Calibrate Pro

Make screens match the work with profiles, LUTs, monitor control, and verification reports.

Project Telos | gather | crucible | index | forum | telos | calibrate-pro

Calibrate Pro is a Windows display-calibration toolkit for characterized and measured workflows. It combines display discovery, calibration targets, DDC/CI, ICC/VCGT and LUT tooling, and evidence-labelled reports behind one preview-and-confirm workflow. Sensorless values are explicitly labelled as estimates; measured values require an instrument and retain their evidence source.

Try it

calibrate-pro doctor
calibrate-pro list-targets
calibrate-pro list-panels
calibrate-pro gui

Install from the Windows release build or run from source with pip install -e ".[all]".

Why it matters

Display color is part of the creative pipeline. If the screen is wrong, every design, render, photo, video grade, and model-generated visual can be judged against a bad reference. Calibrate Pro gives a practical path to better display behavior, records what changed, and keeps verification close to the profile.

What to test first

• Launch calibrate-pro gui, select a display, and inspect the detected identity and available capabilities.
• Choose a method and target, then review the exact plan before deciding whether to confirm any supported display change.
• Complete the GUI workflow and inspect the evidence-labelled result or report; values remain estimated or Not measured unless they came from an instrument.

Current status

• Release: Calibrate Pro 1.1.0; command calibrate-pro; Python 3.10+ on Windows 10/11; per-user installer and portable package.
• Operator surface: a PySide6 desktop workflow plus read-only CLI diagnostics, target and panel listings, HDR status, patterns, and plugin discovery. Legacy mutation-capable CLI names are proposal-only and point to the GUI rather than changing display state.
• Safety boundary: Detect -> Method -> Preview -> Apply -> Verify -> Save/Report. The application starts unelevated. A display change requires an exact preview and explicit confirmation; rejection performs no write.
• Evidence boundary: reports distinguish measured, estimated, simulated, replayed, and Not measured values instead of presenting model output as an observation.

Install

Standalone (Windows)

Download the per-user installer or portable ZIP from Releases. No Python installation is required. Both desktop entry points start unelevated; unavailable hardware or operating-system capabilities fail closed and are reported by calibrate-pro doctor.

The 1.1.0 Windows artifacts are not Authenticode-signed, so Windows may show a SmartScreen warning. Verify the downloaded file against the release's SHA256SUMS.txt before running it.

From source

git clone [e-mail]:HarperZ9/calibrate-pro.git
cd calibrate-pro
pip install -e ".[all]"
calibrate-pro

Requires Python 3.10+ and Windows 10/11.

Usage

Launch the installed application or run calibrate-pro gui. Read-only CLI surfaces include:

calibrate-pro doctor            # Read-only installation/capability diagnostics
calibrate-pro doctor --json     # Stable machine-readable diagnostics
calibrate-pro list-targets      # List calibration targets
calibrate-pro list-panels       # List characterized panel profiles
calibrate-pro info <panel>      # Show stored characterization evidence
calibrate-pro hdr-status        # Query Windows HDR state
calibrate-pro patterns          # Display visual test patterns
calibrate-pro gui               # Launch the calibration workflow

Run calibrate-pro --help for the complete command list. Old direct-action names such as auto, calibrate, restore, and verify are proposal-only in 1.1: they do not mutate the display and instead direct the operator to preview and confirm through the GUI.

See the usage guide for installation, command behavior, evidence labels, troubleshooting, and the read-only example.

How It Works

1. Detects the selected display and reports available capabilities.
2. Chooses a sensorless or measured method and calibration target.
3. Previews an immutable plan, including bounded DDC changes and SHA-256-bound external assets.
4. Confirms the exact plan with a one-use confirmation before the first write.
5. Applies only supported operations after capturing restorable prior state; failures trigger verified compensation.
6. Verifies the result and labels every performance value by evidence kind.
7. Saves the approved profile, LUT, and/or report. Background guard behavior is monitor-and-notify only in 1.1.

Calibration Modes

Mode	Requires	Evidence
Sensorless	A characterized panel profile or EDID-derived inputs	Estimated; never presented as a measurement of the attached unit
Measured	A supported colorimeter	Instrument observations with source/provenance attached

Without a colorimeter there is no measurement of the attached unit. Calibrate Pro therefore renders unavailable observations as Not measured and labels model-derived diagnostics as estimated.

