difotrain 0.1.0

Human to Robot Motion Transfer

DifoTrain

Human to Robot Motion Transfer

---

Overview

DifoTrain is a comprehensive pipeline designed to capture human motion through webcam input, learn intelligent mappings to robot joint configurations, and control robotic systems to authentically imitate human movements in both simulated and real-world environments.

Features

Motion Capture Real-time human pose estimation using Google MediaPipe Pose Landmarker for accurate motion tracking.	Representation Standardized skeleton representation for human and robot states, enabling seamless data transfer.
Learning Imitation learning module using PyTorch to map human joint positions and angles to robot commands.	Control Robot controller integration with comprehensive PyBullet simulation support.

Installation

This project uses uv for dependency management, but standard pip works as well.

Prerequisites

• Python 3.13 or higher
• Webcam for motion recording

Setup

Step 1: Install Dependencies

Using uv (Recommended):

uv sync

Using pip:

pip install -r requirements.txt

Direct installation:

pip install mediapipe opencv-python numpy torch

Step 2: Download MediaPipe Model

The system requires the pose_landmarker_lite.task model file. Run the setup script to download it automatically:

python setup_mediapipe.py

Usage

1. Record Human Motion

Capture motion from your webcam. This saves a trajectory file to storage/human_trajectory.json.

python main.py record

Press q to stop recording.

2. Generate Dummy Data (Optional)

If you don't have a webcam, you can generate synthetic test data:

python -m tests.generate_dummy_data

3. Train Imitation Model

Train a neural network to map human states to robot actions using the recorded data.

python -m learning.imitation

4. Run Robot Controller

Execute the robot controller to perform the trajectory using retargeting and the learned model.

python -m robot.controller

Project Structure

difotrain/
├── capture/           # Modules for webcam capture and MediaPipe processing
├── representation/    # Data structures for Skeleton and Trajectory states
├── storage/          # JSON storage for recorded movements
├── learning/         # PyTorch models for imitation learning
├── robot/            # Robot control interfaces
├── simulation/       # PyBullet simulation environments
└── tests/            # Unit tests and data generators

Architecture

graph LR
    A[Webcam Input] --> B[MediaPipe Pose]
    B --> C[Human Skeleton]
    C --> D[Trajectory Storage]
    D --> E[Imitation Learning]
    E --> F[Robot Controller]
    F --> G[PyBullet Simulation]
    F --> H[Real Robot]

Workflow

sequenceDiagram
    participant User
    participant Capture
    participant Learning
    participant Robot

    User->>Capture: Record Motion
    Capture->>Capture: Process with MediaPipe
    Capture->>Learning: Save Trajectory
    User->>Learning: Train Model
    Learning->>Learning: Map Human to Robot
    User->>Robot: Execute Movement
    Robot->>Robot: Apply Learned Mapping

Technologies

• MediaPipe: Human pose estimation and landmark detection
• PyTorch: Neural network training and inference
• OpenCV: Video capture and image processing
• PyBullet: Physics simulation and robot control
• NumPy: Numerical computing and array operations

Contributing

Contributions are welcome. Please feel free to submit a Pull Request.

License

This project is licensed under the MIT License - see the LICENSE file for details.

Acknowledgments

• Google MediaPipe team for the pose estimation models
• PyBullet community for the simulation framework
• PyTorch team for the deep learning framework

---

Made with dedication to advancing human-robot interaction
