codebread 1.0.4

Interactive codebase analyzer & visualizer — slice open a project and see how it's wired together.

Slice open any codebase and see how it's actually wired together.
An interactive, zero-dependency map of files → functions → API routes → database tables.

---

What is this

CodeBread scans a project, extracts every function and class, maps how everything connects — frontend → API → backend → database — and renders it as an interactive node-graph in your browser. Click a file to slice it open into its functions; click a function to see everything it calls and everything that calls it, with the full chain lit up end to end.

The problem it solves: dropping into a codebase you didn't write — or one an AI generated for you — and not knowing where anything is. Reading files one at a time doesn't build a mental model fast. CodeBread builds the model for you: it finds the routes, follows the fetch() calls to the handlers that answer them, follows the handlers to the tables they touch, and draws the whole path.

Why I built this

This started as a personal tool. I kept generating projects with AI and then staring at the result with no idea how the pieces fit together — which file called which, where the API boundary actually was, what touched the database. I wanted something that would just show me, instead of me grepping through the tree file by file. CodeBread is that tool.

It's a v1.0 — actively used by me on my own projects, and I'll keep adding to it. If it's useful to you too, that's a bonus. Issues and PRs are welcome.

What it's built with

• Backend/analysis engine: pure Python standard library — no required third-party packages, nothing to pip install beyond Python itself. Parsing is stdlib ast for Python and structural regex for everything else (see language table below).
• Frontend: vanilla JavaScript + SVG, no framework, no build step, no npm install. The entire UI is three files (app.js, index.html, style.css).
• Serving: a tiny local server built on http.server from the stdlib.

That's it. Clone it, run it, nothing to compile.

---

Install

pip install codebread

Optional extra (better .gitignore matching while scanning):

pip install codebread[full]        # adds pathspec

Requires Python 3.9+. Nothing else.

Prefer running from source instead (e.g. to contribute)?

git clone https://github.com/honow48-tech/CodeBread.git
cd CodeBread
pip install .                      # or: python codebread.py --path /path/to/project

Use

codebread --path /path/to/project        # scan + open the UI in your browser
codebread                                # prompts for the path

That's the whole quick start: point it at a folder, a browser tab opens with the map already scanned.

CLI reference

Flag	What it does
--path, -p PATH	root folder to scan (prompted if omitted)
--port 8137	local server port (auto-picks a free one nearby if taken)
--json out.json	export the full graph as JSON
--load out.json	re-open a saved scan without re-scanning
--html out.html	export a self-contained static HTML file you can share
--diff old.json new.json	compare two saved scans and print what changed (files/functions/tables added, removed, changed)
--no-open	don't auto-open the browser
--no-serve	scan + export only, don't start the server
--version	print the installed version

---

What you get

• Explorer sidebar — the full folder tree, expandable like a file explorer; every file tagged with its layer color.
• Orbit layout (default) — files float freely in space, spread apart so connections stay untangled. Expand a file and its functions arrange in a clean ring around it, spoked by straight lines back to the center. A Free force-directed layout is also available (toggle bottom-right).
• Focus mode — clears the canvas so you inspect one file at a time: pick a file in the Explorer and only it, its functions, and its direct connections show up. Toggle it off to go back to the full overview.
• Progressive reveal (OSINT-style) — click a file to slice it open into its numbered functions; click a function to draw in what it calls and what calls it. Dense codebases stay readable.
• Full-chain highlight — select any node and its complete end-to-end chain lights up (frontend fetch() → GET /api/users route → handler → users table), everything unrelated dims.
• Right-click for actions — a context menu on every node, edge, and the empty canvas: reveal connections, focus a file, open it in the IDE view, jump to a route's source/target, copy a name or path, and more.
• Insights panel — flags orphaned functions (no detected callers) and circular call chains, both clickable to jump straight to them.
• Diff mode — compare two saved scans (--diff old.json new.json) to see exactly what changed between them.
• Minimap + breadcrumb — a live minimap of the whole graph with a draggable viewport, and a breadcrumb showing the real folder path of whatever's currently selected.
• Keyboard navigation — ←/→ step through a selected node's neighbors, ↑/↓ walk back/forward through your selection history, / to search.
• Detail panel — params, return type, auto-generated description ("Function 3 · handles GET /api/users · queries users"), every caller and callee, clickable.
• View the actual code — every function has an expandable ▸ View code section: syntax-highlighted source with real line numbers. A full IDE view (⌗) opens any file whole, with an outline sidebar.
• Search (/) and layer filter (Frontend / Backend / Database / Config) in the header.
• Warnings, never silence — unreadable files, unsupported languages and permission problems show up as ⚠ badges and in the warnings list, never hidden. Secrets found in config files are always masked.