Native USB Colorimeter

Built-in USB HID driver for the X-Rite i1Display3 family (i1Display Pro, ColorMunki Display, Calibrite ColorChecker Display). No ArgyllCMS required.

Native USB HID driver for the i1Display3 family reads per-unit calibration matrices from each device's EEPROM - 9 stored matrices for different display technologies (OLED, WhiteLED, CCFL, WideGamut, etc.). Falls back to approximate constants if EEPROM reading fails.

Supported Displays

58 characterized panels with DDC/CI recommendations:

• QD-OLED (17): ASUS PG27UCDM, Samsung G6/G7/G8/G9, Dell AW3423DW/DWF/AW2725DF/AW3225QF, MSI 321URX
• WOLED (10): LG C2/C3/C4/G4, ASUS PG27AQDP/PG34WCDM, LG 34GS95QE
• IPS (20): Dell U2723QE/U3224KB, ASUS ProArt PA279CRV, BenQ SW271C/SW272U, EIZO CS2740/CG2700X
• Nano-IPS (2): LG UltraGear 27GP950-B, LG UltraGear 27GP850-B
• Mini-LED (4): ASUS PG32UCDM, Apple Pro Display XDR
• VA (3): Samsung Odyssey G7, Sony INZONE M9
• RGB OLED (2): ASUS ProArt PA32DC

Unknown monitors are calibrated using EDID chromaticity data.

Output Files

File	Usage
.cube	33x33x33 3D LUT (DaVinci Resolve, OBS, any LUT app)
.clf	ACES Common LUT Format (SMPTE ST 2136-1)
.icc	ICC v4 profile (Windows/macOS color management)
.3dlut	MadVR format
_reshade.png	ReShade LUT texture
_specialk.png	Special K LUT texture
_obs.cube	OBS Studio LUT
_mpv.conf	mpv player config snippet
_report.html	Calibration report with CIE diagram, gamma curves, gamut coverage

Architecture

calibrate_pro/
  core/           Color math, LUT engine, ICC v4 profiles
  panels/         Display detection, 58-panel database, DDC recommendations
  sensorless/     Sensorless calibration engine (Oklab/JzAzBz gamut mapping)
  calibration/    Native measurement loop, CCMX spectral correction
  hardware/       i1Display3 native USB, DDC/CI with retry + WMI fallback
  lut_system/     DWM 3D LUT, VCGT gamma ramp, AMD/NVIDIA API
  verification/   12 patch sets (287 patches), grayscale tracking, PDF export
  services/       CalibrationGuard, GamutClamp, AppSwitcher, DriftMonitor
  gui/            PySide6 desktop workflow and read-only system tray
  platform/       Windows (full) + macOS (planned)

Color Science

• Perceptual spaces: Oklab, JzAzBz, ICtCp, CAM16-UCS, CIE Lab/Luv
• Transfer functions: PQ (ST.2084), HLG (BT.2100), sRGB, BT.1886, BT.2390 EETF
• Color spaces: sRGB, Display P3, Rec.2020, AdobeRGB, ACES
• Gamut mapping: Oklab perceptual compression (SDR), JzCzhz for HDR
• Chromatic adaptation: Bradford transform, D50/D65 illuminants
• Verification: CIEDE2000 + CAM16-UCS, 12 patch sets (287 patches)

Building

# From source
pip install -e ".[all]"
calibrate-pro gui

# Reproducible Windows release (locked dependencies and release gates)
powershell -File scripts/build_windows.ps1

Dependencies

Required: Python 3.10+, numpy, scipy, build-color GUI: PySide6 + QtPy + Build UI 2 (pip install ".[gui]") Sensor: hidapi (pip install ".[sensor]") Windows distribution: includes the audited runtime dependencies and notices required by the release manifest, including the approved dwm_lut runtime files.

License

FSL-1.1-MIT. Copyright (c) 2022-2026 Zain Dana Harper. Source-available, not open source: read it, run it, and build on it; commercial Competing Use is reserved to the Licensor to fund continued development. See the license.

For developers

Keep the public README, package metadata, and examples aligned with current behavior. Before opening a PR or pushing a release, run the local package verification path.

python -m pip install -e ".[test]"
python -m pytest
