COASTSim: ConOps Astronomical Space Telescope Simulator

A Python module for simulating Concept of Operations (ConOps) for space telescopes and astronomical spacecraft missions.

Overview

COASTSim is a comprehensive simulation framework designed to model and analyze the operational behavior of space-based astronomical observatories. It enables mission planners and engineers to simulate Day-In-The-Life (DITL) scenarios, evaluate spacecraft performance, optimize observation schedules, and validate operational constraints before launch.

The package is organized into logical submodules for better maintainability and clearer separation of concerns: common (utilities), config (configuration), ditl (simulation), schedulers (planning), targets (observations), and simulation (core components).

Key Features

• Spacecraft Bus Simulation: Model power systems, attitude control, and thermal management
• Orbit Propagation: TLE-based ephemeris computation and orbit tracking
• Observation Planning: Target queue management and scheduling algorithms
• Instrument Modeling: Multi-instrument configurations with power and pointing requirements
• Constraint Management: Sun, Moon, Earth limb, and custom geometric constraints
• Power Budget Analysis: Solar panel modeling, battery management, and emergency charging scenarios
• Ground Station Passes: Communication window calculations and data downlink planning
• Attitude Control System: Slew modeling, pointing accuracy, and settle time simulation
• South Atlantic Anomaly (SAA) Avoidance: Radiation belt constraint handling
• DITL Generation: Comprehensive day-in-the-life timeline simulation
• Plan Export: Versioned JSON plans with optional TLE provenance and executed attitude and orbit-state sidecars

Installation

From Source

git clone https://github.com/CosmicFrontierLabs/coast-sim.git
cd coast-sim
pip install -e .

Requirements

• Python >= 3.10
• See pyproject.toml for full dependency list

Key dependencies include:

• astropy - Astronomical calculations and coordinate systems
• numpy - Numerical computations
• matplotlib - Visualization
• rust-ephem - Efficient ephemeris calculations
• pydantic - Configuration validation
• shapely - Geometric operations

Quick Start

Basic DITL Simulation

from datetime import datetime, timedelta
from conops import Config, QueueDITL
from rust_ephem import TLEEphemeris

# Load configuration
config = Config.from_json_file("example_config.json")

# Set simulation period
begin = datetime(2025, 11, 1)
end = begin + timedelta(days=1)

# Compute orbit ephemeris
ephemeris = TLEEphemeris(tle="example.tle", begin=begin, end=end)

# Run DITL simulation
ditl = QueueDITL(config=config)
# Field-of-regard telemetry is optional and disabled by default.
# Enable it only when needed:
# ditl = QueueDITL(config=config, calculate_field_of_regard=True)
ditl.ephem = ephemeris
ditl.begin = begin
ditl.end = end
ditl.calc()

# Export the executed plan. When available, attitude and orbit-state sidecars
# are written beside the plan JSON and linked from it.
plan_path = ditl.plan.save("observation_plan.json")

# Analyze results
ditl.plot()
ditl.print_statistics()

Configuration-Based Approach

Create a JSON configuration file defining your spacecraft parameters:

{
    "name": "My Space Telescope",
    "spacecraft_bus": {
        "power_draw": {
            "nominal_power": 50.0,
            "peak_power": 300.0
        },
        "attitude_control": {
            "slew_acceleration": 0.01,
            "max_slew_rate": 1.0
        }
    },
    "solar_panel": {
        "panels": [...]
    },
    "instruments": {
        "instruments": [...]
    }
}

Examples

Comprehensive examples are provided in the examples/ directory as Jupyter notebooks:

• Example_Spacecraft_DITL.ipynb: Complete spacecraft DITL simulation with custom spacecraft configuration, including power modeling, attitude control, and observation scheduling
• Example_DITL_from_JSON.ipynb: Simplified workflow using JSON configuration files for quick simulations

To run the examples:

cd examples
jupyter notebook

Visualization

COASTSim includes a set of plotting utilities to visualize DITL simulations and telemetry. Each visualization function accepts an optional config parameter. If omitted, the plots will use ditl.config.visualization if present, or reasonable defaults defined by VisualizationConfig.

Key plotting utilities are in the conops.visualization module:

• plot_ditl_telemetry() — show RA, Dec, ACS mode, battery, power, and ObsIDs in a multi-panel timeline
• plot_data_management_telemetry() — recorder volume/fill fractions, cumulative data generated/downlinked, and alert timelines
• plot_acs_mode_distribution() — pie chart of time spent in each ACS mode; supports custom mode colors
• plot_ditl_timeline() — full timeline view with orbit numbers, observations, slews, SAA, and eclipses
• plot_sky_pointing() — interactive mollweide sky projection showing current pointing, patterns, and constraints

How to customize fonts and colors

Custom visualization settings are controlled via the VisualizationConfig Pydantic model (conops.config.visualization). Important fields include:

• font_family (str): font used for titles, labels, and legends (default: Helvetica)
• title_font_size, label_font_size, legend_font_size, tick_font_size (int)
• mode_colors (dict[str, str]): color mapping for ACS modes used in plots such as plot_acs_mode_distribution

