CellRank for directed single-cell fate mapping

Project description

PyPI Bioconda Downloads CI CI-Notebooks Documentation Coverage

CellRank for directed single-cell fate mapping

CellRank is a toolkit to uncover cellular dynamics based on Markov state modeling of single-cell data. It contains two main modules: kernels compute cell-cell transition probabilities and estimators generate hypothesis based on these. Our kernels work with a variety of input data including RNA velocity (see La Manno et al. (2018) and Bergen et al. (2020)), cellular similarity (both transcriptomic and spatial) and pseudotime, among others. Our VelocityKernel takes into account uncertainty in the velocities and allows you to aggregate the short-range fate relations given by RNA velocity into longer trends along the phenotypic manifold. Our main estimator is Generalized Perron Cluster Cluster Analysis (G-PCCA) GPCCA18 which coarse-grains the Markov chain into a set of macrostates which represent initial, terminal and intermediate states. For each transient cell, we compute its fate probability towards any terminal state. We show an example of such a fate map in the figure above, which has been computed using the data of pancreatic endocrinogenesis. CellRank combines kernels and estimators with a powerful plotting API, enabling you to visualize e.g. smooth gene expression trends along lineages or fate-informed circular embeddings, to name just a few.

CellRank scales to large cell numbers, is fully compatible with scanpy and scvelo and is easy to use. For installation instructions, documentation and tutorials, visit


Please check out our manuscript Lange et al. (2022) in Nature Methods to learn more.

Getting started with CellRank

If you’re new to CellRank, make sure to go though the basic tutorial which introduces you to CellRank’s high-level API. Most biological systems require a bit more control, so be sure to check out the kernels and estimators tutorial which allows to unlock the full power of CellRank. If you want to see individual functions in action, visit our gallery.

CellRank’s key applications

  • compute initial & terminal as well as intermediate macrostates of your biological system
  • infer fate probabilities towards the terminal states for each individual cell
  • visualize gene expression trends along specific lineages while accounting for the continuous nature of fate determination
  • identify potential driver genes for each identified cellular trajectory


Install CellRank by running:

conda install -c conda-forge -c bioconda cellrank
# or with extra libraries, useful for large datasets
conda install -c conda-forge -c bioconda cellrank-krylov

or via PyPI:

pip install cellrank
# or with extra libraries, useful for large datasets
pip install 'cellrank[krylov]'
# or with external modules, see External API
pip install 'cellrank[external]'

Why is it called “CellRank”?

CellRank does not rank cells, we gave the package this name because just like Google’s original PageRank algorithm, it works with Markov chains to aggregate relationships between individual objects (cells vs. websites) to learn about more global properties of the underlying dynamics (initial & terminal states and fate probabilities vs. website relevance).


We welcome your feedback! Feel free to open an issue, send us an email or tweet if you encounter a bug, need our help or just want to make a comment/suggestion.


We actively encourage any contribution! To get started, please check out both the contribution guide as well as the external API. CellRank’s modular structure makes it easy to contribute, be it a new method to compute cell-cell transition probabilities (kernels), a new way to analyze a transition matrix (estimators) or an addition to the plotting API. If you’re thinking of contributing a new kernel, we have a kernel tutorial that guides you trough the process.

CellRank was developed in collaboration between the Theislab and the Peerlab.
