Dear RosNodeViewer
About
- Visualize ROS2 node diagram
- Support the following sources:
- architecture.yaml generated by CARET
- rosgraph.dot generated by rqt_graph
- running ROS graph analysis
Requirements
- Ubuntu 20.04 or 22.04
- graphviz is required
- optional: ROS 2 Galactic or Humble if you need runtime ROS graph analysis
- e.g.,
sudo apt install ros-humble-rqt-graph,sudo apt install ros-humble-desktop
- e.g.,
- Not tested in Windows / Mac
Get Started
# Install Dear RosNodeViewer
pipx install dear-ros-node-viewer --system-site-packages
# Download sample graph
wget https://raw.githubusercontent.com/iwatake2222/dear_ros_node_viewer/main/sample/architecture_autoware.yaml
# Run Dear RosNodeViewer
dear_ros_node_viewer architecture_autoware.yaml
- Quick operation guide:
- Middle button drag: move graph area
- Mouse scroll: zoom in/out (zoom function is tentative)
How to Use
Development
Setup
git clone https://github.com/iwatake2222/dear_ros_node_viewer.git
cd dear_ros_node_viewer
pip install -e .
pip install -r requirements.txt
Running Tests
# Run all tests
pytest tests/ -v
# Run with coverage
pytest --doctest-modules -v --cov=./src/dear_ros_node_viewer
# Run single test file
pytest tests/test_caret2networkx.py -v
Linting
flake8 . --exclude=.venv --count --select=E9,F63,F7,F82 --show-source --statistics
pylint ./src/dear_ros_node_viewer --disable=E0401,W1203,C0301
Acknowledgements
- Dear RosNodeViewer utilizes Dear PyGui
- Dear RosNodeViewer is named in honor of Dear PyGui
- Dear RosNodeViewer contains Roboto font
- licensed under the Apache License, Version 2.0.