Example — customizing fonts and colors

from conops import Config, QueueDITL
from conops.visualization import plot_ditl_telemetry, plot_acs_mode_distribution
from datetime import datetime, timedelta
from rust_ephem import TLEEphemeris

cfg = Config.from_json_file("examples/example_config.json")
cfg.visualization.font_family = "Helvetica"
cfg.visualization.title_font_size = 14
cfg.visualization.mode_colors["SAA"] = "#800080"  # purple

begin = datetime.utcnow()
end = begin + timedelta(days=1)
ephem = TLEEphemeris(tle="examples/example.tle", begin=begin, end=end)
ditl = QueueDITL(config=cfg)
ditl.ephem = ephem
ditl.calc()

# Render using the resolved visualization config
fig, axes = plot_ditl_telemetry(ditl)
fig2, ax2 = plot_acs_mode_distribution(ditl, config=cfg.visualization)

Tip: Set cfg.visualization to keep consistent fonts and colors across every plot end-to-end. Note that the requested font must be installed on your system; Matplotlib may fallback to another font (e.g., DejaVu Sans or Arial) if the requested family isn't available. To guarantee a specific font, use a FontProperties object with the font file path.

Core Components

Configuration (conops.config)

Pydantic-based configuration management for spacecraft parameters, instruments, and operational constraints.

DITL Simulation (conops.ditl)

Day-In-The-Life simulation classes including DITL, DITLMixin, and QueueDITL for comprehensive timeline simulation.

Instantaneous field-of-regard telemetry (for_solid_angle_sr) is optional and disabled by default for performance. To enable it, pass calculate_field_of_regard=True when creating DITL or QueueDITL.

Scheduling (conops.schedulers)

Target observation queue management and intelligent scheduling algorithms (DumbScheduler, DumbQueueScheduler).

Targets (conops.targets)

Target management classes including Pointing, Queue, TargetList, Plan, and PlanEntry for observation planning and portable plan export.

Simulation (conops.simulation)

Core simulation components including ACS (Attitude Control System), slew modeling, SAA handling, emergency charging, and other simulation utilities.

Common Utilities (conops.common)

Shared utilities, enums (ACSMode, ChargeState, ACSCommandType), vector mathematics, and common functions.

Module Structure

conops/
├── __init__.py              # Package initialization and exports
├── _version.py              # Version information
├── common/                  # Shared utilities and common functions
│   ├── __init__.py
│   ├── common.py
│   ├── enums.py
│   └── vector.py
├── config/                  # Configuration management
│   ├── __init__.py
│   ├── config.py
│   ├── constants.py
│   ├── constraint.py
│   ├── battery.py
│   ├── solar_panel.py
│   ├── instrument.py
│   └── spacecraft_bus.py
├── ditl/                    # Day-In-The-Life simulation
│   ├── __init__.py
│   ├── ditl.py
│   ├── ditl_mixin.py
│   └── queue_ditl.py
├── schedulers/              # Scheduling algorithms
│   ├── __init__.py
│   ├── scheduler.py
│   └── queue_scheduler.py
├── targets/                 # Target management and planning
│   ├── __init__.py
│   ├── pointing.py
│   ├── plan.py
│   ├── plan_entry.py
│   └── target_queue.py
└── simulation/              # Core simulation components
    ├── __init__.py
    ├── acs.py
    ├── acs_command.py
    ├── emergency_charging.py
    ├── passes.py
    ├── roll.py
    ├── saa.py
    ├── slew.py
    └── ephemeris.py

Testing

The project includes a comprehensive test suite:

pytest tests/

The test suite includes a COAST-owned default plan output regression check. Run it directly when reviewing planner/output changes:

python scripts/check_default_plan_output.py

If a planner change intentionally changes the default output, update and review the checked-in baseline:

python scripts/check_default_plan_output.py --update

Run with coverage:

pytest --cov=conops tests/

Documentation

Full API documentation is available in the docs/ directory and can be built using Sphinx.

Building Documentation

Install documentation dependencies:

pip install -e ".[docs]"

Build the HTML documentation:

cd docs
make html

The built documentation will be available in docs/_build/html/index.html.

For more information, see docs/README.md.

Development

Setup Development Environment

pip install -e ".[dev]"
pre-commit install

Code Quality

This project uses:

• ruff: Linting and code formatting
• mypy: Static type checking
• pytest: Testing framework
• pre-commit: Git hooks for code quality

Use Cases

• Mission Planning: Evaluate operational scenarios before launch
• Performance Analysis: Assess power budgets, observation efficiency, and data return
• Schedule Optimization: Test different scheduling algorithms and target prioritization
• Constraint Validation: Verify observational constraints are satisfied
• Trade Studies: Compare different spacecraft configurations and operational strategies
• Operations Training: Simulate realistic mission scenarios for operations teams

Contributing

Contributions are welcome! Please:

1. Fork the repository
2. Create a feature branch
3. Add tests for new functionality
4. Ensure all tests pass and code quality checks succeed
5. Submit a pull request

License

See LICENSE file for details.

Author

Jamie A. Kennea Email: jak51@psu.edu

Acknowledgments

Developed for space telescope mission planning and operational analysis.

Project Status

Development Status: Production/Stable

For questions, issues, or feature requests, please open an issue on GitHub.
