ckanext-orcid 0.1.0

ORCID integration with CKAN

ckanext-orcid

ORCID SSO integration for CKAN. Allows users to log in to your CKAN instance using their ORCID iD via OAuth2.

Requirements

Compatibility with core CKAN versions:

CKAN version	Compatible?
2.10	not tested
2.11+	yes

Installation

1. Clone the source and install it on the virtualenv:

git clone https://github.com/DataShades/ckanext-orcid.git
cd ckanext-orcid
pip install -e .

2. Add orcid to the ckan.plugins setting in your CKAN config file:

ckan.plugins = ... orcid

3. Run the database migration:

ckan db upgrade

4. Configure your ORCID credentials (see Obtaining ORCID credentials below).

5. Restart CKAN.

Obtaining ORCID credentials

To enable ORCID login you need to register an application in the ORCID developer portal and obtain a Client ID and Client Secret.

Using the sandbox (recommended for development)

The ORCID sandbox is a free test environment with no real user data.

1. Create a sandbox account at https://sandbox.orcid.org/register.
2. Log in and go to Developer Tools (under your account name menu).
3. If prompted, verify your email address first.
4. Click Register for the free ORCID public API.
5. Fill in the application details:
   • Name — your portal's name
   • Website URL — your CKAN instance URL (e.g. http://127.0.0.1:5000)
   • Description — short description of your portal
   • Redirect URIs — add your callback URL: http://127.0.0.1:5000/orcid/callback (replace the host with your actual domain in production)
6. Save. You will be shown a Client ID (format APP-XXXXXXXXXXXXXXXXX) and Client Secret.

Set in your CKAN config:

  ckanext.orcid.client_id = APP-XXXXXXXXXXXXXXXXX
  ckanext.orcid.client_secret = your-client-secret
  ckanext.orcid.sandbox = true

Using the production ORCID registry

1. Log in (or register) at https://orcid.org.
2. Go to Developer Tools under your account menu.
3. Click Register for the free ORCID public API and follow the same steps as above, using your production redirect URI (e.g. https://yourckan.example.org/orcid/callback).
4. Copy the Client ID and Client Secret.

Set in your CKAN config:

ckanext.orcid.client_id = APP-XXXXXXXXXXXXXXXXX
ckanext.orcid.client_secret = your-client-secret

Note: ckanext.orcid.sandbox defaults to false, so omit it (or set it to false) for production.

Members API

Email retrieval from ORCID requires access to the ORCID Members API, which is only available to ORCID member organisations. The public API used above supports authentication (verifying a user's identity) but not reading private profile data such as email addresses. If your organisation is an ORCID member, contact ORCID support to obtain member API credentials and a separate client ID/secret with the /read-limited scope.

Config settings

Setting	Required	Default	Description
ckanext.orcid.client_id	yes	—	OAuth2 Client ID from the ORCID developer portal
ckanext.orcid.client_secret	yes	—	OAuth2 Client Secret from the ORCID developer portal
ckanext.orcid.sandbox	no	false	Set to true to use the ORCID sandbox environment

Tests

pytest --ckan-ini=test.ini

License

AGPL
