docflow-sager 0.1.1

Document-native DAG runner for preprocessing PDFs, Office files, and email messages into structured evidence artifacts.

docflow-sager

docflow-sager is a document-native workflow engine for preprocessing files into structured evidence artifacts, plain-text exports, and downstream indexes.

The package name on PyPI is docflow-sager, while the Python import stays:

import docflow

What It Does

DocFlow is designed for document pipelines in the same way PromptFlow is designed for prompt pipelines.

Instead of chaining prompt nodes, DocFlow chains document-processing steps such as:

• scanning files
• parsing documents
• normalizing parser output into evidence atoms
• enriching metadata
• constructing an evidence graph
• building semantic, structural, and spatial indexes
• exporting structured outputs

It is a strong fit for:

• document intelligence
• preprocessing large file corpora
• evidence-aware retrieval pipelines
• text extraction and indexing workflows
• AI-ready document transformation

Supported Input Types

DocFlow currently supports:

• pdf
• docx
• doc
• xlsx
• xls
• msg

Implementation notes:

• pdf uses pypdf
• docx uses Open XML parsing
• doc uses OLE-based text extraction as a pragmatic fallback
• xlsx uses Open XML parsing
• xls uses xlrd
• msg uses extract-msg

Installation

pip install docflow-sager

Quick Start

Python API

from docflow import run_flow

result = run_flow(
    "document_preprocess.flow.dag.yaml",
    inputs={
        "source_dir": "/path/to/documents",
        "output_dir": "/tmp/docflow_run",
    },
)

print(result["flow_name"])
print(result["final_output"])

CLI

The package exposes a docflow command-line entrypoint.

Run a flow:

docflow run document_preprocess.flow.dag.yaml --source-dir /path/to/documents --output-dir /tmp/docflow_run --trace

Inspect the compiled graph:

docflow graph document_preprocess.flow.dag.yaml

Example Flow

name: document_preprocess
variables:
  dataset_name: docflow_demo
  output_dir: docflow_runs/demo

nodes:
  - name: scan
    step: scan_documents
    config:
      source_dir: ${inputs.source_dir}
      file_types: [pdf, docx, doc, xlsx, xls, msg]

  - name: parse
    step: parse_documents
    depends_on: [scan]
    config:
      dataset_name: ${dataset_name}

  - name: normalize
    step: normalize_atoms
    depends_on: [parse]

  - name: metadata
    step: enrich_metadata
    depends_on: [normalize]

  - name: graph
    step: build_evidence_graph
    depends_on: [metadata]

  - name: indexes
    step: build_indexes
    depends_on: [graph]

  - name: write
    step: write_outputs
    depends_on: [graph, indexes]
    config:
      output_dir: ${output_dir}

outputs:
  final_node: write

Output Structure

A typical DocFlow run writes:

• documents/*.json
• text/*.txt
• indexes/semantic_index.json
• indexes/structural_index.json
• indexes/spatial_index.json
• manifest.json

The manifest records:

• processed document count
• parse error count
• per-document stats
• skipped-file error details

Core Concepts

Evidence Atoms

Each extracted line or structured unit becomes an evidence atom containing:

• document id
• page number
• text
• reading order
• parser provenance
• confidence
• role label

Evidence Graph

DocFlow constructs lightweight graph edges between atoms, including:

• adjacency in reading order
• containment under headings

This makes the outputs better suited for downstream retrieval and reasoning than plain flattened text alone.

Multi-Format Exports

DocFlow outputs can later be exported or indexed as:

• plain text
• JSON
• CSV
• XLSX
• SDF-compatible structured artifacts

Notes and Limitations

• .doc support is text-oriented, not layout-faithful
• .msg support focuses on message metadata and body extraction
• malformed PDFs are skipped and logged in the manifest instead of aborting the full batch
• parser quality depends on the underlying format adapter

Package Identity

• PyPI package: docflow-sager
• Python import: docflow
• CLI command: docflow

Repository

Source repository:

https://github.com/Meet2147/SAGER
