DeepLC: Retention time prediction for (modified) peptides using Deep Learning.

Project description

GitHub release PyPI Conda GitHub Workflow Status License Twitter

DeepLC: Retention time prediction for (modified) peptides using Deep Learning.


DeepLC is a retention time predictor for (modified) peptides that employs Deep Learning. It's strength lies in the fact that it can accurately predict retention times for modified peptides, even if hasn't seen said modification during training.

DeepLC can be run with a graphical user interface (GUI) or as a Python package. In the latter case, DeepLC can be used from the command line, or as a python module.

Graphical user interface


Download GUI

  1. Download from the latest release and unzip.
  2. Install DeepLC GUI with install_gui_windows.bat or, depending on your operating system.
  3. Run DeepLC GUI by running the deeplc_gui.jar.

Python package


install with bioconda install with pip container

Install with conda, using the bioconda and conda-forge channels:
conda install -c bioconda -c conda-forge deeplc

Or install with pip:
pip install deeplc

Command line interface

To use the DeepLC CLI, run:

deeplc --file_pred <path/to/peptide_file.csv>

We highly recommend to add a peptide file with known retention times for calibration:

deeplc --file_pred  <path/to/peptide_file.csv> --file_cal <path/to/peptide_file_with_tr.csv>

For an overview of all CLI arguments, run deeplc --help.

Python module

Minimal example:

import pandas as pd
from deeplc import DeepLC

peptide_file = "datasets/test_pred.csv"
calibration_file = "datasets/test_train.csv"

pep_df = pd.read_csv(peptide_file, sep=",")
pep_df['modifications'] = pep_df['modifications'].fillna("")

cal_df = pd.read_csv(calibration_file, sep=",")
cal_df['modifications'] = cal_df['modifications'].fillna("")

dlc = DeepLC()
preds = dlc.make_preds(seq_df=pep_df)

For a more elaborate example, see examples/ .

Input files

DeepLC expects comma-separated values (CSV) with the following columns:

  • seq: unmodified peptide sequences
  • modifications: MS2PIP-style formatted modifications: Every modification is listed as location|name, separated by a pipe (|) between the location, the name, and other modifications. location is an integer counted starting at 1 for the first AA. 0 is reserved for N-terminal modifications, -1 for C-terminal modifications. name has to correspond to a Unimod (PSI-MS) name.
  • tr: retention time (only required for calibration)

For example:


See examples/datasets for more examples.

Prediction models

DeepLC comes with multiple CNN models trained on data from various experimental settings:

Model filename Experimental settings Publication
full_hc_dia_fixed_mods.hdf5 Reverse phase Rosenberger et al. 2014
full_hc_LUNA_HILIC_fixed_mods.hdf5 HILIC Spicer et al. 2018
full_hc_LUNA_SILICA_fixed_mods.hdf5 HILIC Spicer et al. 2018
full_hc_PXD000954_fixed_mods.hdf5 Reverse phase Rosenberger et al. 2014

By default, DeepLC selects the best model based on the calibration dataset. If no calibration is performed, the first default model is selected. Always keep note of the used models and the DeepLC version.


If you use DeepLC for your research, please use the following citation:

DeepLC can predict retention times for peptides that carry as-yet unseen modifications
Robbin Bouwmeester, Ralf Gabriels, Niels Hulstaert, Lennart Martens, Sven Degroeve
bioRxiv 2020.03.28.013003; doi: 10.1101/2020.03.28.013003


Q: Is it required to indicate fixed modifications in the input file?

Yes, even modifications like carbamidomethyl should be in the input file.

Q: So DeepLC is able to predict the retention time for any modification?

Yes, DeepLC can predict the retention time of any modification. However, if the modification is very different from the peptides the model has seen during training the accuracy might not be satisfactory for you. For example, if the model has never seen a phosphor atom before, the accuracy of the prediction is going to be low.

Q: Installation fails. Why?

Please make sure to install DeepLC in a path that does not contain spaces. Run the latest LTS version of Ubuntu or Windows 10. Make sure you have enough disk space available, surprisingly TensorFlow needs quite a bit of disk space. If you are still not able to install DeepLC, please feel free to contact us: and

Q: I have a special usecase that is not supported. Can you help?

Ofcourse, please feel free to contact us: and

Q: DeepLC runs out of memory. What can I do?

You can try to reduce the batch size. DeepLC should be able to run if the batch size is low enough, even on machines with only 4 GB of RAM.

Q: I have a graphics card, but DeepLC is not using the GPU. Why?

For now DeepLC defaults to the CPU instead of the GPU. Clearly, because you want to use the GPU, you are a power user :-). If you want to make the most of that expensive GPU, you need to change or remove the following line (at the top) in

# Set to force CPU calculations
os.environ['CUDA_VISIBLE_DEVICES'] = '-1'

Also change the same line in the function reset_keras():

# Set to force CPU calculations
os.environ['CUDA_VISIBLE_DEVICES'] = '-1'

Either remove the line or change to (where the number indicates the number of GPUs):

# Set to force CPU calculations
os.environ['CUDA_VISIBLE_DEVICES'] = '1'

Q: What modification name should I use?

The names from unimod are used. The PSI-MS name is used by default, but the Interim name is used as a fall-back if the PSI-MS name is not available. Please also see unimod_to_formula.csv in the folder unimod/ for the naming of specific modifications.

Q: I have a modification that is not in unimod. How can I add the modification?

In the folder unimod/ there is the file unimod_to_formula.csv that can be used to add modifications. In the CSV file add a name (that is unique and not present yet) and the change in atomic composition. For example:

Met->Hse,O,H(-2) C(-1) S(-1)

Make sure to use negative signs for the atoms subtracted.

Q: Help, all my predictions are between [0,10]. Why?

It is likely you did not use calibration. No problem, but the retention times for training purposes were normalized between [0,10]. This means that you probably need to adjust the retention time yourselve after analysis or use a calibration set as the input.

Q: How does the ensemble part of DeepLC work?

Models within the same directory are grouped if they overlap in their name. The overlap has to be in their full name, except for the last part of the name after a "_"-character.

The following models will be grouped:


None of the following models will not be grouped:


Q: I would like to take the ensemble average of multiple models, even if they are trained on different datasets. How can I do this?

Feel free to experiment! Models within the same directory are grouped if they overlap in their name. The overlap has to be in their full name, except for the last part of the name after a "_"-character.

The following models will be grouped:


So you just need to rename your models.
