brainpy-state 0.1.0

brainpy.state: stateful spiking neural network models in BrainPy

brainpy.state is one differentiable substrate that bridges brain simulation and brain-inspired computing. It is the point-neuron modeling layer of the BrainX ecosystem, built on JAX and brainstate.

The same building blocks let you run biophysical spiking networks and train them with gradient descent — because the projections that keep simulation memory-efficient are exactly what make gradient-based and online learning memory-efficient too. That bridge was introduced in the ICLR 2024 paper and is the keystone of the Core Concepts.

brainpy.state ships two model families, both production-ready:

• BrainPy-style models — high-level, composable neurons (LIF, ALIF, AdEx, HH, Izhikevich, …), synapses (Expon, Alpha, AMPA, GABAa, BioNMDA), the AlignPre/AlignPost projections, synaptic outputs (COBA / CUBA / MgBlock), short-term plasticity, readouts, and input generators, in the tradition of BrainPy. Differentiable through surrogate gradients out of the box.
• NEST-compatible models — JAX re-implementations of NEST simulator neurons, synapses, plasticity (STDP, STP), and devices that preserve NEST's parameter names and unit conventions, numerically validated against a live NEST install within documented tolerance bands.

All parameters carry physical units via brainunit, catching unit errors at construction time.

Key features

• One differentiable substrate — biophysical simulation and gradient-based / brain-inspired computing share the same neurons, synapses, and projections.
• Memory-efficient projections — the AlignPre/AlignPost design aligns synaptic state to the pre- or post-synaptic neurons (O(N)) instead of to individual synapses (O(N_pre · N_post)), without approximation. See the AlignPre/AlignPost concept page.
• Composable architecture — mix and match neurons, synapses, synaptic outputs (COBA / CUBA / MgBlock), and projections.
• Physical units everywhere — parameters use brainunit quantities (mV, ms, nS, …), preventing unit errors at construction time.
• Differentiable — surrogate gradients enable backpropagation through spiking networks for gradient-based training.
• NEST parameter parity — port models from NEST with minimal friction; the NEST-compatible family is numerically validated against a live NEST install within documented tolerance bands.
• Hardware-accelerated — JAX backend with JIT compilation for CPU, GPU, and TPU.

Installation

brainpy.state requires Python ≥ 3.11 and runs on Linux, macOS, and Windows.

pip install brainpy.state -U

For hardware-specific JAX backends:

pip install brainpy.state[cpu] -U     # CPU only
pip install brainpy.state[cuda12] -U  # CUDA 12.x
pip install brainpy.state[cuda13] -U  # CUDA 13.x
pip install brainpy.state[tpu] -U     # TPU

Or install the full BrainX ecosystem:

pip install BrainX -U

Quickstart

brainpy.state offers two entry points, depending on which family you reach for. Both examples build a model from the public brainpy.state namespace and run it on the JAX backend.

1. BrainPy-style — an excitatory–inhibitory balanced network

A COBA E/I network wired with the memory-efficient AlignPostProj. The synaptic state lives on the post-synaptic neurons (O(N_post)) — see the AlignPre/AlignPost concept page for why this is exact, not an approximation.

import brainpy
import brainstate
import braintools
import brainunit as u


class EINet(brainstate.nn.Module):
    def __init__(self):
        super().__init__()
        self.n_exc, self.n_inh = 3200, 800
        self.num = self.n_exc + self.n_inh
        self.N = brainpy.state.LIFRef(
            self.num,
            V_rest=-60. * u.mV, V_th=-50. * u.mV, V_reset=-60. * u.mV,
            tau=20. * u.ms, tau_ref=5. * u.ms,
            V_initializer=braintools.init.Normal(-55., 2., unit=u.mV),
        )
        self.E = brainpy.state.AlignPostProj(
            comm=brainstate.nn.EventFixedProb(self.n_exc, self.num,
                                              conn_num=0.02, conn_weight=0.6 * u.mS),
            syn=brainpy.state.Expon.desc(self.num, tau=5. * u.ms),
            out=brainpy.state.COBA.desc(E=0. * u.mV),
            post=self.N,
        )
        self.I = brainpy.state.AlignPostProj(
            comm=brainstate.nn.EventFixedProb(self.n_inh, self.num,
                                              conn_num=0.02, conn_weight=6.7 * u.mS),
            syn=brainpy.state.Expon.desc(self.num, tau=10. * u.ms),
            out=brainpy.state.COBA.desc(E=-80. * u.mV),
            post=self.N,
        )

    def update(self, t, inp):
        with brainstate.environ.context(t=t):
            spk = self.N.get_spike() != 0.
            self.E(spk[:self.n_exc])
            self.I(spk[self.n_exc:])
            self.N(inp)
            return self.N.get_spike()


net = EINet()
brainstate.nn.init_all_states(net)

# Drive the model with brainstate.transform.for_loop — never a bare Python loop.
with brainstate.environ.context(dt=0.1 * u.ms):
    times = u.math.arange(0. * u.ms, 1000. * u.ms, brainstate.environ.get_dt())
    spikes = brainstate.transform.for_loop(
        lambda t: net.update(t, 20. * u.mA), times,
    )

See examples/brainpy_like/103_COBA_2005.py for the full version with a spike raster.

