproducible performance comparison. The command fails if either the cached or end-to-end calculation is not faster for every case:

python benchmarks/benchmark_against_pymatgen.py \
    --number 20 --repeat 7 --require-speedup 1 --json benchmark.json

Performance is machine- and dependency-version-specific, so benchmark JSON records the exact environment and all timing samples. The versioned scaling data, plotting commands, and CPU/CUDA protocol are documented in the paper README.

Demonstration

The NaCl demonstration loads a CIF, verifies the calculated powder lines against pymatgen, and writes an overlay with a residual panel:

python -m pip install -e . matplotlib
python demo/compare_with_pymatgen.py

The script stops if either implementation departs from the stated numerical tolerances.

The executable artifact-simulation notebook continues from a CIF through an ideal pattern, individual artifact components, an imported .xye background, and a reproducible combined simulation:

jupyter notebook notebooks/artifact_simulation.ipynb

Related software

BraggCalculator and DebyeCalculator provide complementary scattering models: BraggCalculator uses reciprocal-space translational symmetry for periodic crystals, whereas DebyeCalculator evaluates the real-space Debye scattering equation for finite, disordered, or non-crystalline structures.

Data and model references

• P. A. Doyle and P. S. Turner, Acta Crystallographica A 24, 390–397 (1968), DOI: 10.1107/S0567739468000756.
• V. F. Sears, Neutron News 3(3), 26–37 (1992), DOI: 10.1080/10448639208218770.
• The pymatgen diffraction documentation describes the independent oracle implementation used in validation.

License

Apache License 2.0. See LICENSE.
