dash-leaflet2

dash-leaflet2 — Leaflet 2 maps for Dash

Leaflet 2-native mapping components for Plotly Dash 4.

No react-leaflet · unified Pointer Events · BlanketOverlay canvas/WebGL layers · ES6-class subclassing · ResizeObserver sizing · map rotation · liquid-glass theme · full Dash callback interoperability.

Documentation · Discord · YouTube · GitHub

Live at leaflet.2plot.dev — every map on the docs site is a running Dash app.

Maintained by Pip Install Python LLC.

Overview

dash-leaflet is frozen on react-leaflet → Leaflet 1.9. react-leaflet has no Leaflet 2 line, and its architecture is built around Leaflet 1.x's context and lifecycle model — so a Leaflet-2-native component cannot ride react-leaflet.

dash-leaflet2 wraps Leaflet 2 core directly through a small React-context bridge. That sheds the entire react-leaflet abstraction layer and unlocks v2's headline features:

• Unified Pointer Events — one event model for mouse, touch and stylus. The Leaflet event's .originalEvent is a native PointerEvent, so pointerType, pressure and tiltX / tiltY reach your Python callbacks
• BlanketOverlay canvas / WebGL layers — draw your own renderer across the whole viewport instead of fighting the DOM layer system
• ES6-class subclassing — extend Leaflet 2 classes in plain JS and mount the result as a Dash component
• ResizeObserver sizing — no more grey tiles when a map is born inside a hidden tab, accordion or drawer
• Map rotation — bearing as a first-class, two-way prop, with a keyboard control
• Liquid-glass theme — tooltips, popups, the zoom bar and attribution use color-mix() + backdrop-filter, so they read correctly in light and dark mode

The package ships the compiled JS bundle — Leaflet 2, the marker images and the theme CSS all live inside dash_leaflet2.js. A normal pip install needs no Node and no external_scripts.

Status: alpha. This tracks Leaflet 2.0.0-alpha.1, so the 0.x line is itself alpha and APIs will move until v2 leaves alpha upstream. See CHANGELOG.md for what's shipped, fixed and known-broken.

Watch the introduction

Dash Leaflet 2.0: Drone Tracking, Image Overlays & Map Packages in Python

Drone tracking, image overlays and map packages, built with this library.

Installation

pip install dash-leaflet2

Requires dash>=4.1. See Dash compatibility for the tested matrix.

Quick Start

from dash import Dash, Input, Output, callback, html
import dash_leaflet2 as dl2

app = Dash(__name__)

app.layout = html.Div([
    dl2.Map(
        id="map",
        center=[28.0206, -97.0544],
        zoom=12,
        style={"height": "70vh"},
        children=[
            dl2.TileLayer(url="https://tile.openstreetmap.org/{z}/{x}/{y}.png"),
            dl2.Marker(
                id="pin",
                position=[28.0206, -97.0544],
                draggable=True,
                children=dl2.Tooltip("Drag me"),
            ),
        ],
    ),
    html.Pre(id="out"),
])


@callback(Output("out", "children"), Input("pin", "position"))
def show(position):
    return f"marker at {position}"


if __name__ == "__main__":
    app.run(debug=True)

Drag the pin and position round-trips to Python. No JS, no external_scripts, no Leaflet CSS link — the bundle carries all of it.

Documentation

Full documentation, with a live interactive demo on every page:

📚 leaflet.2plot.dev

Every page also serves /<page>/llms.txt — the prose plus the complete example source, directive-expanded and ready to paste into a chat window.

You can also run the docs site locally:

pip install -r requirements.txt
# markdown2dash pins gunicorn<22, against the CVE-driven gunicorn>=23 floor
# in requirements.txt. Its real dependencies are listed there, so it installs
# without its dependency graph — the docs pages need it.
pip install --no-deps markdown2dash==0.1.2
python run.py                 # open http://127.0.0.1:8050

…or the standalone component harness, which exercises the compiled dl2.* surface without the docs shell:

python usage.py               # open http://127.0.0.1:8060

Components

26 components, all loading from the single bundled JS file.

Core

Layers

Vectors

Controls

Full prop tables are generated into each dash_leaflet2/<Component>.py docstring by dash-generate-components, and rendered on every documentation page.

The data boundary

• Two-way props are marked in the docstrings. [MUTABLE] means Python callbacks can push the value into the map; [READONLY] means the map writes it back. Map.center, Map.zoom, Map.bearing, Marker.position, TileSelector.selectedTiles, ImageOverlay.bounds and EditControl.geojson all round-trip in both directions.
• Events are props, not a separate channel. Clicks land as n_clicks, drags as an updated position, draws as geojson + lastAction — so a plain @callback is the whole integration.
• Pointer events carry v2's extra data. Pointer props report pointerType, pressure and tiltX / tiltY from the native PointerEvent, which Leaflet 1 could not express.
• Only JSON crosses the boundary. Tiles, canvas bitmaps and the Leaflet instances themselves stay in the browser.