Language support

Parser used per language, then exactly what gets extracted — checked feature by feature against the actual parser code, not a marketing table:

Language	Parser	Functions / methods	Classes / structs	Backend routes	Outgoing API calls	ORM / DB models	Raw SQL	Call graph	Page-nav links
Python	stdlib ast (precise)	✅	✅	✅ Flask / FastAPI / Django	✅ requests / httpx / aiohttp / urllib	✅ SQLAlchemy / Django / peewee / tortoise	✅	✅	–
JavaScript / TypeScript / JSX / TSX	regex + brace matching	✅	✅	✅ Express / Fastify / Koa / NestJS	✅ fetch / axios	✅ Mongoose / Prisma / Sequelize / Knex / TypeORM	✅	✅	–
Vue / Svelte	regex, <script> block only¹	✅	✅	✅ (same as JS)	✅ (same as JS)	✅ (same as JS)	✅	✅	–
Java	regex	✅	✅	✅ Spring @*Mapping	–	–	✅	✅	–
C#	regex	✅	✅	✅ ASP.NET [Http*]	–	–	✅	✅	–
Go	regex	✅	✅ (structs)	✅ Gin / net-http style	–	–	✅	✅	–
PHP	regex	✅	✅	✅ Laravel Route::	–	–	✅	✅	✅
Ruby	regex	✅	✅	✅ Rails / Sinatra	–	–	✅	✅	✅
SQL (.sql files)	regex	–	–	–	–	✅ CREATE TABLE schemas + columns	✅	–	–
Config (.env, json/yaml/toml/ini/xml…)²	key scan	–	–	–	–	–	–	–	–
Anything else (Rust, Kotlin, Swift, C/C++, Scala, Elixir, Erlang, Lua, R, Perl, Dart, Zig…)	–	–	–	–	–	–	–	–	–

Unsupported languages still show up in the Explorer tree with an "⚠ Unsupported — parsing skipped" badge — never silently dropped — they just have no functions/edges to draw.

¹ Vue/Svelte only parse the <script> block — template-only bindings (@click, v-on, Svelte reactive markup) aren't extracted. ² Config-format files get a DB-connection-settings scan instead of code extraction — credentials always masked, see export.py-embedded source too. Files like settings.py or config.js are parsed as their real language (full extraction above), not this bucket — only non-code formats (json/yaml/toml/ini/.env/xml/properties) land here.

Only Python's ast-based parser captures real parameter type annotations, return types, and docstrings — every regex-based parser above extracts parameter names only.

How it classifies layers

Score-based heuristics combining framework import signatures (React/Vue → frontend, Flask/Express → backend, SQLAlchemy/Prisma → database), folder conventions (/client, /server, /models…), file extensions, and extracted facts (defines routes → backend, defines models → database). Ambiguous files are marked Unclassified instead of guessed.

How orphan + cycle detection works

• Orphaned functions: any function/method with zero detected incoming calls, that isn't a route handler and isn't a common framework entry point (__init__, main, setUp, test functions, …). Flagged with a badge on the node and listed in the Insights panel — a good starting point for finding dead code (heuristic, not exhaustive: it can miss calls the static parser doesn't recognize).
• Circular call chains: an iterative cycle-detection pass over the call graph (no recursion, so it's safe on large codebases) flags functions that call each other in a loop, both on the node (↻ badge) and as a listed chain in the Insights panel.

Project layout

codebread.py              ← runnable entry point (no install needed)
codebread/
  cli.py                  ← argparse CLI
  scanner.py              ← .gitignore-aware recursive walker
  languages.py             ← language detection / binary sniffing
  parsers/
    python_parser.py      ← ast-based Python extractor
    javascript_parser.py  ← JS/TS/Vue/Svelte extractor
    generic_parser.py     ← Java/C#/Go/PHP/Ruby + SQL + config
  classifier.py           ← frontend/backend/database/config scoring
  connections.py           ← call graph + API↔route + fn↔table matching +
                               orphan/cycle detection
  analyzer.py              ← pipeline orchestration
  diff.py                  ← compares two saved scans
  server.py                ← stdlib local web server
  export.py                ← JSON + single-file HTML export
  web/                     ← the UI (vanilla JS + SVG, zero dependencies)
tests/                     ← pytest suite + per-language fixture corpus
assets/                    ← logo (.svg source + .png for the README —
                               GitHub blocks same-repo SVG <img> embeds)

---

Testing

pip install -e ".[full,test]"
pytest -q

The suite covers every parser (a small fixture file per language under tests/fixtures/), the connection/graph builder (call resolution, API↔route matching, DB edges, orphan + cycle detection), the scanner (.gitignore handling, language detection), the local server (including a regression test for the path-traversal fix), and an end-to-end analyze pass — including a regression test that secrets in scanned .env files never leak into an exported graph. CI (.github/workflows/ci.yml) runs it on every push/PR across the minimum and latest supported Python versions, and the PyPI release workflow won't publish if it fails.

Roadmap

Already done as of v1.0:

• Orphaned-function and circular-dependency detection
• Diff mode between two scans
• Focus mode, orbit layout, right-click actions, minimap, breadcrumb
• Automated test suite + CI

Not yet, but planned:

• "Explain this function" — a plain-language AI summary button
• More precise multi-language parsing (currently structural regex for everything but Python)

Have an idea? Open an issue.

Contributing

This is a young, actively-changing personal project, so keep that in mind — but contributions are genuinely welcome:

• Bugs / ideas → open an issue with a repro or a description.
• Pull requests → welcome, especially for language parser improvements or UI polish. Keep the zero-dependency philosophy: the core tool should keep running on nothing but the Python standard library, and the UI should keep running on vanilla JS with no build step.
• Run pytest -q before opening a PR (see Testing above); add a fixture + test case under tests/ for new parser behavior where you can.

Security issue instead? See SECURITY.md rather than a public issue.

License

MIT — use it, modify it, ship it, sell it. No attribution required beyond keeping the license file. See LICENSE for the full text.