2. NEST-like — a single neuron driven by a constant current

The NEST-compatible family uses an explicit Simulator with NEST's create / connect / simulate workflow and NEST's parameter names. Here a single iaf_psc_alpha is driven by a constant current I_e and observed by a voltmeter (connected in the reversed direction, as in NEST).

import jax
import brainpy
import brainstate
import brainunit as u

jax.config.update("jax_enable_x64", True)   # NEST-parity runs use float64
brainstate.environ.set(precision=64)

sim = brainpy.state.Simulator(dt=0.1 * u.ms)
neuron = sim.create(brainpy.state.iaf_psc_alpha, 1, I_e=376.0 * u.pA)
vm = sim.create(brainpy.state.voltmeter)
sim.connect(vm, neuron)              # reversed: the voltmeter observes the neuron

res = sim.simulate(1000.0 * u.ms)
v_m = res.trace(vm, "V_m")           # membrane potential trace (with units)

See examples/nest_like/one_neuron.py for the full version with plotting, and the NEST-compatible hub for the tutorials, model directory, and validation evidence.

Two model families

brainpy.state is organized around two model families that share one substrate — explicit State, physical units, and brainstate.transform-driven simulation. Both are production-ready; the API reference is organized by family for navigation, not by maturity.

BrainPy-style (native)

The idiomatic, composable layer: 45+ neurons, the AlignPre/AlignPost projections, synaptic outputs, short-term plasticity, readouts, and input generators. Every BrainPy-style neuron is differentiable through surrogate gradients, so the same model you simulate you can also train. Start with the BrainPy-style modeling guide.

NEST-compatible (validated against live NEST)

JAX re-implementations of NEST neurons, synapses, plasticity rules, and devices that keep NEST's parameter names and unit conventions, so you can port a NEST model with minimal friction. Rather than asking you to take fidelity on trust, every model carries live-NEST parity evidence: numerical agreement is checked against a real NEST install within documented tolerance bands. See the validation showcase for per-model parity results and tolerance categories.

Documentation

Full documentation: https://brainx.chaobrain.com/brainpy-state/

• Get started (install → run → mental model): https://brainx.chaobrain.com/brainpy-state/get-started/index.html
• Core concepts (the bridging thesis; AlignPre/AlignPost keystone): https://brainx.chaobrain.com/brainpy-state/concepts/index.html
• BrainPy-style modeling: https://brainx.chaobrain.com/brainpy-state/brainpy-style/index.html
• NEST-compatible hub (tutorials, models, validation): https://brainx.chaobrain.com/brainpy-state/nest-style/index.html
• API reference: https://brainx.chaobrain.com/brainpy-state/apis/index.html
• Examples: https://brainx.chaobrain.com/brainpy-state/examples/brainpy-gallery.html

Examples and tutorials

Runnable examples live in examples/: BrainPy-style scripts under examples/brainpy_like/ and NEST-compatible ports under examples/nest_like/. They are catalogued in the BrainPy-style gallery and the NEST gallery. Highlights:

• E-I balanced networks, COBA and CUBA variants
• Gamma oscillations (Susin & Destexhe 2021: AI, CHING, ING, PING mechanisms)
• Surrogate-gradient training on Fashion-MNIST and MNIST
• Joglekar et al. 2018 cortical propagation model
• NEST ports: Brunel random balanced networks, gap-junction networks, astrocyte networks

Contributing

Contributions are welcome. Please read CONTRIBUTING.md for the development setup, coding conventions, testing guidance, and documentation workflow (including how to document new APIs and how to record live-NEST validation/parity evidence for NEST-compatible models).

Ecosystem

brainpy.state is one part of the BrainX ecosystem:

Package	Description
brainstate	State management for JAX-based brain modeling
brainunit	Physical units for neuroscience
brainevent	Event-driven sparse operators
braintools	Surrogate gradients, analysis, and utilities
braintrace	Linear-memory online learning for spiking networks

Citing

If you use brainpy.state, please consider citing the following:

@article {10.7554/eLife.86365,
    article_type = {journal},
    title = {BrainPy, a flexible, integrative, efficient, and extensible framework for general-purpose brain dynamics programming},
    author = {Wang, Chaoming and Zhang, Tianqiu and Chen, Xiaoyu and He, Sichao and Li, Shangyang and Wu, Si},
    editor = {Stimberg, Marcel},
    volume = 12,
    year = 2023,
    month = {dec},
    pub_date = {2023-12-22},
    pages = {e86365},
    citation = {eLife 2023;12:e86365},
    doi = {10.7554/eLife.86365},
    url = {https://doi.org/10.7554/eLife.86365},
    journal = {eLife},
    issn = {2050-084X},
    publisher = {eLife Sciences Publications, Ltd},
}

@inproceedings{wang2024a,
    title={A differentiable brain simulator bridging brain simulation and brain-inspired computing},
    author={Chaoming Wang and Tianqiu Zhang and Sichao He and Hongyaoxing Gu and Shangyang Li and Si Wu},
    booktitle={The Twelfth International Conference on Learning Representations},
    year={2024},
    url={https://openreview.net/forum?id=AU2gS9ut61}
}

License

brainpy.state is released under the Apache License 2.0. See LICENSE for the full text.