Dash compatibility

dash-leaflet2 targets Dash 4.1 and up. That range is verified, not assumed — scripts/compat_matrix.py builds a throwaway virtualenv per Dash version, installs the full documentation site into each, and runs the smoke suite there:

python scripts/compat_matrix.py                    # 4.1.0, 4.2.0, 4.3.0, 4.4.1
python scripts/compat_matrix.py 4.4.1 --backends flask fastapi
python scripts/compat_matrix.py --browser          # + Playwright console-error sweep

Results land in COMPATIBILITY.md. The per-version harness is scripts/smoke_test.py, which also runs standalone:

python scripts/smoke_test.py

It checks that every markdown page registered a route with no duplicate paths, that every page layout builds and survives Dash's JSON encoder, and that every route plus /_dash-layout, /_dash-dependencies, /healthz, /llms.txt, /robots.txt and /sitemap.xml answers over the backend's test client. No socket, no browser.

Development

# Install dependencies
npm install                  # TypeScript + webpack toolchain
pip install -r requirements.txt

# Build the JS bundle + regenerate the Python wrappers
npm run build                # webpack UMD bundle + dash-generate-components
npm run build:js             # webpack only (after .tsx edits)
npm run build:backends       # regenerate Python classes only (after prop changes)
npm run watch                # JS-only rebuild loop

# Run
python run.py                # documentation site  → http://127.0.0.1:8050
python usage.py              # component harness   → http://127.0.0.1:8060

# Test
python scripts/smoke_test.py

# Build a distribution
python -m build --wheel

• TypeScript source of truth is src/ts/ — components/ holds the public components; icons.ts, theme.css, useLayer.ts and layersControl-shared.ts are the shared plumbing; types/leaflet.d.ts is our ambient declaration (Leaflet 2 ships no types).
• After editing src/ts/components/*.tsx you must npm run build — the Python classes and the JS bundle are generated artifacts.
• The built bundle and generated wrappers are committed, so pip install -e . works without npm.
• dash_leaflet2/__init__.py is hand-maintained (it registers _js_dist); dash-generate-components does not regenerate it.
• Defaults go in destructured default parameters, never Component.defaultProps (React 18.3 deprecation warning; react-docgen@5 reads both, so the defaults survive).
• Keep the version in sync across package.json, pyproject.toml and lib/constants.py when cutting a release.

Documentation site

Each page is a docs/<slug>/<slug>.md with frontmatter plus a docs/<slug>/example.py exporting a component. pages/markdown.py walks them and registers each as a Dash page; .. exec:: embeds the live demo, .. source:: renders the example source, and .. kwargs:: generates the prop table. Adding a page is two files and no routing code.

The deployed site at leaflet.2plot.dev also runs as a 2plot network satellite — ad slots, traffic rollups, Clerk sign-in and an admin page-visibility board. Every one of those is dormant without its environment keys, so a local python run.py is just the docs. See DEPLOYMENT.md.

Requirements

• Python >= 3.9 (the documentation site itself needs >= 3.10 — see below)
• Dash >= 4.1
• Node.js >= 16 — only to rebuild the JS bundle

The package needs only Python 3.9+ and Dash 4.1+; every combination in that range is verified in CI. Running the documentation site from source additionally needs Python 3.10+, because python-frontmatter imports typing.TypeGuard. That floor does not apply to pip install dash-leaflet2.

Leaflet 2 notes

Leaflet 2 is a genuine break from 1.x, and these cost real debugging time:

• The version string is 2.0.0-alpha.1, with the dot. The dotless form 404s on unpkg.
• The UMD build exposes window.leaflet, not window.L — the L global is gone.
• There are no lowercase factory functions. Use new Marker(...), not L.marker(...).
• v2 fires pointer events (pointermove / pointerdown), not mousemove / mousedown.
• Canvas-clear bug: BlanketOverlay._onMoveEnd() draws and then calls _resizeContainer(), which sets canvas.width and wipes the bitmap — so the Canvas renderer goes blank after pan/zoom. We re-issue a redraw on the next animation frame after moveend / zoomend. The SVG renderer is unaffected.
• Default marker icons need explicit wiring when bundled: v2's CSS-based icon-path detection fails, and Marker's default icon is a shared instance created at module-load time. All of it is handled in src/ts/icons.ts.

The documentation site covers each of these with a live page.

Community & support

Come build with us:

• 💬 Discord — discord.gg/WEnZR35mrK
• ▶️ YouTube — @2plotai
• 🐛 Issues — github.com/pip-install-python/dash-leaflet2/issues

More from Pip Install Python LLC

dash-leaflet2 is one of several tools built and maintained by Pip Install Python LLC:

License

MIT — see LICENSE. Built by Pip Install Python LLC to bring a generation-ahead mapping stack into the Dash framework.
